The Kramer FA10BC-4 interfaces a USB audio host with supported analog speaker and microphone connections. A USB camera output is also listed for compatible conferencing arrangements.
FA10BC-4 Detailed Features
- Connect USB computer audio to analog peripherals. This model provides a USB host interface and analog audio connections. It suits installations that need a controlled audio boundary while retaining compatible speakers or analog microphone equipment.
- Support microphone and camera use. The manufacturer lists microphone support and a USB camera output for this model. These functions support compatible conferencing arrangements without assuming support for every USB peripheral type.
- Keep media channels closed until activated. Positive-disconnect operation leaves the relevant channels disconnected by default. Users open supported media paths intentionally, helping manage when audio or camera information can pass.
- Use push-button control with visible status. Buttons and colored indicators show whether a controlled channel is open or closed. This gives people in the room a direct indication of the current media state.
- Close connections automatically after a set interval. Timed operation can end an open session without relying on a user to remember a final button press. Configuration options determine how long channels stay open and whether extensions are allowed.
- Limit unwanted audio signaling. Directional audio paths and low-pass filtering help reduce risks associated with repurposing audio peripherals or transmitting signals outside the intended listening range.
- Fit a small desktop installation. The enclosure measures approximately 85 × 65 × 34mm. This model has analog peripheral audio connections; it does not provide the USB headset output found on other configurations.
Specifications
| Manufacturer part number | CPN22569 |
|---|---|
| FEATURES — Input Interface (Host) | USB |
| FEATURES — Output Interface (Audio Device) | Analog |
| FEATURES — Microphone Support | V |
| FEATURES — Always Open | X |
| FEATURES — USB output for camera | V |
| FEATURES — USB output for Headset | X |
| PHYSICAL — Dimensions | 85(W) x 65 (D) x 34 (H) mm / 3.3(W) x 2.6 (D) x 1.3 (H) inch |
| PHYSICAL — Weight | 185 gr (0.41 lbs.) |
| ENVIRONMENTAL — Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| ENVIRONMENTAL — Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| ENVIRONMENTAL — Humidity | Operating - 20% to 80% non-condensing; Storage - 10% to 90% non-condensing |
| ENVIRONMENTAL — Altitude | 0 to 10,000 ft |
| GENERAL INFO — Manufactured | BAA & TAA Compliant |
| GENERAL INFO — Product life-cycle | 10 years |
Technical Questions and Answers
What does the FA10BC-4 do?
The Kramer FA10BC-4 interfaces a USB audio host with supported analog speaker and microphone connections. A USB camera output is also listed for compatible conferencing arrangements.
What is specified for input interface (host)?
USB
What is specified for output interface (audio device)?
Analog
What is specified for dimensions?
85(W) x 65 (D) x 34 (H) mm / 3.3(W) x 2.6 (D) x 1.3 (H) inch
What is specified for product life-cycle?
10 years
Where can I check installation compatibility?
Use the manufacturer documentation linked below to verify the exact model, connections and installation requirements before installation.
How do I identify the correct version?
Match model FA10BC-4 and manufacturer part CPN22569 when ordering.
Is this suitable for my installation?
It is intended for supported conferencing installations requiring audio isolation. Match its listed interfaces, physical format and operating requirements to the rest of the system.
Choosing the Right Product
What is the Kramer FA10BC-4 used for?
It is used for supported conferencing installations requiring audio isolation. Interfaces a USB audio host with supported analog speaker and microphone connections. A USB camera output is also listed for compatible conferencing arrangements.
Who should choose the FA10BC-4?
Choose this model when your project needs supported conferencing installations requiring audio isolation. Compare the model-specific connections and specifications above with the equipment in your system.
What should I check before ordering the FA10BC-4?
Confirm manufacturer part CPN22569, the required connections and the installation requirements. Use the linked documentation to check compatible equipment and required accessories.
