QSC I/O USB Bridge Q-SYS AV-to-USB Bridging Solution

QSC

QSC I/O USB Bridge Q-SYS AV-to-USB Bridging Solution
$2,200.00
Part Number:
QSC-I/O USB Bridge
Condition:
New
Availability:
3-5 Days
1:
Driverless USB 2.0 Connection
2:
Built for BYOD
3:
Resolutions Upto 1080p
4:
Emulates Computer Soundcard
5:
Free USA Shipping
6:
QSC Factory Warranty
7:
Ships with the Latest Firmware
8:
QSC Certified

This QSC I/O-USB Bridge Q-SYS AV-to-USB Bridging Solution provides convenient USB connectivity for devices that require Q-SYS audio, video, and control, bringing networked AV capabilities directly to meeting room systems.

The Q-SYS I/O-USB Bridge integrates networked Q-SYS conferencing camera video and professional audio processing into soft-codec applications through a single USB connection, without requiring special drivers.

Designed for medium to large meeting rooms, the I/O-USB Bridge connects Q-SYS networked AV systems with compatible conferencing applications, simplifying integration and supporting flexible room configurations.

As part of the Q-SYS Platform, the I/O-USB Bridge can function as an in-rack endpoint or a Bring Your Own Device (BYOD) interface, delivering conferencing camera feeds and audio processed with Q-SYS acoustic echo cancellation (AEC).

Cryptographically signed firmware updates help support secure system updates and ongoing functionality improvements across the Q-SYS ecosystem.

READ MORE

QSC I/O-USB Bridge Q-SYS AV-to-USB Bridging Solution Features

  • Driverless USB 2.0 connectivity using USB Video Class (UVC) and USB Audio Class (UAC)
  • Designed for plug-and-play Bring Your Own Device (BYOD) conferencing
  • Supports video resolutions up to 1080p
  • Emulates webcam video and AEC-enabled speakerphone audio over a single USB connection
  • Emulates a computer sound card, including multichannel audio
  • Bridges audio and video between Q-LAN and USB
  • Supports routing USB HID events across Q-LAN networks
  • Powered by an external 12 V DC power supply or Power over Ethernet (PoE, IEEE 802.3af)
Q-SYS Level 1 Certified Expertise at HDTV Supply

QSC Certified Expertise

Knowledgeable Support for QSC Products

HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.

This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.

Why Buy the QSC I/O-USB Bridge from HDTV Supply?

Connect Q-SYS networked audio and video with compatible USB conferencing applications using a flexible, driverless AV bridging solution. Contact HDTV Supply for assistance with product selection and system compatibility.

Ask a Question About the QSC I/O-USB Bridge

Need help with compatibility, connectivity, or integrating the QSC I/O-USB Bridge into your Q-SYS system? Contact our team for assistance.

Call: 833-WOLFPACK (833-965-3722)

Website: HDTV Supply

You can also submit your product question through the product page's question form.

QSC I/O-USB Bridge Q-SYS AV-to-USB Bridging Solution Specifications

Supported Video Resolutions MJPEG: 1080p at 30 or 15 fps; 720p at 30 or 15 fps; 360p at 30 or 15 fps; 180p at 30 or 15 fps
USB Connection USB 2.0; driverless USB Video Class (UVC) and USB Audio Class (UAC) connection for compatible Windows and OS X devices
USB Functions Emulates webcam video, AEC speakerphone audio, and multichannel sound card functions over a single USB connection
Network Connectivity Bridges audio and video between Q-LAN and USB; supports routing USB HID events across Q-LAN networks
Power Options IEEE 802.3af Power over Ethernet (PoE) or 12 V DC, 1 A
Dimensions 25 × 85 × 183 mm / 1 × 3.35 × 7.2 in (as supplied; verify against the manufacturer's documentation)
Weight 500 g / 1.1 lb

QSC I/O-USB Bridge Manuals and Documentation

QSC I/O-USB Bridge Frequently Asked Questions

Q1: What is the QSC I/O-USB Bridge?

The QSC I/O-USB Bridge connects Q-SYS networked audio and video systems to compatible computers and soft-codec conferencing applications through USB.

Q2: Does the I/O-USB Bridge require special USB drivers?

The device is designed to use standard USB Video Class (UVC) and USB Audio Class (UAC) interfaces, avoiding the need for dedicated drivers on compatible systems.

Q3: What video resolutions does the bridge support?

The supplied specifications list MJPEG video at resolutions up to 1080p at 30 frames per second, with additional lower-resolution modes available.

Q4: Can the I/O-USB Bridge be used for BYOD meetings?

Yes. It is designed to support Bring Your Own Device (BYOD) workflows by connecting a compatible computer to a Q-SYS conferencing system over USB.

Q5: Does it support Q-SYS conferencing cameras?

It is designed to bridge supported networked Q-SYS conferencing camera video to USB conferencing applications. Confirm camera and system compatibility before installation.

Q6: Does the bridge support acoustic echo cancellation?

It can deliver audio processed by Q-SYS acoustic echo cancellation (AEC) as part of a properly configured Q-SYS conferencing system.

Q7: How does the I/O-USB Bridge connect to a computer?

It connects to a compatible computer through USB 2.0, presenting supported audio and video functions through standard USB interfaces.

Q8: How is the QSC I/O-USB Bridge powered?

The supplied specifications list IEEE 802.3af Power over Ethernet (PoE) or a 12 V DC, 1 A power supply.

Q9: Can the bridge emulate a computer sound card?

Yes. The supplied specifications state that it can emulate a multichannel sound card along with webcam video and AEC speakerphone audio over a single USB connection.

Q10: Is the I/O-USB Bridge suitable for medium and large meeting rooms?

It is designed for networked AV integration in meeting rooms, including medium and large installations that use Q-SYS audio processing and conferencing equipment.

Q11: How does the QSC I/O-USB Bridge integrate Q-SYS AV with video conferencing software?

The bridge transports supported Q-SYS audio and networked camera video to a compatible computer over USB, allowing supported conferencing applications to use the connected AV devices.

Q12: What USB standards does the QSC I/O-USB Bridge use?

The supplied specifications identify USB 2.0 connectivity using USB Video Class (UVC) and USB Audio Class (UAC) for compatible host devices.

Q13: Can the QSC I/O-USB Bridge route USB HID events over Q-LAN?

Yes. The listed features include routing USB human interface device (HID) events across Q-LAN networks, subject to the system configuration and supported devices.

Q14: Does the QSC I/O-USB Bridge support secure firmware updates?

The supplied product description states that the Q-SYS Platform supports cryptographically signed firmware updates to help maintain system security and functionality.

Q15: What should I check before purchasing a QSC I/O-USB Bridge?

Confirm compatibility with your Q-SYS system, conferencing cameras, computer operating system, conferencing software, network configuration, and available power source. Contact HDTV Supply for assistance.

QSC I/O-USB Bridge Warranty

Warranty coverage and terms for the QSC I/O-USB Bridge have not been confirmed in the supplied product information. Please contact HDTV Supply to verify the applicable warranty for this product before purchase.

For assistance, call 833-WOLFPACK (833-965-3722).

QSC I/O-USB Bridge Reviews

Customer reviews for the QSC I/O-USB Bridge will appear here when available. If you have purchased and used this product, please share your experience to help other customers make an informed decision.
