QSC AD-S162T-WH AcousticDesign Series 16-Driver Column Surface-Mount Loudspeaker (White)
The QSC AD-S162T-WH is a 16-driver column loudspeaker from the AcousticDesign Series, designed for professional foreground and background audio applications. Its slim column profile provides an unobtrusive appearance for installations where controlled sound coverage and discreet loudspeaker placement are important.
Supporting 70V, 100V, and 8-ohm bypass operation, this passive loudspeaker offers flexibility for different commercial audio system designs. Its pan-and-tilt mounting system supports positioning close to the wall while allowing downward tilt to direct sound toward the listening area.
Features
- 16-driver column surface-mount loudspeaker for professional audio applications
- Slim, unobtrusive design for commercial and architectural environments
- 70V and 100V transformer operation with 8-ohm bypass
- Selectable broad and narrow beam contour options
- Pan-and-tilt mounting system for flexible loudspeaker positioning
- Supports up to 20° downward tilt, as specified in the supplied product information
- Coated aluminum enclosure with paintable enclosure and grille
- Weather-treated cones and powder-coated grille
- IP54-rated dust and splash resistance
- Suitable for appropriate indoor and outdoor installations when installed according to manufacturer guidance
QSC Certified Expertise
Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Why Buy the QSC AD-S162T-WH from HDTV Supply?
HDTV Supply offers professional audio products for commercial installations. The QSC AD-S162T-WH is a flexible column loudspeaker option for projects that require a slim design, distributed audio connectivity, and directional sound coverage.
Ask a Question About the QSC AD-S162T-WH
Need help with system compatibility, amplifier selection, mounting, or beam coverage? Contact HDTV Supply for assistance with your QSC loudspeaker installation.
QSC AD-S162T-WH Specifications
| General | |
|---|---|
| Brand | QSC |
| Model | AD-S162T-WH |
| Product Type | Passive Column Surface-Mount Loudspeaker |
| Enclosure Material | Coated aluminum |
| Enclosure Color | White, based on the product model and title; verify the supplied finish before publishing |
| Speaker System and Performance | |
| Speaker Type | Passive |
| Number of Drivers | 16 |
| Driver Type | 16 × 2.75-inch full-range paper drivers |
| Nominal Output Power | 200W, as listed in the supplied specifications |
| Recommended Amplifier Power | 250W |
| Frequency Response | 90 Hz–17 kHz, as listed in the supplied specifications |
| Nominal Impedance | 8 ohms |
| Maximum SPL | 112 dB, as listed in the supplied specifications |
| Sensitivity | 89 dB, as listed in the supplied specifications |
| Transformer Operation | 70V/100V with 8-ohm bypass |
| Coverage | 160° × 15°, as listed in the supplied specifications |
| Beam Contour | Selectable broad/narrow contour |
| Installation and Environmental | |
| Mounting System | Pan-and-tilt wall mounting system |
| Included Accessory | Wall mounting bracket, as listed in the supplied specifications |
| Environmental Rating | IP54 dust and splash resistance |
| Recommended Placement | Indoor and appropriate outdoor installations, subject to manufacturer guidance |
| Dimensions and Weight | |
| Width | 5.2 inches |
| Depth | 5 inches |
| Height | 45.7 inches |
| Product Weight | 26.01 lb |
| Package Weight | 32 lb, as listed in the supplied packaging information |
| Box Dimensions (L × W × H) | 54.5 × 12.25 × 9.75 inches |
QSC AD-S162T-WH Manuals and Documentation
Q/A
Q1: What is the QSC AD-S162T-WH?
The QSC AD-S162T-WH is a passive, 16-driver column surface-mount loudspeaker from the AcousticDesign Series, intended for professional foreground and background audio applications.
Q2: How many drivers does the AD-S162T-WH have?
The supplied specifications list 16 full-range 2.75-inch paper drivers.
Q3: Can the AD-S162T-WH operate on 70V and 100V systems?
Yes. It supports 70V and 100V transformer operation, as well as an 8-ohm bypass mode. Follow the manufacturer's wiring and configuration instructions.
Q4: What is the recommended amplifier power?
The supplied product specifications list a recommended amplifier power of 250W. Confirm the correct amplifier rating and configuration using QSC's documentation.
Q5: What is the frequency response of this loudspeaker?
The supplied specifications list a frequency response of 90 Hz to 17 kHz. Check the manufacturer's datasheet for the measurement conditions.
Q6: What is the coverage pattern of the AD-S162T-WH?
The supplied specifications list a coverage pattern of 160° × 15°. The loudspeaker also offers selectable broad and narrow beam contour options.
Q7: Does the AD-S162T-WH include a mounting bracket?
The supplied specifications list a wall mounting bracket as an included accessory. Verify package contents before installation.
Q8: Can the loudspeaker be tilted downward?
The supplied product description identifies a pan-and-tilt mounting system that supports up to 20° of downward tilt. Consult the installation manual for the permitted adjustment range and procedure.
Q9: Is the AD-S162T-WH suitable for outdoor use?
The supplied specifications list an IP54 rating for dust and splash resistance. Outdoor use should follow QSC's environmental and installation guidance for the specific location.
Q10: Can the enclosure and grille be painted?
The supplied product description identifies the enclosure and grille as paintable. Follow the manufacturer's painting instructions to avoid affecting the grille, drivers, or enclosure performance.
Q11: What applications are suitable for the QSC AD-S162T-WH column loudspeaker?
It is intended for foreground and background sound applications, including environments where a slim loudspeaker design and controlled coverage are useful.
Q12: What is the benefit of the selectable broad and narrow beam contour?
Selectable beam contour options allow the loudspeaker's coverage behavior to be configured for different acoustic and listening conditions. Consult QSC documentation to select the appropriate setting.
Q13: What is the IP54 rating on the AD-S162T-WH?
IP54 indicates protection against dust ingress at a level that does not interfere with operation and protection against water splashes under defined test conditions. It does not mean the speaker is waterproof or suitable for every outdoor exposure.
Q14: What are the dimensions and weight of the AD-S162T-WH?
The supplied specifications list dimensions of approximately 5.2 inches wide, 5 inches deep, and 45.7 inches high, with a product weight of 26.01 lb.
Q15: Where can I buy the QSC AD-S162T-WH?
Contact HDTV Supply to inquire about availability and purchasing the QSC AD-S162T-WH. Email customerservice@hdtvsupply.com for assistance.
Warranty Information
The AD-S162T-WH is a QSC loudspeaker. Please contact HDTV Supply or QSC to confirm the applicable warranty coverage for this product and the terms associated with your purchase.
