Build a Modular HDMI Matrix Switch From a 8x8 to 32x32

(No reviews yet) Write a Review
$400.00
Part Number:
WPL-FOL
UPC:
728350689644
Availability:
Usually ships in 5-7 business days
1:
Family of HDMI Matrix Switchers
2:
You Build w/1080p HDMI In & Out Cards
3:
8x8, 16x16 & 32x32 Chassis Sizes
4:
16 Presets to Save/Recall Scenes
5:
IR Remote, RS-232 & Front Control
6:
Optional 7" Color Dual Displays (Shown)
7:
Optional 1080p to 220' HDMI Baluns via CAT6

HDTV Supplys WolfPackLite 1080p Modular HDMI Matrix Switchers are a family of modular HDMI matrix switchers that allow them to be an all-in-one solution for a variety of different projects. They can be used in Restaurants & Sport Bars. Because they are Modular HDMI Matrix Switchers, they allow any input to be routed to any output; or the same input to be routed to all outputs, or any combination. Our HDMI Modular Matrix Switchers can be controlled by a remote control, front panel buttons or color display, an RS232 port, Windows software & optional Crestron & Control4 Drivers.

These Modular Matrix system are designed to allow the switching & distribution of up to 32 source HDMI devices to up to 32 connected displays directly via HDMI cables or the above optional HDBaseT HDMI standalone HDMI to CATx extenders that send a 1080p signal up to 220 feet or 330 feet depending upon which one you choose (See above OPTIONS). If you don't want to configure your own and see our preconfigured WolfPackLite Matrix Switchers CLICK ON 8x8 or 16x16 or 32x32.

By having 4-port slide in cards the matrix is very reliable as in the unlikely even there is a loss of signal you just replace the card with a spare you have purchased or order another from us. The complete matrix does not have to be sent to us for a repair. HDTV Supplys WolfPackLite matrix switchers can be used at Restaurants, Bowling Alleys, Fitness Centers, Sports Bars, Malls, Places of Worship, Data Centers, Casinos, Conference Rooms, Schools, Home Theaters or any application requiring HDMI switching.

WolfPackLite 32x32 HDMI Matrix Switch Configuration Example #1:

  • 1 - 4-card in and 4-card out card cage
  • 8 - 4-port HDMI input cards = 32 HDMI inputs
  • 8 - 4-port HDMI output cards = 32 HDMI outputs

WolfPackLite 8x28 HDMI Matrix Switch Configuration Example #2:

  • 1 - 32-card in and 32-card out card cage
  • 2 - 4-port HDMI input cards = 8 HDMI inputs
  • 7 - 4-port HDMI output cards = 28 HDMI inputs

What sets the WolfPackLite of Modular HDMI Matrix Switchers apart for our competitors:

  • Can be configured from a 4x4 to a 32x32 matrix system
  • Year 2022 Firmware
  • Plug-n-Play HDMI in and out cards (not hot swappable)
  • Supports all HDTV′s
  • The matrix can be controlled 6-ways:
    1. Front Panel Control
    2. A remote control
    3. RS232 port
    4. Windows Software
    5. Optional Control4 Drivers
    6. Optional Crestron Drivers

WolfPackLite HDMI Matrix Switch Features:

  • Switching of up to 32 HDMI sources to 32 displays depending upon the chassis you choose
  • 16 Presets to save often used configurations
  • HDCP and HDMI backwards compatible
  • LCD front panel for status
  • Supports a bandwidth of up to 10.2 Gbps
  • Built-in HDCP internal management
  • Supports 3D pass-through
  • Supports High Speed HDMI 1.4 Specifications (Deep Color, Lip Sync, and HD lossless audio formats)
  • Supports full HD 1080p (1920x1080p@60Hz at 4:4:4)
  • Supports DDC transmission
  • Supports Dolby Digital-True HD and DTS-HD
  • Control via its remote control, RS-232 and front-panel buttons
  • Full RS-232 control for incorporating third party control systems
  • HDTV Supply, Inc. is an HDBaseT.Org Approved Adopter of HDBaseT™ Products.

The WolfPackLite HDMI Matrix Switch is a top-of-the-line digital matrix switcher made for the demands of today's HDMI (High-Definition Multimedia Interface) routing. Created to route your systems HDMI signals to go to 32 outputs from 32 inputs, this Modular HDMI Matrix Switch delivers high performance.

The WolfPackLite Matrix Router provides full HDCP internal management for today's integration in commercial A/V market, ensuring HDCP key authentication and administering the handshake internally. Our WolfPackLite HDMI Matrix Router comes with a full HDCP (High-bandwidth Digital Content Protection) internal management system that will eradicate any interception of your digital data.

Streaming between the source and display units is easily controlled through our HDMI Matrix interface. HDCP key authentication will no longer be an issue when using our switcher. Control for our unit is varied and easily accessible. Enabled RS-232 commands is provided for advanced user control management. It also has optional Crestron Modules & Control4 Drivers.

Why not create a WolfPackLite HDMI Matrix Switch today?

16x32 HDMI Matrix Switch

This HDMI Matrix Switcher has an option to add a Rack Mount 7-inch Dual Color Display (shown) for you to select & see screens of what is happening in your large matrix system located in other rooms. It requires the dedicated use of 2-1080p HDMI outputs to wire to the 2-HDMI inputs of the dual display. Those 2-Matrix HDMI outputs cannot be used for anything else so count the number of outputs you need and add two (2) more to see if this matrix fulfills your needs.

WolfPackLite HDMI Matrix Switch Specs:

  • I/O card: 4 - HDMI ports/card
  • Input Connector: HDMI A female; T.M.D.S. 2.9V/3.3V, 75 ohms
  • Video Output: HDMI A female; T.M.D.S. 2.9V/3.3V; 75 ohms
  • Gain: 0 dB
  • Resolution: Up to 1080p 4:4:4
  • HDMI Standard: HDCP 1.4 - supports CEC, EDID and DDC and compliant with HDCP
  • Control Options: Buttons, IR remote & RS232 (9-pin female D connector)
  • Worldwide Power Supply: 100VAC ~ 240VAC, 50/60Hz; 50W
  • Temperature: -10 ~ 50 degrees C
  • Working Humidity: 10 ~ 90 degrees
  • Regulation: CE, FCC and CCC

WolfPackLite HDMI Matrix Switch Specs:

  • Gain: 0 dB
  • Bandwidth: 340 MHz (10.2 Gbit/s)
  • Video Signal: HDMI (or DVI-D)
  • Maximum Pixel Clock: 165MHz
  • Resolution Range: Up to 1080p 4:4:4

WolfPackLite HDMI Matrix Router Input:

  • Inputs: Up to 32 HDMI
  • Input Connector: HDMI 1.4 & HDCP 1.4
  • Input Level: T.M.D.S. 2.9V/3.3V
  • Input Impedance: 75 ohms

WolfPackLite HDMI Matrix Switch Output:

  • Outputs: Up to 32 outputs
  • Output Connector: HDMI 1.4 & HDCP 1.4
  • Output Level T.M.D.S. 2.9V/3.3V
  • Output Impedance: 75 ohms

Other WolfPackLite Modular HDMI Matrix Router Specs:

  • Input cable distance: ~25 feet AWG24 HDMI 1.4 high speed cable
  • Output cable distance: ~35 feet AWG24 HDMI 1.4 high speed cable
  • HDCP Management: Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and HDMI 1.4 standards. The built-in HDCP management technology can analyze HDCP key authentication and realize the handshake internally.
  • Serial Control Port: RS-232, 9-pin female D connector with a pin configuration of 2 = TX, 3 = RX, 5 = GND
  • IR Remote: Yes
  • Front Panel Control: Buttons

Why not create a WolfPackLite Modular HDMI Matrix Router today?

Frequently
Reasons To Buy an HDTV Supply WolfPack Product

HDTV Supply has successfully installed our WolfPack, WolfPackLite and our other HDMI Matrix Switchers in Sports Bars, Restaurants, Bowling Alleys, Fitness Centers, Malls, Places of Worship, Data Centers, Gaming Rooms, Nail Salons, County Clubs, Casinos, Factories, Conference Rooms, Schools, Home Theaters or many other installations requiring HDMI matrix switching. The reason, we are told by the users, is the number of features we offer compared to other companies they looked at.

These modular HDMI matrix switchers can usually be integrated with many third party control systems using the RS232 port on the back of the matrix.

For experienced hardware & software professionals who want to write their own drivers for 3rd party control systems from:

  • AMX™
  • Control4™
  • Creston™
  • RTI™
  • DTVGameControl™
  • Elan g!™
  • Media Switcher™
  • OnControls™
  • Savant™
  • SimpleControl™
  • SwitchItUp™
  • SAVI Control™
  • URC Control™

...we have created a simple and very easy to use RS232 script to write your own drivers.

EXAMPLE: If you want to switch input 8 to output 1, 8, 16, the RS232 command would be 8V1.8V8.8V16 . See the RS232 section in this WolfPackLite Modular Matrix Switch User Manual if you want to write your own drivers.

How to use the info:

END USER: If you are an end user and want to have a whole-house control system from any of the above 3rd party control houses but your budget can't support the price you were quoted, do the following:

  1. Call us for a quote
  2. Once you get our quote call a 3rd party control reseller or installer in your area and tell them "Here is the hardware I want to use, please give me a quote on writing the software and installing all of the hardware at my location." You usually can save $1,000s on larger systems.

CAVEAT: We are not certified by any of the above 3rd party control systems companies nor have the necessary hardware to verify, troubleshoot and support the 3rd party writing of the code. We do warranty, though, that the RS232 script in the above RS232 Users Manual has and will work to control the matrix directly.

Q: If I need to add a new 4-port HDMI card in the future, where can I find them to order?

A: See WolfPackLite 4-Port HDMI Input & Output Cards.

Q: Does the matrix support Remote IR (IR Pass-through) from far away rooms?

A: No, but it is operated with an included remote control.

A: 38KHz

Q: Are the HDMI cards on the WolfPackLite chassis all the same and can be interchanged within an 8x8, 16x16 and 32x32 chassis?

A: Yes.

Q: We have a 24/7 operation and want to do our own field repair and maintenance, do you have a field repair kit?

A: Yes, it contains the control board, LAN card, power supply, LCD screen, LCD board and all the components to repair the matrix in the field. It doesn't include the metal chassis, nor HDMI cards as you can buy the cards at our site. Call us at 800-841-9238 for details.

Q: Do you have HDBaseT cards and receivers for the matrix?

A: No, we only have 1080p HDMI input and 1080p HDMI output cards. See the above optional standalone POE 1080p HDBaseT extenders which have a Transmitter and a Receiver and one AC adapter. If you need that kind of a matrix see our WolfPack Modular HDMI Matrix Routers w/iPad & Android App.

Q: Do you have a WEB GUI or iOS App for the matrix?

A: No, you use the Front Buttons, Remote control & RS232 to the Control Ins & Outs. If you need that kind of a matrix see our WolfPack Modular HDMI Matrix Routers w/iPad & Android App.

Q: I see a LAN port on the matrix, can that be used?

A: No. The LAN port is in a beta stage and does not work. Do not buy the matrix if you want to operate it on your LAN. Use the Front Buttons, Remote control & RS232 to the Control Ins & Outs. If you need that kind of a matrix see our WolfPack Modular HDMI Matrix Routers with LAN control.

HDTV Supply's WolfPack Family of Matrix Switchers can be created however you wish. Just SCROLL DOWN and fill out the below and press SUBMIT and we will send you a quotation based upon your needs within an hour.

If it doesn't meet your needs just call us right now at 833-WOLFPACK or 833-965-3722 or email us at support@hdtvsupply.com



Why not buy this WolfPackLite Modular HDMI Matrix Switchers today?
