The Kramer FV11H-M isolates a single HDMI video path between a computer and display. It supports 4K30 video; keyboard and mouse connections are not provided on this model.
FV11H-M Detailed Features
- Place an isolation boundary at the workstation. The unit sits between a computer and supported peripherals. It is intended for installations where directly connecting a display or console peripherals would not provide the required separation.
- Isolate an HDMI video connection. The video isolator supports an HDMI source-to-display path. This model does not provide keyboard or mouse connections, so it is suited to display isolation rather than a full KVM console.
- Support the specified Ultra HD format. The model-specific video limit is 4K30. Configure compatible source and display equipment within that limit rather than assuming the capability of another isolator variant.
- Capture monitor identification deliberately. EDID is captured when the installer uses the designated control. This avoids a continuously open display-identification path between the display and source.
- Restrict the display information passed to the computer. The isolator parses EDID and limits it to the essential information needed for operation. This is part of its approach to reducing unwanted communication through the display connection.
- Use the prescribed initialization procedure. The manufacturer provides an EDID capture and restart sequence. Follow it when setting up or changing a display so the source receives the intended monitor information.
- Plan mounting and power for the chosen model. Compatible HSL mounting and power-distribution accessories can support a grouped installation. Confirm the exact accessory and device combination rather than assuming every isolator uses the same arrangement.
Specifications
| Manufacturer part number | 22-00013690 |
|---|---|
| CONSOLE PORTS — Displays | 1 x HDMI 1.4 |
| CONSOLE PORTS — Max Resolution (Input & Output) | 3840x2160 @ 30 Hz |
| CONSOLE PORTS — Mouse and Keyboard | N/A |
| COMPUTER PORTS — Display Type | 1 x HDMI 1.4 |
| COMPUTER PORTS — Mouse and Keyboard | N/A |
| PHYSICAL — Dimensions | 145 x 105 x 28 mm / 5.8 x 4.2 x 1.1 inches |
| PHYSICAL — Weight | 0.3 kg (0.64 lbs) |
| POWER — Power Requirements | DC input 12V/1.5A Maximum |
| POWER — AC Input | Wall-mounted power supply included. Power input 90 to 240V AC |
| POWER — Power Type | External Power Supply |
| ENVIRONMENTAL — Operating Temperature | 32° to 104° F (0° to 40° C) |
| ENVIRONMENTAL — Storage Temperature | -4° to 140° F (-20° to 60° C) |
| ENVIRONMENTAL — Humidity | 20 to 80% non condensing; Storage–10 to 90% non condensing |
| SOFTWARE — Supported OS | Windows, Linux, Mac |
| GENERAL INFO — Manufactured | BAA & TAA Compliant |
| GENERAL INFO — Product life-cycle | 10 years |
Technical Questions and Answers
What does the FV11H-M do?
The Kramer FV11H-M isolates a single HDMI video path between a computer and display. It supports 4K30 video; keyboard and mouse connections are not provided on this model.
What does the console displays connection support?
1 x HDMI 1.4
What video resolution does it support?
3840x2160 @ 30 Hz
What is provided for computer-side display type?
1 x HDMI 1.4
What is specified for dimensions?
145 x 105 x 28 mm / 5.8 x 4.2 x 1.1 inches
What are the power requirements requirements?
DC input 12V/1.5A Maximum
What are the ac input requirements?
Wall-mounted power supply included. Power input 90 to 240V AC
What are the power type requirements?
External Power Supply
Choosing the Right Product
What is the Kramer FV11H-M used for?
It is used for a single HDMI display connection requiring video isolation. Isolates a single HDMI video path between a computer and display. It supports 4K30 video; keyboard and mouse connections are not provided on this model.
Who should choose the FV11H-M?
Choose this model when your project needs a single HDMI display connection requiring video isolation. Compare the model-specific connections and specifications above with the equipment in your system.
What should I check before ordering the FV11H-M?
Confirm manufacturer part 22-00013690, the required connections and the installation requirements. Use the linked documentation to check compatible equipment and required accessories.
