Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet

Atlona

Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet
$530.00
Part Number:
AT-UHD-EX-100CE-TX
UPC:
846352004422
Condition:
New
Availability:
In Stock
1:
4K/UHD Capability @ 60 Hz
2:
4:2:0 Chroma Subsampling
3:
Supports 4K HDR10 @ 24 Hz
4:
Multi-Channel Audio Compliant
5:
HDCP 2.2 Compliant
6:
Free USA Shipping
7:
3-Year Atlona Warranty

This Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet is an HDBaseT transmitter for HDMI transmission up to 330 feet (100 meters) over category cable with Ethernet, RS-232, and IR control pass-through. Designed to work with HDBaseT inputs on switchers and projectors, this extender transmits video signals up to 4K/UHD @ 60Hz with embedded multi-channel audio. Additionally, the transmitter extends Ethernet, RS-232, and 12 volt-based IR control commands. The AT-UHD-EX-100CE-TX is HDCP 2.2 compliant and supports EDID communication. The transmitter features a quarter rack width metal enclosure for easy rack mounting with rear panel I/O ports for uncluttered wire management. This PSE (Power Sourcing Equipment) device is externally powered, includes a desktop power supply and provides Power over Ethernet for compatible receiving devices. The AT-UHD-EX-100CE-TX is certified by the HDBaseT Alliance.

This HDBaseT Class A transmitter is designed to support the growing number of displays and video projectors in the commercial market with HDBaseT inputs. Built-in Ethernet and bi-directional control signal extension eliminates the need for additional cabling from switcher to the display or remote input device. Installer-friendly features include: a rack-mountable form factor that allows four transmitters to share a single, 1U rack tray; power chaining to allow multiple sets to be powered from one power supply; and a front mounted USB port for easy firmware updates.

Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet Feature:

  • 4K/UHD capability
    • Compatible with Ultra High Definition sources and displays
    • Full support of 4K/UHD streaming services and playback devices
  • HDCP 2.2 compliant
    • Adheres to latest specification for High-bandwidth Digital Content Protection
    • Allows protected content stream to pass between devices
  • Supports 4K HDR10 @ 24 Hz
    • Extends 4K HDR10 @ 24 Hz (4:2:0 chroma subsampling, 10-bit color)
  • PSE – Power Sourcing Equipment
    • Uses external power supply (included)
    • Eliminates the need for remote power or power-injection devices
  • AV, Ethernet, power, and control over HDBaseT
    • Delivers 4K/UHD video, audio, 100Base-T Ethernet, power, and control through a single cable
    • Eliminates multiple cable runs between source, control system, router, and display
  • Extended distance HDMI extension
    • Transmits HDMI signals up to 330 ft (100m) @ 1080P and 328 ft (100m) @ 4K/UHD using CAT6a/7 cable
    • Uses easy to integrate category cable for low-cost, reliable system installation
  • Rear panel I/O connectors
    • Placement of ports on rear panel simplifies wire management
    • Saves installation time and eliminates clutter
  • Multi-channel audio compliant
    • Supports PCM, Dolby Digital, Dolby Digital Plus™, Dolby TrueHD, Dolby Atmos®, DTS Digital Surround™, DTS-HD Master Audio™, DTS:X™
    • Allows any multi-channel audio stream to be used within a professional audio system
  • Field updatable firmware
    • Front panel USB port provides an easy means for kit upgrades
    • Ensures long term system return on investment
  • Front panel Power and Link status LEDs
    • LED indicators provide power and HDBaseT link status information
    • Provides easy setup and troubleshooting
  • Power chaining
    • Included power supply provides ample power for up to three Atlona HDBaseT extenders
    • Four Atlona HDBaseT extenders can be powered using the optional AT-PS-483125-C power supply
    • Reduces clutter from multiple power supplies in equipment racks
  • Low-profile, 1 inch (2.5cm) high quarter rack-width enclosure
    • Easy installation into racks and confined spaces behind displays
    • Keeps devices out-of-sight when placed in public spaces
  • Included accessories
    • User guide, desktop power supply for transmitter, detachable power cable, IR emitter P/N AT-IR-CS-TX, mounting brackets

Why not buy this Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet from HDTV Supply today?

Atlona AT-UHD-EX-100CE-TX 4K/UHD HDMI Over 100 M HDBaseT Transmitter With Ethernet Specifications:

  • Resolution
    • Video 4096×2160@24/25/30/50*/60Hz*, 3840×2160@24/25/30/50*/60Hz*, 2048x1080p, 1080p@23.98/24/25/29.97/30/50/59.94/60Hz, 1080i@50/59.94/60Hz, 720p@50/59.94/60Hz, 576p, 576i, 480p, 480i
    • VESA 2560×2048, 2560×1600, 2048×1536, 1920×1200, 1680×1050, 1600×1200, 1600×900, 1440×900, 1400×1050, 1366×768, 1360×768, 1280×1024, 1280×800 1280×768, 1152×768, 1024×768, 800×600, 640×480
    • Colorspace YCbCr, RGB
    • Chroma Subsampling 4:4:4, 4:2:2, 4:2:0
    • Color Depth 8-bit, 10-bit, 12-bit
    • HDR 4K HDR10 @ 24Hz, 4:2:0 chroma subsampling, 10-bit color
    • (Source signal delivered from Ultra HD Blu-ray as 4K @ 24Hz 4:2:2. Not compatible with HDR10 @ 60Hz.)
  • Audio
    • Formats PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
    • Sample Rate 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
    • Bit Rate up to 24-bit
  • Distance
    • CAT5e/6 @ 4K – up to 70 meters / up to 230 feet
    • CAT6a/7 @ 4K – up to 100 meters / up to 328 feet
    • CAT5e/6 @ 1080p – up to 100 meters / up to 328 feet
    • HDMI IN/OUT @ 4K – up to 5 meters / up to 15 feet
    • HDMI IN/OUT @ 1080p – up to 10 meters / up to 30 feet
  • Signal
    • Bandwidth 10.2 Gbps
    • CEC Pass through
    • HDCP Supports up to 2.2
  • Connector
    • Firmware Mini-B USB
    • HDBaseT RJ45 (8P8C)
    • HDMI Type A
    • LAN RJ45 (8P8C), Ethernet pass through
    • TX-IR 4-pin captive screw
    • RS-232 3-pin captive screw
    • Power 2-pin, 48V captive screw
  • Temperature
    • Operating 0°C to 50°C / 32°F to 122°F
    • Storage -20°C to 60°C / -4°F to 140°F
    • Humidity 20 to 90% non-condensing
  • Power
    • Consumption 12W (when paired with RX)
    • Supply
      • Input: AC100~240V 50/60Hz
      • Output: DC 48V/0.83A
  • Dimensions
    • Unit 0.98 x 4.29 x 3.50 Inches / 25 x 109 x 89 Millimeters
    • Unit w/feet/ears 1.06 x 4.69 x 3.50 Inches / 27 x 119 x 89 Millimeters
    • Power Supply 1.42 x 1.81 x 4.41 Inches / 36 x 46 x 112 Millimeters
  • Weight
    • Unit 0.39kg / 0.86lbs
  • Certification
    • Power Supply CE, FCC, RoHS, cULus, RCM, CCC
    • Product CE, FCC
