This Zenty ZT-497 4K 60Hz 4:4:4 HDBaseT HDMI Extender over Cat5e/6 (394ft | 492ft) - TAA-compliant is a professional UHD 4K@60Hz 4:4:4 HDR HDMI over Ethernet extender solution. Users can transmit a 4K@60Hz signal up to 120M/394Ft. and a 1080P@60Hz signal up to 150M/492Ft. over a single Cat5e/Cat6 Ethernet cable. The ZT-EX1504K transmitter features a local HDMI output port for splitting your source signal locally and extending an output to a remote display. Utilize the built-in PoC (Power over Cable) function and power both your transmitter and receiver from only one power adapter.
Installation is simple, quick, and easy. The ZT-EX1504K will pass your display's EDID information to your connected source device so that any signal compatibility issues will be resolved before they even begin. Flexible and appropriate for any application, the ZT-EX1504K supports the latest audio and video standard including HDR, HDR10, Dolby Vision, Dolby Digital+, DTS-HD Master & Dolby TrueHD.
Zenty ZT-497 4K 60Hz 4:4:4 HDBaseT HDMI Extender over Cat5e/6 (394ft | 492ft) - TAA-compliant Features:
- HDMI 2.0 | HDCP 2.2, DVI 1.0 compliant
- Transmit 4K 60Hz up to 394ft. over single CAT6/7 cable
- Transmit 1080P 60Hz up to 492ft. over single CAT6/7 cable
- 18Gbps video bandwidth
- HDMI loop-out on the transmitter
- Sends de-embedded audio signal to analog stereo output on receiver
- Bi-directional IR, RS232, and CEC pass-through
- HDR | HDR10 | Dolby Vision | HLG functions supported
Why not buy this Zenty ZT-497 4K 60Hz 4:4:4 HDBaseT HDMI Extender over Cat5e/6 (394ft | 492ft) - TAA-compliant from HDTV Supply today?
Zenty ZT-497 4K 60Hz 4:4:4 HDBaseT HDMI Extender over Cat5e/6 (394ft | 492ft) - TAA-compliant Specification:
- Technical
- HDCP Compliance 1.4 | 2.2
- Distance
- 1080P 60Hz: 120m / 492ft.
- 4K 60Hz: 120m / 394ft.
- Video Bandwidth 18Gbps
- Video Resolution Up to 4K 60Hz 4:4:4
- Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
- Color Depth
- 8/10/12-bit (1080P 60Hz, 4K 30Hz, 4K 60Hz YCbCr 4:2:2/4:2:0)
- 8-bit (4K 60Hz 4:4:4)
- HDMI Audio Formats
- LPCM 2.0/2.1/5.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital+, DTS-ES, DTS HD
- Master. DTS HD-HRA, DTS-X
- L/R Audio Formats PCM 2.0
- ESD Protection
- Human body model - +-8kV (air-gap discharge)
- & +- 4kV (Contact discharge)
- Connections
- Transmitter
- Input
- 1 x HDMI Type A [19-pin female]
- Outputs
- 1 x HDMI Type A [19-pin female]
- 1 x HDBT Out [RJ45]
- Control
- 1 x IR In [3.5mm Stereo Mini-jack]
- 1 x IR Out [3.5mm Stereo Mini-jack]
- 1 x RS232 [Phoenix jack]
- 1 x Service [Mini-USB, Update port]
- Input
- Receiver
- Input
- 1 x HDBT In [RJ45]
- Outputs
- 1 x HDMI Type A [19-pin female]
- 1 x Audio Out [3.5mm Stereo Mini-jack]
- Control
- 1 x IR In [3.5mm Stereo Mini-jack]
- 1 x IR Out [3.5mm Stereo Mini-jack]
- 1 x RS232 [Phoenix jack]
- 1 x Service [Mini-USB, Update port]
- Input
- Transmitter
- Mechanical
- Housing Metal Enclosure
- Color Black
- Dimensions 140mm [W] x 65mm [D] x 18mm [H]
- Weight
- Transmitter: 160g
- Receiver: 155g
- Power Supply
- Input: AC 100 – 240V 50/60Hz
- Output: DC 24V/1A (Locking connector)
- Power Consumption 9.36W
- Operating Temperature
- 32°F ~ 104°F | 0°C ~ 40°C
- Storage Temperature
- -4°F ~ 140°F | -20°C ~ 60°C
- Relative Humidity
- 20 – 90% RH (No condensation)
