This ZeeVee Z4KMEDDECC3 ZyPer4K Medical HDMI 2.0 Copper Decoder accepts IP streaming via 10Gbit/copper. Supports analog audio, IR, RS−232. No USB. Includes power supply.
Requires ZyPer4K AVoIP Encoder. Cables not included.
ZeeVee Z4KMEDDECC3 ZyPer4K Medical HDMI 2.0 Copper Decoder Features:
- Uncompressed 4K
- Multiview
- Video Wall
- HDMI 2.0
- HDCP 2.2
- AES Encryption
Why not buy this ZeeVee Z4KMEDDECC3 ZyPer4K Medical HDMI 2.0 Copper Decoder from HDTV Supply today?
ZeeVee Z4KMEDDECC3 ZyPer4K Medical HDMI 2.0 Copper Decoder Specifications:
- Video: HDMI 2.0 with HDCP pass-through. Widescreen format selection (Crop, stretch or box): HDMI 2.0 type A with optional DisplayPort
- Audio (Digital): Multi-channel linear PCM up to 8 channels (7:1): HDMI 2.0 type A
- Audio (Analog): Unbalanced Stereo (Output): 3.5mm stereo mini jack
- IR: Input/Output ports: 3.5mm mini jacks
- RS-232: Full Duplex up to 115.2 kbps: 9–pin D–sub
- USB (Optional): USB 2.0: 2 USB Type A
- Ethernet: 10 Gb for Video/Audio/Control with 1 Gb Utility: 10 Gb RJ45 or SFP+ port 1 Gb RJ45 port
- Formats:
- VGA: 640x480 (4:3)
- SXGA: 1280x1024 (5:4)
- 1080p/i: 1920x1080 (16:9)
- SVGA: 800x600 (4:3)
- WXGA: 1366x768 (16:9)
- QXGA: 2048x1536 (4:3)
- XGA: 1024x768 (4:3)
- SXGA+: 1440x1080 (4:3)
- Ultra HD: 3840x2160 (16:9)
- HDTV: 1280x720 (16:9)
- UXGA: 1600x1200 (4:3)
- 4K: 4096x2160 (17:9)
- Custom resolutions are supported at pixel clock rates up to 600 MHz
- Video Other: Color depth: 24 bit, 30 bit, 36 bit, 48 bit
- Video Wall and Multiview:
- Video Wall up to 15x15
- Multiview up to 19 sources
- Signal Transmission Distance: Cat6a: 328 ft (100 m) or 30km fiber optic line
- Copy Protection/Security:
- HDCP 2.2
- AES–128 Encryption
- 802.1X compatible
- Power Input (locking connector): 12 VDC 2A (Worldwide AC adapter is supplied)
- Power (Standard encoder/decoder): Approximately 15 watts
- Dimensions (L x W x H) / Weight: 6.9 in (176mm) x 5.7 in (145mm) x 1.5 in (37mm), 31.0 oz (880 g)
- Dimensions, Long box version: 9 in (229mm) x 5.7 in (145mm) x 1.5 in (37mm), 37.7 oz (1070 g)
- Temperature:
- Operating temperature: 32° F to 104° F (0° C to +40° C)
- Storage temperature: –4° F to +176° F (–20° C to +80° C)
- Humidity: Operating/Storage: 20% to 90% (Non–Condensing)
