This ZeeVee Z4KDECF3 ZyPer4K HDMI 2.0 Fiber Decoder is an HDMI 2.0 Decoder that is part of the ZyPer4K product line.
It accepts IP streaming over 10Gbit/fiber up to 4K60 4:4:4 resolution with embedded audio and HDCP 2.2 encryption at zero−frame latency.
This Decoder supports analog audio as well as IR and rs232. The Z4KDECF3 requires a ZyPer4K Encoder for operation.
The power supply is included but other cables are not.
ZeeVee Z4KDECF3 ZyPer4K HDMI 2.0 Fiber Decoder Features:
- AV over IP
- 10 Gbps
- Uncompressed 4K
- SDVOE
- Decoder
Why not buy this ZeeVee Z4KDECF3 ZyPer4K HDMI 2.0 Fiber Decoder from HDTV Supply today?
ZeeVee Z4KDECF3 ZyPer4K HDMI 2.0 Fiber Decoder Specifications:
- Video: HDMI 2.0 with HDCP pass-through: HDMI 2.0 type A
- Audio (Digital): Encoded audio formats and LPCM up to 8 channels: HDMI 2.0 type A
- Audio (Analog): Unbalanced 2-Channel Stereo (In or Out): 3.5mm stereo mini jack
- IR: Input/Output ports: 3.5mm mini jacks
- RS-232: Full Duplex up to 115.2 kbps: 9–pin D–sub
- Ethernet: 10 Gb for Video/Audio/Control with 1 Gb Utility: 10 Gb SFP+ port and 1 Gb RJ45 port
- Formats:
- Supports all major VESA resolutions and variations including full HDMI 2.0 support
- VGA: 640x480 (4:3)
- SXGA: 1280x1024 (5:4)
- 1080p/i: 1920x1080 (16:9)
- SVGA: 800x600 (4:3)
- WXGA: 1366x768 (16:9)
- QXGA: 2048x1536 (4:3)
- XGA: 1024x768 (4:3)
- SXGA+: 1440x1080 (4:3)
- Ultra HD: 3840x2160 (16:9)
- HDTV: 1280x720 (16:9)
- UXGA: 1600x1200 (4:3)
- 4K: 4096x2160 (17:9)
- Video Other: Color depth: 24 bit, 30 bit, 36 bit, 48 bit
- Video Wall and Multiview:
- Video Wall up to 15x15
- Multiview with up to 19 sources
- Signal Transmission Distance: Cat6a: 100m | multimode fiber optic line: 300m
- Copy Protection/Security:
- HDCP 2.2
- AES–128 Encryption
- Power Input (locking connector): 12V, 2A
- Power: Approximately 15 watts
- Dimensions (L x W x H) / Weight:
- 5.7 in (144mm) x 2.5 in (175mm) x 1.7 in (43mm)
- Weight: 31 oz (880 g)
- Temperature:
- Operating temperature: 32°F to 104°F (0°C to +40°C)
- Storage temperature: –4°F to +176°F (–20°C to +80°C)
- Humidity: Operating/Storage: 20% to 90% (Non–Condensing)
- Warranty: 3 years
