The QSC KS112 2000W 12-Inch Compact Powered Subwoofer is a compact active subwoofer designed for live performances, mobile entertainment, houses of worship, presentation spaces, and professional AV applications.
Featuring a 12-inch long-excursion driver and a Class-D amplifier, the KS112 delivers powerful low-frequency reinforcement in a space-efficient enclosure. It is designed to work with full-range loudspeakers and can complement QSC K.2 Series powered speakers.
Onboard DSP provides adjustable crossover settings, user-saveable scenes, Intrinsic Correction tuning, and loudspeaker management functions. The rear panel features two combo XLR-1/4-inch inputs and two XLR thru outputs for connecting compatible audio equipment.
The KS112 can be deployed vertically or horizontally and features M20 threaded pole fittings for compatible speaker-pole setups. Its rugged painted plywood enclosure is designed for professional use, and a locking IEC power cord is included.
QSC KS112 Features
- High-output performance in an ultracompact enclosure
- 2000W peak Class-D amplifier module, as specified in the supplied product information
- 12-inch long-excursion low-frequency driver
- Sixth-order bandpass enclosure design
- Variable crossover settings
- Save-and-recall scenes for commonly used applications
- Intrinsic Correction tuning and loudspeaker management
- Two combo XLR-1/4-inch TRS inputs
- Two XLR thru outputs
- Vertical or horizontal deployment options
- M20 threaded pole fittings for compatible speaker-pole configurations
- Rugged painted plywood enclosure
- Optional KS-LOC security cover available separately
- EASE and CAD information available from the manufacturer

QSC Certified Expertise with Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Why Buy the QSC KS112 from HDTV Supply?
HDTV Supply offers professional AV equipment for sound reinforcement, live events, and installation projects. Contact our team for assistance selecting a subwoofer for your application.
Ask a Question (0)
Need help with compatibility, speaker placement, crossover settings, or choosing a subwoofer for your sound system? Contact HDTV Supply for assistance.
QSC KS112 Specifications
| Specification | Details |
|---|---|
| Brand | QSC |
| Model | KS112 |
| Speaker Type | Active subwoofer |
| Enclosure Type | Sixth-order bandpass |
| Amplifier Power | 2000W peak, Class-D |
| Low-Frequency Driver | One 12-inch / 30.5 cm woofer |
| Frequency Range (-10 dB) | 38 Hz–121 Hz |
| Frequency Range (-6 dB) | 41 Hz–108 Hz |
| Maximum SPL | 128 dB peak |
| Signal Processing | Adjustable alignment delay up to 100 ms, as supplied |
| Audio Inputs | Two combo XLR-1/4-inch TRS inputs |
| Audio Outputs | Two 3-pin XLR thru outputs |
| Network I/O | None listed |
| USB I/O | None listed |
| Wireless Connectivity | None listed |
| Mobile App Compatibility | None listed |
| AC Input | 100–240 VAC, 50/60 Hz |
| Power Connection | One locking IEC input |
| Current Consumption | 100 VAC: 2.4 A; 120 VAC: 2 A; 240 VAC: 1.3 A |
| Color | Black |
| Construction Material | Plywood |
| Environmental Resistance | Not specified as weather-resistant |
| Dimensions | 24.5 x 15.5 x 24.3 inches / 622.3 x 393.7 x 616 mm |
| Product Weight | 62.6 lb / 28.4 kg |
| Box Dimensions (L x W x H) | 29.2 x 27.2 x 20.1 inches |
QSC KS112 Manuals and Documentation
Documentation: Refer to the QSC KS112 User Manual for installation, operation, DSP configuration, and technical information.
Frequently Asked Questions
Q1: What is the QSC KS112?
A: The QSC KS112 is a compact active subwoofer featuring a 12-inch driver and integrated amplification for professional low-frequency sound reinforcement.
Q2: How much power does the KS112 provide?
A: The supplied specifications list a 2000W peak Class-D amplifier. Peak power should not be interpreted as continuous output power.
Q3: What size driver does the KS112 use?
A: The KS112 uses one 12-inch (30.5 cm) low-frequency driver.
Q4: What is the frequency response of the KS112?
A: The supplied specifications list 38 Hz–121 Hz at -10 dB and 41 Hz–108 Hz at -6 dB.
Q5: What is the maximum SPL of the KS112?
A: The supplied specifications list a peak maximum SPL of 128 dB.
Q6: Can the KS112 be used with full-range speakers?
A: Yes. It is designed to complement compatible full-range loudspeakers and provide additional low-frequency reinforcement.
Q7: Does the KS112 have built-in DSP?
A: Yes. Its listed processing features include adjustable crossover settings, scene storage and recall, Intrinsic Correction tuning, and loudspeaker management.
Q8: What audio connections does the KS112 offer?
A: The supplied specifications list two combo XLR-1/4-inch TRS inputs and two 3-pin XLR thru outputs.
Q9: Can the KS112 be positioned horizontally or vertically?
A: Yes. The supplied product information lists both vertical and horizontal deployment options. Follow the manufacturer's instructions for safe positioning.
Q10: Does the KS112 include a power cord?
A: Yes. The supplied description states that a locking IEC power cord is included.
Q11: What applications is the QSC KS112 suitable for?
A: It may be suitable for houses of worship, small performance venues, presentations, mobile entertainment, and AV applications that need compact low-frequency reinforcement.
Q12: Can the KS112 be used with QSC K.2 Series speakers?
A: The supplied description identifies QSC K.2 Series powered speakers as a suitable pairing. Choose crossover and level settings appropriate to your system.
Q13: Does the KS112 support stereo operation?
A: The supplied description indicates that two units are needed for independent left- and right-channel subwoofer operation. Confirm the recommended signal routing in the KS112 manual.
Q14: Is the QSC KS112 weatherproof?
A: The supplied specifications do not identify the KS112 as weatherproof. Protect it from moisture and follow QSC's environmental operating guidance.
Q15: What should I consider before buying the QSC KS112?
A: Consider your venue size, required bass output, compatibility with your full-range speakers, placement, power supply, and transport requirements. Contact HDTV Supply if you need help selecting equipment.
QSC KS112 Warranty Information
The QSC KS112 is a QSC KS Series speaker product. QSC KS Series speakers are covered for 3 years, with an additional 3 years available with product registration, for up to 6 years of coverage.
Warranty coverage is subject to QSC's current warranty policy, product eligibility, purchase region, and registration requirements. For warranty questions, contact HDTV Supply Customer Service.
