The QSC AD-S112-sw-BK AcousticDesign Series 12-Inch 300W Surface-Mount Subwoofer (Black) is a passive, 8-ohm subwoofer designed to deliver powerful low-frequency reinforcement for foreground and background music systems. Supplied with a yoke mounting system, it complements QSC AcousticDesign full-range loudspeakers in commercial audio installations.
Featuring a weather-treated 12-inch paper-cone woofer with a 2.5-inch voice coil, the AD-S112-sw-BK provides 300W RMS power handling, a frequency range of 30 Hz to 135 Hz (-10 dB), and a peak maximum SPL of 121 dB.
Its Turbulent Flow Reduction (TFR) port optimizes enclosure resonance and airflow to help achieve higher output levels before port turbulence becomes audible.
A removable four-pole Euroblock connector with loop-through wiring is located beneath a sealed input cover to help protect the terminals from moisture.
The rugged ABS enclosure and powder-coated aluminum grille provide dust and splash resistance exceeding IP54 ratings, making this subwoofer suitable for supported indoor and outdoor applications.
QSC AD-S112-sw-BK AcousticDesign Subwoofer Features
- Designed for foreground and background music reinforcement in restaurants, retail spaces, educational facilities, houses of worship, transportation terminals, and other commercial environments
- Includes a yoke mounting assembly to support installation and help reduce vibration transmission
- M10 fittings support compatible suspended installations using the separately available M10 Kit-C
- Direct-radiating 12-inch weather-treated paper-cone woofer with a 2.5-inch voice coil
- TFR port design optimizes airflow and enclosure resonance to help reduce port turbulence at high output levels
- Rugged ABS enclosure with a powder-coated aluminum grille
- Dust and splash resistance exceeding IP54 ratings
- Four-pole Euroblock input with loop-through wiring under a sealed input cover
- QSC Intrinsic Correction voicing filters are available through compatible Q-SYS processing or CXD amplifier platforms, sold separately
QSC Certified Expertise
Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Why Buy the QSC AD-S112-sw-BK from HDTV Supply?
Shop HDTV Supply for QSC AcousticDesign loudspeakers and accessories. Our team can help you select audio equipment for your commercial sound system.
Ask a Question About the QSC AD-S112-sw-BK
Need help with amplifier matching, mounting options, or speaker compatibility? Contact HDTV Supply for assistance with the QSC AD-S112-sw-BK subwoofer.
QSC AD-S112-sw-BK AcousticDesign Subwoofer Specifications
| Speaker | |
|---|---|
| Active / Passive | Passive |
| Number of Included Speakers | 1 |
| Speaker Configuration | Subwoofer |
| Power Handling | 300W RMS (2 hours, low impedance) |
| Recommended Amplifier Power | 600W |
| Impedance | 8 ohms |
| Enclosure Type | Bass-reflex |
| Drivers | |
| LF Driver | 1 × 12-inch / 30.48 cm paper woofer |
| LF Voice Coil | 2.5-inch / 6.35 cm |
| Performance | |
| Frequency Range | 30 Hz to 135 Hz (-10 dB) |
| Maximum SPL (Continuous) | 115 dB |
| Maximum SPL (Peak) | 121 dB |
| Sensitivity | 90 dB SPL |
| Connectivity | |
| Inputs / Outputs | 1 × removable four-pole block speaker input / loop-through |
| Physical and Environmental | |
| Environmental Resistance | Dust, humidity, and water resistance (IP54 rating as listed) |
| Operating Temperature | -4°F to 122°F / -20°C to 50°C |
| Color | Black |
| Mounting Points | 1 top bracket point; 1 bottom bracket point; 2 bottom M10 suspension points |
| Construction Materials | ABS, aluminum grille, polymer |
| Dimensions | 23.4 × 13.9 × 12.7 in / 59.44 × 35.31 × 32.26 cm |
| Weight | 29 lb / 13.2 kg |
| Packaging Information | |
| Package Weight | 43.4 lb |
| Box Dimensions (L × W × H) | 27 × 21.5 × 19 in |
QSC AD-S112-sw-BK User Manual
Q/A
Q1: What is the QSC AD-S112-sw-BK?
It is a passive, 12-inch surface-mount subwoofer from QSC's AcousticDesign series, designed to provide low-frequency reinforcement for commercial audio systems.
Q2: How much power can the AD-S112-sw-BK handle?
The supplied specifications list 300W RMS power handling for two hours at low impedance.
Q3: What is the impedance of this subwoofer?
The AD-S112-sw-BK has an 8-ohm impedance.
Q4: What size woofer does it use?
It features one 12-inch weather-treated paper-cone woofer with a 2.5-inch voice coil.
Q5: What is its frequency range?
The listed frequency range is 30 Hz to 135 Hz at -10 dB.
Q6: What is the maximum sound pressure level?
The supplied specifications list 115 dB continuous maximum SPL and 121 dB peak maximum SPL.
Q7: Is the AD-S112-sw-BK weather-resistant?
It is designed for dust and splash resistance, with IP54 listed in the supplied specifications. Follow QSC guidance for suitable installation environments and exposure limits.
Q8: What mounting hardware is included?
The supplied product description states that a yoke mounting assembly is included.
Q9: Can the subwoofer be suspended?
The listed specifications include two bottom M10 suspension points. Suspended installation must use manufacturer-approved hardware and procedures, and may require the separately available M10 Kit-C.
Q10: What connector does the subwoofer use?
It uses a removable four-pole Euroblock speaker input with loop-through wiring, located under a sealed input cover.
Q11: What applications suit the QSC AD-S112-sw-BK?
It is intended for low-frequency reinforcement in commercial environments such as restaurants, retail stores, educational facilities, worship spaces, concourses, casinos, and transportation terminals.
Q12: Can it be paired with QSC AcousticDesign full-range speakers?
Yes. The product description identifies it as a suitable companion to QSC AcousticDesign full-range loudspeakers. Confirm system design and amplifier compatibility for your specific installation.
Q13: What amplifier power is recommended?
The supplied specifications list 600W as the recommended amplifier power. Confirm amplifier settings and operating limits using the manufacturer's guidance.
Q14: Does the AD-S112-sw-BK have built-in amplification?
No. It is listed as a passive subwoofer and requires a compatible external amplifier.
Q15: Where can I get help choosing or installing this subwoofer?
Contact HDTV Supply for assistance reviewing compatibility, amplifier requirements, and mounting options for your QSC AcousticDesign audio system.
Warranty Information
Please contact HDTV Supply or QSC to confirm the applicable warranty coverage for the AD-S112-sw-BK and the terms associated with your purchase.
