Osprey RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19

Osprey Video

Osprey RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19
$1,390.00

5% Discount. Apply Code 5percentOff at Checkout!

Part Number:
97-50004
UPC:
603134693690
Availability:
Usually ships the same business day
1:
15.6 Display 3840 x 2160"
2:
16:9 Aspect Ratio
3:
330cd/m², 1000:1 Contrast Ratio
4:
SDI, HDMI, VGA & DVI Inputs
5:
Free Shipping & 2-Year Osprey Warranty
Make a Fair Offer
Ask an Expert

This Osprey 97-50004 RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19 is a 4K monitor featuring a 3840 x 2160 native resolution, a 16:9 aspect ratio, a maximum brightness of 330cd/m?, with 1000:1 contrast ratio, and a 176? viewing angle. It supports 3G-SDI, HDMI 2.0, DVI, and VGA video inputs. The four HDMI inputs are comprised of one HDMI 2.0 input supporting 4K resolution at 60 fps plus three HDMI 1.4 inputs supporting 4K resolution at 30 fps. As an additional feature, it also supports unbalanced stereo audio input via RCA connectors.

Osprey 97-50004 RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19 Features:

  • 15.6" 4K UHD (3840 x 2160) resolution
  • One 3G-SDI input with a loop output, three HDMI 1.4 plus one HDMI 2.0 inputs, one DVI, and one VGA
  • Support for dual/quad view and PiP mode. All inputs can be used for different layout options ranging from side-by-side dual view, PiP, and quad view
  • SMPTE SDI compliance: 259M, 292M, 296M, 372M, 424M
  • Supports 525i59.94 NTSC and 625i50 PAL standards
  • 3.5mm audio headphone jack and RCA connections for unbalanced stereo audio input
  • Video input selection, display adjustments, tally indicator lights, center and safety markers, aspect ratio, system settings, H/V delay, check field, underscan, signal loss color bars, zoom, image flip, PiP, and multiview

Why not buy this Osprey 97-50004 RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19 today?

Osprey 97-50004 RM3G-4K 15.6" 4K Monitor 3G SDI, HDMI 2.0, DVI, VGA 19 Specifications:

  • Display
    • Panel Type: IPS-Type LCD
    • Display Size: 15.6" / 39.6 cm
    • Resolution: 3840 x 2160
    • Aspect Ratio: 16:9
    • Viewing Angle: 176°
    • Touchscreen: No
    • Maximum Brightness: 330 cd/m2
    • Contrast Ratio: 1000:1
    • Dot Pitch: 0.09 x 0.09 mm
    • Pixels Per Inch (ppi): 282 ppi
    • Image Controls: Check Field, Customizable Aspect Ratios, H/V Delay, Image Flip, Picture-in-Picture, Pixel Zoom, Screen Markers, Underscan
  • I/O
    • Video
      • 1 x BNC (3G-SDI) Input
      • 1 x BNC (3G-SDI) Loop Output
      • 1 x HDMI Type A (HDMI 2.0) Input
      • 3 x HDMI Type A (HDMI 1.4) Input
      • 1 x DVI-I (Dual-Link DVI) Input
      • 1 x DE-15/DB-15 (VGA) Input
    • Audio
      • 1 x 2RCA Line Input
      • 1 x 1/8" / 3.5 mm Headphone Output
    • Built-In Speaker: 1
    • Power I/O: 1 x XLR 4-Pin Input
    • Other I/O: 1 x Tally (DE-9/DB-9)
    • Media/Memory Card Slot: None
    • Wi-Fi: None
  • Format Support
    • Video Format
      • HDMI
        • 1080p: 60/59.94/50/30/29.97/25/24/23.98
        • 1080i: 60/50
        • 720p: 60/59.94/50
      • SDI
        • 1080p: 60/59.94/50/30/29.97/25/24/23.98
        • 1080i: 60/59.94/50
        • 720p: 60/59.94/50
  • Power
    • DC Input Power: 12 to 24 VDC
    • Battery Type: 1 x V-Mount
    • Power Consumption: 15 W
  • Mounting
    • Rack Form Factor: 6 RU
    • Mounting-Hole Pattern: 100 x 100 mm, 75 x 75 mm
  • Environmental
    • Operating Temperature: 32 to 104°F / 0 to 40°C
  • General
    • Dimensions: 19 x 10.5 x 1.5" / 482.5 x 267 x 38 mm
    • Weight: 7.50 lb / 3.4 kg
    • Warranty Length: Limited 2-Year Warranty
  • Packaging Info
    • Package Weight: 25.14 lb
    • Box Dimensions (LxWxH): 24 x 14.5 x 9.3"
