The Kramer GALIL 6-CO provides a pair of two-way open-back ceiling speakers for installed sound. A 6.5-inch woofer and separate tweeter cover voice and music applications.
GALIL 6-CO Detailed Features
- Provide a pair of ceiling speakers for installed audio. The package contains two speakers for voice and music applications. Plan their placement around the listening area and the amplifier's supported speaker load.
- Use a two-way coaxial driver arrangement. Each speaker combines a 6.5-inch polypropylene woofer with a 0.5-inch Mylar tweeter. The coaxial layout brings the high- and low-frequency sections together at one ceiling position.
- Cover a broad audio range. The specified frequency response is 60Hz–20kHz. This supports general installed sound, while final bass performance depends on the ceiling environment and installation.
- Connect to an 8-ohm amplifier system. These are low-impedance speakers rated at 8 ohms. Calculate the resulting load if several speakers are connected to an amplifier channel.
- Match the intended power range. Kramer recommends 30W RMS and lists an 80W maximum rating. Choose amplification and operating levels appropriate to those specifications.
- Plan for an open-back installation. The infinite-baffle design uses an open-back ceiling arrangement. Check the ceiling cavity and project requirements rather than assuming it has a sealed rear enclosure.
- Finish the ceiling with white grilles. White baffle and aluminum grilles provide the visible finish. A template and manual are supplied, and the SKIC-6 mounting bracket is listed as an optional accessory.
Specifications
| Manufacturer part number | 60-000033 |
|---|---|
| DESCRIPTION | 2–way open–back ceiling speakers. |
| HIGH FREQUENCY DRIVER | 0.5" Mylar dome tweeter. |
| LOW FREQUENCY DRIVER | 6.5” polypropylene cone with rubber surround woofer. |
| IMPEDANCE | 8Ω. |
| DISPERSION COVERAGE | 120° @2kHz. |
| CROSSOVER FREQUENCY | 3kHz. |
| NOMINAL SENSITIVITY | 87dB SPL @1m, 1W. |
| COVERAGE ANGLE | 104°. |
| DIRECTIVITY FACTOR (Q) | 8.5 (averaged 100Hz to 10kHz). |
| DIRECTIVITY INDEX (DI) | 9.2dB (averaged 100Hz to 10kHz). |
| FREQUENCY RESPONSE | 60Hz to 20kHz. |
| INPUT POWER | 30W RMS, 80W continuous program. |
| TRANSFORMER | 70V — 3.7W/7.5W/15W/30W |
| TRANSFORMER | 100V — 7.5W/15W/30W. |
| RECOMMENDED AMPLIFIER POWER | 30W. |
| INPUT CONNECTOR | Spring–type push terminal block. |
| WEIGHT PER SINGLE SPEAKER | 1.55kg (3.41lbs) approx. |
| SHIPPING WEIGHT (FOR PAIR) | 4.05kg (8.91lbs) approx. |
| DIMENSIONS (OD) | 23cm (9.06"). |
| CUTOUT DIAMETER | 19.5cm (7.68"). |
| MOUNT DEPTH | 7.5cm (2.95"). |
| OPTIONAL | SKIC–6 installation bracket. |
Technical Questions and Answers
What does the GALIL 6-CO do?
The Kramer GALIL 6-CO provides a pair of two-way open-back ceiling speakers for installed sound. A 6.5-inch woofer and separate tweeter cover voice and music applications.
What is specified for description?
2–way open–back ceiling speakers.
What is specified for high frequency driver?
0.5" Mylar dome tweeter.
What is specified for low frequency driver?
6.5” polypropylene cone with rubber surround woofer.
What is specified for impedance?
8Ω.
What is specified for dispersion coverage?
120° @2kHz.
What is specified for crossover frequency?
3kHz.
What is specified for nominal sensitivity?
87dB SPL @1m, 1W.
Choosing the Right Product
What is the Kramer GALIL 6-CO used for?
It is used for ceiling-mounted background music and speech reinforcement. Provides a pair of two-way open-back ceiling speakers for installed sound. A 6.5-inch woofer and separate tweeter cover voice and music applications.
Who should choose the GALIL 6-CO?
Choose this model when your project needs ceiling-mounted background music and speech reinforcement. Compare the model-specific connections and specifications above with the equipment in your system.
What should I check before ordering the GALIL 6-CO?
Confirm manufacturer part 60-000033, the required connections and the installation requirements. Use the linked documentation to check compatible equipment and required accessories.
