This Kramer 3KHVE2R HDb3000 HDMI Media Module Blade is a HD video encoder/modulator used in HDbridge3000 Chassis that includes 2 HDMI inputs up to 1080i/1080p with embedded digital audio or analog audio and is MPEG−2 RF output configurable for QAM or DVB−T/C. 2 delay match analog audio output for analog audio input. Closed Captions supported via composite (3.5mm input). Cables sold separately.
Kramer 3KHVE2R HDb3000 HDMI Media Module Blade Features:
- RF Modulation
- HDB3000 Blade
- 2 HDMI inputs
- 1080p
- QAM or DVB–T/C output
- ZvShow
Why not buy this Kramer 3KHVE2R HDb3000 HDMI Media Module Blade from HDTV Supply today?
Kramer 3KHVE2R HDb3000 HDMI Media Module Blade Specification:
- General
- Power: 100 ~ 240 V AC 50/60 Hz, 300 W capacity, IEC 60320–C14 jack
- Cooling: Four hot-swappable, N+1 redundant, high-capacity cooling fans
- Airflow: Front inlet, rear exhaust
- Operating Temperature: +32°F to +113°F (0°C to +45°C)
- Mounting: Standard 19-inch equipment rack mounting
- Rack Height: 3 standard rack units (front or rear mountable rack ears)
- Dimensions (W x H x D): 17.4” x 5.1” x 14.75” (441 mm x 129 mm x 374 mm)
- Shipping Weight: 29.5 lbs (13.4 kg), includes packaging
- Modulation Types
- QAM 256 and 64 (ITU–T J83 Annex B)
- DVB–T, DVB–C (ITU–T J83 Annex A) — varies by region
- Cable Standard
- QAM Standard, HRC, or IRC
- DVB–T & DVB–C — user defined (varies by region)
- CCIR Frequency Range
- Frequency agile QAM RF CATV from 54–864 MHz (Channels 2–135)
- Frequency must be within 400 MHz band within the chassis
- Frequency agile CCIR Channels 21–79, 57 MHz – 900 MHz
- Quality
- 2kHz resolution
- ±30 PPM accuracy
- ±35 PPM stability
- RF Output Level
- 13–34 dBmV in 1 dB increments
- MER
- Greater than 39 dB (typical)
- Simple Setup
- User Interface: ZeeVee Maestro
- Network Interface: 10/100 Mb Ethernet via RJ45 connection
- IP address displayed on front and back LCD screens
- IP Configuration: DHCP (default) or static
- Browser-based interface for configuration
- Easy firmware updates
- All settings are persistent
