Atlona AT-VKP-8E Velocity 8 Button Keypad Controller

Atlona

Atlona AT-VKP-8E Velocity 8 Button Keypad Controller
$600.00
Part Number:
AT-VKP-8E
UPC:
846352007614
Condition:
New
Availability:
In Stock
1:
8 Button Keypad Control System
2:
IP-based For Controlling System
3:
RS-232 Control Port
4:
Configure With Atlona Cloud
5:
One-Gang Enclosure
6:
Free USA Shipping
7:
3-Year Atlona Warranty

This Atlona AT-VKP-8E Velocity 8 Button Keypad Controller is a simple yet powerful 8 button IP-based keypad controller for one room of up to 10 devices. The buttons are fully configurable for controls such as display power, input switching, audio levels, or any other functions supported by system devices. In addition to Ethernet, the VKP-8E also features RS-232 for control of legacy devices. For enhanced customization, the VKP-8E incorporates a 2.7” electronic paper (e-paper) display that supports multiple pages to dynamically change icons and text associated with the buttons.

LED indicators for each button and a multi-step LED level indicator provide additional feedback to users. The VKP-8E is designed to mount in one-gang US junction boxes and comes with both black and white faceplates that attach to the button panel via magnets. Power over Ethernet (PoE) provides both power and data to the panel over a single cable. For setup, the VKP-8E uses a revolutionary new configuration platform called Atlona Cloud.

It provides an intuitive interface for mapping control commands, text, and icons to buttons using the extensive library of Atlona and third-party device drivers. When configuration is complete, lightweight instructions can either be sent to the VKP-8E directly over the network or stored in a file for later upload.

Atlona AT-VKP-8E Velocity 8 Button Keypad Controller Feature:

  • Simple yet powerful keypad control system for one room of up to 10 devices
  • 8 buttons for controlling display power, source input, volume levels, and other system functions
  • RGB LED indicators for each button and a multi-step LED level indicator provide user feedback
  • 2.7” high contrast e-paper display with 264 x 172 resolution allows custom icons and text to be associated with each button and dynamically change with different pages
  • IP-based for controlling system devices over the network
  • Bi-directional RS-232 port for controlling projectors, switchers, and other legacy devices
  • Configure with Atlona Cloud for standalone systems, or use as a supplemental user interface in Velocity systems
  • Pre-configured control files available for our most popular switchers
  • Power over Ethernet (PoE) for remote power and network connection with a single cable
  • Designed to mount in one-gang North American junction boxes
  • Black and white faceplates included
  • Included accessories – black and white faceplates, captive screw connector, mounting screws, faceplate screws, installation guide

Why not buy this Atlona AT-VKP-8E Velocity 8 Button Keypad Controller from HDTV Supply today?

Atlona AT-VKP-8E Velocity 8 Button Keypad Controller Specifications:

  • System
    • CPU: i.MX6 with Cortex A7 @900 MHz
    • OS: Linux
    • RAM: LVDDR3 512Mb
    • Flash Memory: EMMC 4GB
  • Display
    • Panel: 2.7 inch e-ink
    • Resolution: 264×172 pixel
    • Color: white/black
  • IP
    • Port: 1 x RJ45
    • Standards and Protocols: DHCP, HTTP, HTTPS, TCP, NTP, IPv4, IPv6
    • Ethernet Speed: 10/100 Mbps
    • Addressing: DHCP, static
  • Temperature
    • Operating Temperature: 32 to 122 °F / 0 to 50 °C
    • Storage Temperature: -25 to 158 °F / -32 to 70 °C
    • Humidity (RH): 10% to 90%, non-condensing
  • Power
    • PoE: IEEE 802.3at/af
  • Dimensions
    • H x W x D (bezel): 4.49 x 2.75 x 0.45 inches / 114 x 69.8 x 11.4 millimeters
    • H x W x D (w/back box): 4.49 x 2.75 x 1.72 inches / 114 x 69.8 x 43.8 millimeters
    • Wall size: 1-gang
  • Weight
    • Device: 0.33 pounds / 0.15 kilograms
  • Certification
    • Device: CE, FCC, RCM, China RoHS, UKCA, ICES

Why not buy this Atlona AT-VKP-8E Velocity 8 Button Keypad Controller from HDTV Supply today?
