This AJA 3G-AMA 3G-SDI Analog Audio Embedder/Disembedder is a 4-channel analog audio embedder/disembedder with support for 3G-SDI input and output up to 1080p 60.

Audio disembedding is always functional, providing four analog outputs. Audio embedding is user selectable, on a channel pair basis, to either pass 3G-SDI input audio or to embed input analog audio from the breakout cable.

Analog audio levels are selectable. The 3G-AMA automatically detects and configures to the input video standard.

AJA 3G-AMA 3G-SDI Analog Audio Embedder/Disembedder Features:

3G-SDI embedder/disembedder
4-channel balanced analog audio I/O
Supplied XLR breakout cable
USB connectivity via AJA Mini-Config software
Supports HDR pass-through
Dipswitch configuration
+5-20VDC Power

Why not buy this AJA 3G-AMA 3G-SDI Analog Audio Embedder/Disembedder from HDTV Supply today?

AJA 3G-AMA 3G-SDI Analog Audio Embedder/Disembedder Specifications:

Video Formats
- (2K) 2048x1080p
- (2K) 2048x1080PsF
- (HD) 1920x1080p
- (HD) 1920x1080PsF
- (HD) 1920x1080i
- (HD) 1280x720p
- (SD) 720x576i
- (SD) 720x480i
- RGB and YCbCr, 4:4:4/4:2:2, 10-bit
Video Input Formats
- 1x 3 Gb SDI (level A or B)
  - (2K) 2048x1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
  - (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30
  - (HD) 1920x1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
  - (HD) 1920x1080PsF 23.98, 24, 25, 29.97, 30
  - (HD) 1920x1080i 50, 59.94, 60
  - (HD) 1280x720p 50, 59.94, 60
- 1x 1.5 Gb SDI
  - (2K) 2048x1080p 23.98, 24, 25, 29.97, 30
  - (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30
  - (HD) 1920x1080p 23.98, 24, 25, 29.97, 30
  - (HD) 1920x1080PsF 23.98, 24, 25, 29.97, 30
  - (HD) 1920x1080i 50, 59.94, 60
  - (HD) 1280x720p 50, 59.94, 60
- 1x 270 Mb SDI
  - (SD) 625i 50
  - (SD) 525i 59.94
Video Output Formats
- Video Out is a delayed, reclocked version of Video In, at same frame rate, etc. Video Out is undefined when no input
Video Latency, time measured between video input and video output connector:
- 3G level A = 3.2 usec
- 3G level B = 6.1 usec
- HD (1.5 Gb) = 6.3 usec
- SD (270 Mb) = 17.2 usec
Video Input Digital
- 1x 3G-SDI BNC, SMPTE-259/292/372/424
Video Output Digital
- 1x 3G-SDI BNC, SMPTE-259/292/372/424
Audio Inputs and Outputs
- Balanced Analog Audio, 1x 25 pin D female connector on converter, 4-channels in, 4-channels out
- Breakout cable provided with 1x 25 pin D male connector:
- 4x XLR female input breakout connectors
- 4x XLR male output breakout connectors
Digital Audio Converters
- 24-bit
Embedded Audio
- SMPTE 272M (SD): 20-bit, 48 kHz synchronous
- SMPTE 299M (3G/HD): 24-bit, 48 kHz synchronous
- Incoming embedded audio can be passed, removed, or overridden
- Up to 16-channels supported
Note: 2048x1080p/PsF 29.97 and 30 formats support a maximum of 8-channels embedded audio
Path Audio Latency
- Embed Path 1100 μsec
- Disembed Path 1200 μsec
Analog Audio Levels
- Configured via Mini-Config software:
- Pro 1: 0 dBfs = +24 dBu
- Pro 2: 0 dBfs = +18 dBu
- Pro 3: 0 dBfs = +15 dBu
- Consumer 1: 0 dBfs = +12 dBu
User Interface
- External DIP switch
- USB port used with Mini-Config software application to configure device via PC/Mac
Size (w x d x h) 5.8" x 3.1" x 1.0" (147.32 x 78.74 x 25.4 mm)
Weight 0.63 lb. (0.29 kg)
Power +5-20VDC, 5 watts power supply required, included with purchase
Environment
- Safe Operating Temperature: 0 to 40 C (32 to 104 F)
- Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
- Operating Relative Humidity: 10-90% noncondensing
- Operating Altitude: <3,000 meters (<10,000 feet)
