QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expanders

QSC

QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expanders
$733.00
Part Number:
QSC-QIO-ML2x2
Condition:
New
Availability:
3-5 Days
1:
Native Network Audio I/O Solution
2:
Power over Ethernet
3:
Simple Drag-&-Drop Integration
4:
Includes Surface Mounting Hardware
5:
Free USA Shipping
6:
QSC Factory Warranty
7:
Ships with the Latest Firmware
8:
QSC Certified

This QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander extends your Q-SYS system’s capabilities and enables streamlined interoperability with non-networked audio devices.

By separating local I/O from processing hardware, the QIO Series offers modular and easily scalable network I/O to support your desired topology.

The QIO Series includes models that provide mic/line connectivity to integrate consumer or professional audio devices into your Q-SYS system.

Professional mic/line connectivity where you need it: QIO Series network audio I/O expanders allow you to deploy mic/line audio connectivity wherever it is most convenient.

The network audio I/O expanders feature professional mic/line-level inputs with +48 VDC phantom power and/or line outputs, along with microphone detection on inputs to enable monitoring, usage statistics, and failure notifications.

Each model features a compact form factor that can be rack- or surface-mounted.

Expanded I/O customization: The QIO Series provides a simpler way to add network I/O connectivity to Q-SYS systems, separating the physical location of the I/O from processing hardware to support distributed or centralized processing architectures.

The QIO Series lets you customize your I/O configuration and complements newer Q-SYS Core models designed with fewer onboard I/O options, including Core Nano, Core 8 Flex, and NV-32-H (Core Capable).

Simplicity and scalability: Daisy-chain up to four QIO Series devices on a single network run with local daisy-chained DC power to conserve network ports, reduce rack clutter, and simplify future expansion without pulling additional network cables.

Alternatively, QIO Series devices support Power over Ethernet (PoE), providing single-cable connectivity when devices are not daisy-chained.

Designed for Q-SYS: The QIO Series delivers native network I/O customization for Q-SYS, a cloud-manageable audio, video, and control platform designed to provide scalable and flexible AV solutions.

READ MORE

QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander Features:

  • Native network audio I/O solution for Q-SYS
  • Two (2) mic/line inputs and two (2) line outputs
  • Professional mic/line-level inputs with +48 VDC phantom power support
  • Microphone detection on inputs for monitoring, usage statistics, and failure notifications
  • Power over Ethernet (PoE) capable
  • Daisy-chain up to four QIO expanders on a single network run with local daisy-chained DC power
  • Drag-and-drop integration and management through Q-SYS Designer Software and Q-SYS Reflect
  • Surface- or rack-mountable; 1RU, quarter-rack width
  • Includes surface-mounting hardware
Q-SYS Level 1 Certified Expertise at HDTV Supply

QSC Certified Expertise

Knowledgeable Support for QSC Products

HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.

This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.

Why not buy this QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander today?

Ask a Question About the QSC QIO-ML2x2

Have questions about the QSC QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander? Contact HDTV Supply for product information and compatibility assistance.

Call: 833-WOLFPACK (833-965-3722)

Website: HDTV Supply

QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander Specifications:

Specifications QIO-ML2x2
Connectivity
Audio I/O Two (2) mic/line inputs and two (2) line outputs
Mic/Line Inputs
Maximum Input Level Not provided in the supplied specifications
Preamplifier Gain Range Not provided in the supplied specifications
Phantom Power Not provided in the supplied specifications
Equivalent Input Noise Not provided in the supplied specifications
Input-to-Input Crosstalk at 1 kHz Not provided in the supplied specifications
Input Dynamic Range at +24 dBu Sensitivity Not provided in the supplied specifications
Input Dynamic Range at +10 dBu Sensitivity Not provided in the supplied specifications
Input Dynamic Range at -10 dBu Sensitivity Not provided in the supplied specifications
Input Dynamic Range at -36 dBu Sensitivity Not provided in the supplied specifications
Input Impedance Not provided in the supplied specifications
Line Outputs
Output Audio Level Range -36 dBu to +24 dBu
Output Dynamic Range 108 dB
Output-to-Output Crosstalk at 1 kHz > 85 dB
Output Impedance 150 Ω to 300 Ω
Sample Rate 48 kHz
Bit Depth 24 bit
Other Connectors
External Power Supply 24 VDC nominal, 2.5 A on Euro connector with second connector for daisy-chaining. QIO-PSU power supply sold separately.
LAN (PoE) Gigabit LAN connection for Q-LAN, PoE
PoE Specification IEEE 802.3af Type 1
LAN (Thru) Ethernet daisy-chaining
General
Dimensions 8.5 x 4.25 x 1.59 in (215.9 x 108 x 40.4 mm)
Weight 1.72 lb (0.78 kg)
Mounting Options Surface- and wall-mountable with hardware included. Rack-mountable; 1RU, quarter-rack width. QIO-RMK rack kit sold separately.
Environmental
Ambient Operating Temperature 0°C to +50°C
Humidity 0%–85% through 30°C, non-condensing
Storage Temperature -20°C to +70°C
Compliance
Regulatory Compliance FCC 47 CFR Part 15, IC ICES-003, CE (EN55032, EN55035), EU RoHS Directive 2011/65/EU, WEEE Directive 2012/19/EU, China RoHS Directive GB/T26572, EAC, UL, C-UL, NOM-019

Why not buy this QSC Q-SYS QIO-ML2x2 Q-SYS Network 2-Mic/Line Inputs Expander today?

QSC Q-SYS QIO-ML2x2 Manuals and Documentation

QSC QIO-ML2x2 User Manual

QSC QIO-ML2x2 Specification Sheet

QSC Q-SYS QIO-ML2x2 Questions & Answers

The QSC QIO-ML2x2 is a Q-SYS network audio I/O expander with two mic/line inputs and two line outputs for compatible Q-SYS systems.
It provides two mic/line inputs and two line outputs.
The QIO-ML2x2 is described as having mic/line inputs. Confirm the exact input-level and gain specifications in the manufacturer's documentation for your application.
The product description references +48 VDC phantom power for QIO Series mic/line models. Verify the QIO-ML2x2's specific phantom-power capability in its current manufacturer documentation.
The supplied specifications list an output audio level range of -36 dBu to +24 dBu.
Yes. The supplied specifications state that the device supports PoE and conforms to IEEE 802.3af Type 1.
The supplied specifications list a 24 VDC nominal, 2.5 A external power supply connection. The QIO-PSU power supply is sold separately.
Yes. Up to four QIO Series devices can be daisy-chained on one network run using the supported local DC power daisy-chain arrangement.
Yes. It supports surface and wall mounting with included hardware. Rack mounting is supported using the separately sold QIO-RMK rack kit.
The supplied specifications list dimensions of 8.5 x 4.25 x 1.59 inches (215.9 x 108 x 40.4 mm) and a weight of 1.72 lb (0.78 kg). Verify these figures against the manufacturer's documentation before publishing.
A Q-SYS mic/line I/O expander adds audio input and output connectivity at a location that suits the installation, helping connect compatible audio equipment to a Q-SYS system.
It is designed to add network audio I/O to a Q-SYS system. Confirm the signal types, wiring, and compatibility requirements of the connected equipment before installation.
The QIO Series is designed for integration and management through Q-SYS Designer Software and Q-SYS Reflect. Consult current QSC documentation for software version and configuration requirements.
Depending on the installation, the separately sold QIO-PSU power supply or QIO-RMK rack-mount kit may be required. PoE is another supported power option when compatible network equipment is used.
Contact HDTV Supply for current availability and purchasing assistance. Call 833-WOLFPACK (833-965-3722) for help with your Q-SYS product requirements.
