QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier
- Four 250W Output Channels
- Lo-Z, Hi-Z, 70V and 100V Direct Drive
- Dual 1GbE Network Connectivity
- Native Q-SYS Audio and Control Integration
The QSC Q-SYS MPA-Q 4x250 is a four-channel network amplifier designed to extend native Q-SYS integration into distributed audio and performance applications. It delivers up to 250W of maximum power per channel and supports Lo-Z, Hi-Z, 70V, and 100V direct drive without requiring bridging or manual output-mode switches.
Each amplifier channel includes a dedicated analog line-level input that can be fully routed into Q-SYS or used directly with the amplifier. This provides flexible connectivity for systems that combine networked audio with conventional analog sources.
The MPA-Q 4x250 includes dual 1GbE Ethernet ports for redundant networked audio and provides four GPI inputs plus two NO/NC output relays for control integration. Its Standalone Mode can automatically switch to available analog inputs if network connectivity is lost, helping maintain audio continuity.
The amplifier also supports rapid audio restoration after a power interruption when a PoE connection is available. With its 2RU form factor and removable rack ears, the MPA-Q 4x250 can be rack- or surface-mounted in professional AV installations.
QSC Certified Expertise
Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Why not buy this QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier today?
Bring flexible multi-channel amplification and native Q-SYS network audio control to your professional AV installation.
Ask a Question
Have questions about the QSC Q-SYS MPA-Q 4x250, speaker compatibility, 70V/100V operation, Q-SYS integration, networking, or installation? Our team is ready to help.
Contact HDTV Supply Customer Service
Why not buy this QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier today?
Contact HDTV Supply for knowledgeable assistance with your Q-SYS audio system.
Specifications
| Model | MPA-Q 4x250 |
| Product Type | 4-Channel Q-SYS Network Amplifier |
| Output Channels | 4 |
| Maximum Power | 250W per Channel |
| Continuous Power | 150W per Channel, All Channels Driven |
| Direct Drive Loads | Lo-Z, Hi-Z, 70V and 100V |
| Supported Loads | 2Ω, 4Ω, 8Ω, 70V, 100V |
| Bridged Maximum Power | 500W Maximum / 300W Continuous |
| Analog Inputs | 4 x Line-Level Inputs |
| Input Type | Balanced and Unbalanced Analog |
| Input Dynamic Range | >108 dB |
| Input Impedance | >11 kΩ Balanced / >5.5 kΩ Unbalanced |
| Sample Rate | 48 kHz |
| Frequency Response | +0.2 dB / -0.7 dB, 20 Hz - 20 kHz @ 8Ω |
| THD+N | 0.01% - 0.03% Typical; 1% Maximum |
| Signal-to-Noise Ratio | >112 dB, A-Weighted |
| Damping Factor | >160 |
| DSP | Gain, Polarity, IIR/FIR Filters, Delay and Limiters |
| FIR Processing | 1024 Taps per Channel |
| Delay | Up to 2020 ms per Channel |
| GPIO | 4 GPI Inputs |
| Relays | 2 x NO/NC Output Relays |
| Network | Dual 1GbE Ethernet Ports |
| Network Audio | Q-SYS Network Audio |
| PoE Backup | IEEE 802.3af Type 1 on LAN A |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 5% - 85% RH |
| Dimensions | 15.0 x 19.0 x 3.5 Inches (D x W x H) |
| Dimensions | 381 x 483 x 89 mm |
| Product Weight | 19.4 lbs (9.0 kg) |
| Estimated Shipping Weight | 24 lbs |
| Rack Format | 2RU Full Rack Width |
| Cooling | Forced Air, Thermally Regulated Fan |
| Airflow | Front to Rear |
| Power Supply | 100-240 VAC, 50/60 Hz |
Why not buy this QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier today?
Get flexible four-channel amplification with native Q-SYS networking, DSP, GPIO, and direct-drive support for Lo-Z and Hi-Z applications.
Manuals
Q-SYS MPA-Q Series Hardware User Manual
This official manual covers the MPA-Q 4x250, MPA-Q 4x500, MPA-Q 8x125, and MPA-Q 8x250 network amplifiers.
Download the Q-SYS MPA-Q Series Hardware User Manual
Q-SYS MPA-Q Series Specification Sheet
Download the MPA-Q Series Specification Sheet
Why not buy this QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier today?
Review the official documentation and contact HDTV Supply if you need assistance with amplifier configuration or Q-SYS integration.
What is the QSC Q-SYS MPA-Q 4x250?
A: The MPA-Q 4x250 is a four-channel Q-SYS network amplifier capable of up to 250W maximum power per channel.
How many channels does the MPA-Q 4x250 have?
A: It has four independent amplifier output channels.
How much power does each channel provide?
A: The MPA-Q 4x250 provides up to 250W maximum power per channel, with 150W continuous power when all channels are driven.
Can the MPA-Q 4x250 power 70V and 100V speakers?
A: Yes. All channels support direct drive for 70V and 100V Hi-Z loudspeakers without requiring manual output-mode switches.
Can the MPA-Q 4x250 power low-impedance speakers?
A: Yes. The amplifier supports Lo-Z loads including 2Ω, 4Ω, and 8Ω operation.
Does the MPA-Q 4x250 have analog inputs?
A: Yes. It provides four analog line-level inputs that can be routed into Q-SYS or used directly by the amplifier.
Does the MPA-Q 4x250 support Q-SYS network audio?
A: Yes. It is a native Q-SYS network amplifier with dual 1GbE Ethernet ports for redundant networked audio.
Does the MPA-Q 4x250 have GPIO?
A: Yes. It provides four GPI inputs and two NO/NC output relays for control integration.
Can the MPA-Q 4x250 operate if the network connection is lost?
A: Yes. Standalone Mode can automatically switch to available analog inputs when network connectivity drops, helping maintain audio continuity.
Can the MPA-Q 4x250 be rack mounted?
A: Yes. The MPA-Q 4x250 is a 2RU full-rack amplifier with removable rack ears for rack or surface mounting.
What is the Q-SYS MPA-Q 4x250 used for?
A: It is designed for distributed audio, hospitality, entertainment, retail, government, corporate, education, and other professional AV applications.
Can the MPA-Q 4x250 drive both Hi-Z and Lo-Z speakers?
A: Yes. Each channel can directly drive Lo-Z, Hi-Z, 70V, or 100V loads without manual output-mode switching.
Does the MPA-Q 4x250 have built-in DSP?
A: Yes. DSP functions include gain, polarity, IIR filters, FIR filters, delay, and multiple limiter types.
Can the MPA-Q 4x250 recover audio quickly after a power interruption?
A: Yes. If a PoE connection is available, Q-SYS provides a quick audio restoration path following a power interruption.
Why choose the Q-SYS MPA-Q 4x250 for a professional AV system?
A: The MPA-Q 4x250 combines four 250W amplifier channels, flexible Lo-Z/Hi-Z operation, native Q-SYS networking, analog inputs, DSP, GPIO, and redundant Ethernet connectivity in a 2RU chassis.
Why not buy this QSC Q-SYS MPA-Q 4x250 4-Channel 250W Network Amplifier today?
Choose the MPA-Q 4x250 for flexible, scalable amplification and native Q-SYS system integration.
Warranty
The QSC Q-SYS MPA-Q 4x250 is covered by a 3-Year Limited Warranty, subject to the applicable QSC/Q-SYS warranty terms and conditions.
QSC's current warranty statement lists the Q-SYS MP-A Series under a 3-year warranty period, and the MPA-Q Series is part of the Q-SYS network amplifier portfolio.
