The QSC AD-C10T-HPZB-WH AcousticDesign Series 10-Inch Zero-Bezel Ceiling Mount Loudspeaker (White) is a passive, two-way ceiling loudspeaker designed for high-quality audio in hospitality, retail, education, transportation, entertainment, and other commercial environments.
Its 10-inch woofer and 1.5-inch compression driver are arranged coaxially to support consistent sound reproduction. The 90-degree Directivity Matched Transition (DMT) waveguide is designed to provide smooth, uniform frequency response across the coverage area.
The integrated 70V/100V transformer supports distributed audio installations, while the 8-ohm bypass option allows use with compatible low-impedance amplifier systems. The zero-bezel design, snap-fit magnetic grille, and blind-mount system provide a clean, professional ceiling installation.
QSC AD-C10T-HPZB-WH Features
- AcousticDesign Series 10-inch, two-way ceiling loudspeaker
- Zero-bezel design for modern commercial installations
- 10-inch paper woofer and 1.5-inch compression driver
- 90-degree conical coverage using a DMT waveguide
- 70V and 100V multi-tap transformer operation
- 8-ohm transformer-bypass mode for compatible low-impedance systems
- Snap-fit magnetic grille
- Three double-stepped, long-travel dog-ear blind-mount mechanisms
- Consistent tonal characteristics across the AcousticDesign Series
- Intrinsic Correction voicings available through the Q-SYS Platform with compatible CX-Q amplifiers
- Removable, blemish-free logo
- Removable conduit cover plate, with an accessory option for pre-installation wiring
- UL 1480 and UL 2043 certifications, as stated in the supplied product information
- White finish (RAL 9003); black grille accessory sold separately
- EASE, CF2, CAD, and BIM information available from the manufacturer
Why Buy the QSC AD-C10T-HPZB-WH from HDTV Supply?
HDTV Supply offers professional AV equipment for commercial audio systems, distributed sound, and installation projects. Contact our team for help selecting compatible loudspeakers and amplification for your application.
QSC Certified Expertise
Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Ask a Question About the QSC AD-C10T-HPZB-WH
Need help with transformer taps, amplifier compatibility, ceiling installation, or selecting loudspeakers for a commercial audio system? Contact HDTV Supply for assistance.
QSC AD-C10T-HPZB-WH Specifications
| General Information | |
|---|---|
| Brand | QSC |
| Model | AD-C10T-HPZB-WH |
| Series | AcousticDesign |
| Speaker Type | Passive ceiling loudspeaker |
| Number of Speakers | 1 |
| Configuration | Two-way |
| Enclosure Type | Sealed |
| Power and Transformer | |
| Power Handling | 250W RMS, as supplied |
| Peak Power Handling | 500W peak, as supplied |
| 70V Transformer Taps | 200W / 100W / 50W / 25W, or 8-ohm bypass |
| 100V Transformer Taps | 200W / 100W / 50W, or 8-ohm bypass |
| Impedance | 6.9–8 ohms, as supplied; verify the applicable impedance specification for the selected operating mode |
| Amplifier Requirement | Compatible external amplifier required |
| Drivers | |
| High-Frequency Driver | 1 × 1.5-inch (38.1 mm) compression driver |
| Low-Frequency Driver | 1 × 10-inch (254 mm) paper woofer |
| LF Voice Coil | 2-inch (50.8 mm) |
| LF Magnet | Ferrite |
| Audio Performance | |
| Frequency Range (-10 dB) | 68 Hz–20 kHz |
| Frequency Response (-3 dB) | 86 Hz–20 kHz |
| Maximum SPL, Continuous | 116 dB |
| Maximum SPL, Peak | 128 dB |
| Sensitivity | 92.5 dB, as supplied |
| Coverage | 90-degree conical |
| Waveguide Technology | Directivity Matched Transition (DMT) |
| Q-SYS Processing | Intrinsic Correction voicings available through the Q-SYS Platform with compatible CX-Q amplifiers |
| Connectivity | |
| Input/Thru Connection | 1 × 4-pin block speaker connector |
| Transformer Bypass | 8-ohm bypass mode, as supplied |
| Installation and Physical | |
| Mounting | In-ceiling, blind-mount system |
| Mounting Mechanism | Three double-stepped, long-travel dog-ear mechanisms, as supplied |
| Grille | Snap-fit magnetic grille |
| Color | White (RAL 9003) |
| Optional Grille | Black grille accessory sold separately |
| Construction Materials | ABS and steel |
| Environmental Resistance | Not specified as weather-resistant |
| Dimensions | 13.75 × 13.5 × 13.5 inches (349.25 × 342.9 × 342.9 mm), as supplied |
| Product Weight | 23 lb (10.4 kg) |
| Compliance and Design Resources | |
| Safety Certifications | UL 1480 and UL 2043, as stated in the supplied product information |
| Design Resources | EASE, CF2, CAD, and BIM information available from the manufacturer |
QSC AD-C10T-HPZB-WH Manuals and Documentation
Contact HDTV Supply for assistance locating the appropriate QSC user guide, installation instructions, datasheet, or technical documentation for this model.
Q/A
Q1: What is the QSC AD-C10T-HPZB-WH?
A: It is a passive, two-way, 10-inch ceiling loudspeaker from QSC's AcousticDesign Series, designed for commercial and distributed audio applications.
Q2: Is the AD-C10T-HPZB-WH an active or passive speaker?
A: It is a passive loudspeaker and requires a compatible external amplifier.
Q3: What size woofer does this QSC ceiling speaker have?
A: It features one 10-inch paper woofer paired with a 1.5-inch compression driver.
Q4: Does the AD-C10T-HPZB-WH support 70V and 100V audio systems?
A: Yes. The supplied specifications list transformer taps for both 70V and 100V distributed audio systems.
Q5: Can this speaker be used with an 8-ohm amplifier system?
A: The supplied product information lists an 8-ohm transformer-bypass mode. Ensure the speaker is configured correctly and the amplifier is compatible before connecting it.
Q6: What is the coverage angle of this ceiling loudspeaker?
A: The supplied specifications list 90-degree conical coverage.
Q7: What is the frequency response of the AD-C10T-HPZB-WH?
A: The supplied specifications list 68 Hz–20 kHz at -10 dB and 86 Hz–20 kHz at -3 dB.
Q8: What is the maximum SPL of this QSC speaker?
A: The supplied specifications list 116 dB continuous maximum SPL and 128 dB peak maximum SPL.
Q9: How is the AD-C10T-HPZB-WH installed?
A: It is designed for in-ceiling installation and includes a blind-mount system. Follow the manufacturer's installation instructions and verify that the ceiling structure can safely support the speaker.
Q10: What color is the AD-C10T-HPZB-WH?
A: This model has a white finish identified as RAL 9003 in the supplied product information.
Q11: What applications are suitable for this QSC ceiling speaker?
A: It may be used in commercial environments such as restaurants, retail stores, educational facilities, hospitality venues, and transportation facilities, subject to the project's acoustic and installation requirements.
Q12: What is the benefit of the zero-bezel grille design?
A: The zero-bezel design provides a cleaner, less visually intrusive appearance that can suit modern commercial interiors.
Q13: What does the DMT waveguide do?
A: Directivity Matched Transition (DMT) technology is designed to help provide consistent frequency response and coverage across the speaker's intended listening area.
Q14: Can this speaker be used with Q-SYS systems?
A: The supplied information states that Intrinsic Correction voicings are available through the Q-SYS Platform with compatible CX-Q amplifiers. Verify the required system configuration and compatibility in QSC's documentation.
Q15: What should I check before purchasing this ceiling loudspeaker?
A: Check the required coverage, ceiling cutout and mounting requirements, transformer tap selection, amplifier compatibility, power handling, and local installation or fire-safety requirements. Contact HDTV Supply if you need assistance.
