This Kramer VP-200AK 1:2 UXGA Computer Graphics Video & Stereo Audio Distribution Amplifier is a high-performance distribution amplifier designed to ensure the highest quality distribution of computer graphics video and stereo audio signals. It amplifies graphic video signals with resolutions up to and beyond UXGA (1600 x 1200), delivering clear and precise images for corporate, educational, religious, rental, and staging environments.
The unit distributes one computer graphics input to two identical buffered and isolated outputs on high-density 15-pin HD connectors. It also simultaneously outputs two sets of balanced and unbalanced stereo audio signals from a single unbalanced stereo audio input, providing a comprehensive audio-visual solution. With a high video bandwidth of 510MHz, the amplifier remains transparent even at high-resolution graphic modes.
Kramer VP-200AK 1:2 UXGA Computer Graphics Video & Stereo Audio Distribution Amplifier Features:
- High-performance unit with stereo audio signals and a resolution up to and exceeding UXGA.
- Ideal for rental and staging systems, schools, religious institutions and corporate applications.
- Compatible with HDTV component signals when used with the breakout cable (Kramer CGM/3RVF).
- Accepts 1 computer graphics input and distributes the signal to 2 identical outputs on 15-pin HD connectors.
- High video bandwidth — 510MHz.
- ID bit control.
- Separate controls for audio output level and UXGA equalization.
- Right and left level trimmers to adjust the audio signal levels.
- UXGA EQ trimmer to adjust the video equalization compensation.
- Kramer Kr-isp Advanced Sync Processing technology.
- Optional RK-3T rack adapter.
Why not buy this Kramer VP-200AK 1:2 UXGA Computer Graphics Video & Stereo Audio Distribution Amplifier from HDTV Supply today?
Kramer VP-200AK 1:2 UXGA Computer Graphics Video & Stereo Audio Distribution Amplifier Specifications:
- Inputs
1 UXGA on a 15-pin HD (F) connector, 1 unbalanced stereo audio on a 3.5mm mini jack - Outputs
2 UXGA on 15-pin HD (F) connectors, 2 unbalanced stereo audio on 3.5mm mini jacks, 2 balanced stereo audio on detachable 5-pin terminal blocks - Max. Output Level
Video: 2.0Vpp; Audio: 7.2Vpp - Bandwidth (-3dB)
Video: 510MHz; Audio: >100kHz - Diff. Gain
0.55% - Diff. Phase
0.10Deg - K-Factor
<0.05% - S/N Ratio
Video: 72.5dB at 5MHz; Audio: 82dB (balanced); 88dB (unbalanced) - Controls
EQ: 0dB to 4.7dB at 50MHz - Coupling
Video: DC; Audio: AC at the output; DC at the input - Audio THD + Noise
0.005% at 1kHz (unbalanced and balanced) - Audio 2nd Harmonic
0.003% (unbalanced); 0.001% (balanced) - Power Consumption
5V DC, 120mA - Dimensions (W x D x H)
12 x 7.18 x 2.42cm (4.72 x 2.82 x 0.95") - Weight
0.3 kg / 0.66 lbs
