This Kramer VP-211K 2x1 Computer Graphics Video & Stereo Audio Standby Switcher switches the primary input to the secondary input on loss of the primary input. It is compatible with computer graphics video signals with resolutions up to and exceeding UXGA, and unbalanced stereo audio signals. The switcher features a bandwidth of 300MHz (-3dB), a looping input, and a selectable primary input.
Kramer VP-211K 2x1 Computer Graphics Video & Stereo Audio Standby Switcher Features:
- Switches primary input to secondary input on loss of primary input.
- Compatible with computer graphics video signals up to and exceeding UXGA and unbalanced stereo audio signals.
- Bandwidth - 300MHz (-3dB).
- Looping input and selectable primary input.
- Active input LED indicators.
- Automatic and contact closures for controlling the switcher.
- Compact size - 4.76 x 2.83 x 0.95" / 12.1 x 7.18 x 2.42 cm.
- 3 units can be rack-mounted side-by-side in a 1U rack space with the optional RK-3TR rack adaptor.
Why not buy this Kramer VP-211K 2x1 Computer Graphics Video & Stereo Audio Standby Switcher from HDTV Supply today?
Kramer VP-211K 2x1 Computer Graphics Video & Stereo Audio Standby Switcher Specifications:
- Inputs
2 computer graphics video on 15-pin HD connectors; 2 unbalanced stereo audio on 3.5mm mini jacks - Outputs
1 computer graphics video on a 15-pin HD connector; 1 computer graphics video looping on a 15-pin HD connector; 1 unbalanced stereo audio on a 3.5mm mini jack - Maximum Output Level
Video: 1.6Vpp; Audio: >10.5Vpp - Bandwidth
Video: 300MHz; Audio: >100kHz - Differential Gain
0.03% - Differential Phase
0.03Deg - K-Factor
<0.05% - S/N Ratio
Video: 71dB; Audio: 71dB weighted - Crosstalk
Video: -59dB @5MHz; Audio: <-66dB @1kHz - CONTROLS
Contact closure remote control, input default selection switch - Coupling
DC - Power Source
5V DC 200mA - Dimensions
4.76 x 2.83 x 0.95" / 12.1 x 7.18 x 2.42cm - Weight
0.3kg (0.66lbs) approx - Accessories
Power supply, mounting bracket - Options
RK-3T 19" rack adaptor - Packaging Info
Package Weight: 1.2 lb
Box Dimensions (LxWxH): 9.1 x 4.9 x 3.4"
