This Kramer DTAXRD2-OUT2-F34 2-Channel 4K HDR HDMI over HDBaseT Output Card with Analog Audio is a two-channel, 4K@60 Hz (4:4:4), DSC, HDMI, analog audio, bidirectional RS-232, Ethernet & IR over HDBaseT twisted pair transmitter card for compatible Kramer Modular Multi-Format Digital Matrix Switchers. DTAxrD2-OUT2-F34 outputs two extended-reach HDBaseT signals with selectable embedded/de-embedded analog audio, bidirectional RS-232, IR, and Ethernet from the chassis to the line.
Kramer DTAXRD2-OUT2-F34 2-Channel 4K HDR HDMI over HDBaseT Output Card with Analog Audio Features:
- Max data rate: 18 Gb/s (6 Gb/s per graphics channel), 10 Gb/s CSC over CAT cable
- Max resolution: 4K@60 Hz (4:4:4)
- Analog audio embedding/de-embedding or ARC on the same jack
- HDBaseT technology: HDTV compatible, HDCP 2.2/1.4 compliant
- System range: up to 328' at normal mode (4K), up to 430' at normal mode (2K), up to 590' ultra mode (1080p @ 60 Hz @ 24bpp)—Note: when using Kramer HDBaseT cables
- Ethernet extension: Ethernet interface data flows in both directions, allowing extension of up to 100 Mb/s Ethernet connectivity for LAN communication and device control
- Bidirectional RS-232 extension: Serial interface data flows in both directions, allowing data transmission and device control
- Bidirectional infrared extension: IR interface data flows in both directions, allowing remote control of peripheral devices located at either end of the extended line
- 3D pass through
Why not buy this Kramer DTAXRD2-OUT2-F34 2-Channel 4K HDR HDMI over HDBaseT Output Card with Analog Audio from HDTV Supply today?
Kramer DTAXRD2-OUT2-F34 2-Channel 4K HDR HDMI over HDBaseT Output Card with Analog Audio Specification:
- CARD TYPE
- Transceiver Module
- INTERFACES
- Transmission I/O
- 2× Block 6-Pin (RS-232 / Analog Audio) Input/Output
- 2× Block 4-Pin (IR) Input/Output
- 1× RJ45 (LAN) Output
- Transmission I/O
- STANDARDS
- HDCP Support: Yes
- TRANSMISSION
- Max Transmission Distance
- DCI 4K: 328.1 ft / 100 m
- 1080p: 656.2 ft / 200 m
- Video Format
- RJ45: 4096 × 2160
- RJ45: 1920 × 1080p
- Video Bandwidth
- 5.98 Gb/s per Graphic Channel (Compressed)
- 3.4 Gb/s per Graphic Channel (Uncompressed)
- Max Transmission Distance
- POWER
- PoE Support: No
- GENERAL
- Certifications: CE
- Operating Conditions: 32 to 104°F / 0 to 40°C at 10 to 90% Humidity
- Storage Conditions: –40 to 140°F / –40 to 60°C
- Dimensions: 9.8 × 5.1 × 0.8 in / 25 × 13 × 2 cm
- Weight: 7.1 oz / 200 g
