This Kramer BCLS-33 1640ft CAT 6A F/UTP Low-Smoke/Zero-Halogen Cable with Metal-Foil Screen is a high-performance Cat 6A F/UTP cable for IT, LAN, and Ethernet installations. Its design exceeds Cat 6A specifications and provides a larger bandwidth than the basic standard cable (sweep frequency up to 650 MHz).
The cable is constructed with four pairs of 23-gauge solid bare-copper conductors. The low-smoke zero-halogen jacket emits limited smoke and no halogen when exposed to high sources of heat, protecting people and equipment from toxic and corrosive gas.
Acting as a shield, an overall metal-foil screen with a drain wire helps further reduce the potential for electromagnetic interference (EMI). Other features include an internal rip cord to prevent damage to the individual conductors when stripping off the jacket, a cross filler to reduce crosstalk, sequential markings every meter, and a fumigated plywood reel.
Kramer BCLS-33 1640ft CAT 6A F/UTP Low-Smoke/Zero-Halogen Cable with Metal-Foil Screen Features:
- 4 pairs of 23 AWG solid bare-copper conductors
- Low-smoke zero-halogen jacket for safety
- Exceeds Cat 6A specifications for wider bandwidth
- Sweep frequency up to 650 MHz
- Overall metal-foil screen with drain wire
- Internal rip cord for additional protection
- Cross filler for reduced crosstalk
- Sequential markings every meter
- Fumigated plywood reel
- Applications include structure cabling for horizontal and building backbone cable, IT, LAN and Ethernet installations, IEEE 802.3ab 1000BASE-T, 1000BASE-TX and legacy speeds, CDDI/ATM/Token Ring, and IEEE 802.3af (PoE) / IEEE 802.3at (PoE+)
Why not buy this Kramer BCLS-33 1640ft CAT 6A F/UTP Low-Smoke/Zero-Halogen Cable with Metal-Foil Screen from HDTV Supply today?
Kramer BCLS-33 1640ft CAT 6A F/UTP Low-Smoke/Zero-Halogen Cable with Metal-Foil Screen Specification:
- Cable Length: 1640' / 500 m
- Ethernet Standards: Cat 6a
- Compatibility: 10GbE
- Bandwidth Rating: 500 MHz
- Wire Gauge: 23 AWG
- Materials: Conductor: Bare Copper
- Certifications: ANSI, EN, IEC, ISO/IEC
- Packaging Info
- Package Weight: 76 lb
- Box Dimensions (LxWxH): 12.8 x 11.5 x 11"
