This Kramer AW-8D/60-000111 8 Inch, 2-way Wall Mounted PoE Powered Dante Speaker (White) is a powerful, high−performance 8” all−weather PoE−powered Dante speaker, designed to deliver deeper, fuller sound with enhanced sensitivity for both indoor and outdoor environments. Built to withstand harsh weather conditions while meeting the requirements of indoor installations, the AW−8D is the ideal solution for mixed−use deployments where high−quality audio and consistent design are essential.
Engineered with the system integrator in mind, the AW−8D includes a built−in amplifier, DSP, and mixer, allowing for two−channel mixing and precise sound tuning. Advanced features include configurable parametric EQ, high−pass/low−pass filters, input compression, output limiting, power management, a “Find Me” tone trigger, and firmware updates—all managed through Kramer’s intuitive Speaker Utility software.
The AW−8D also supports integration with Kramer Control and third−party control systems via a robust API, enabling remote control of volume, mute, and more.
Available in black or white, the AW−8D combines premium audio performance with sleek, professional design for any commercial installation.
Kramer AW-8D/60-000111 8 Inch, 2-way Wall Mounted PoE Powered Dante Speaker (White) Features:
- Exceptional sound performance
- IP66 rated for outdoor installations
- Made from V–0 flame retardant materials. designed to comply with UL1480A for indoor installations
- Supports PoE++/PoE+/PoE (auto–negotiate)
- Built–in mixer, DSP, and amplifier for two–channel mixing, parametric EQ, High pass and low pass filters, input compressor, output limiter and advanced power settings
- Features a built–in “Find Me” tone, making it easy to identify and locate individual speakers during installation or maintenance.
- Power handling: 10W continuous / 30W peak
- Sound Pressure Level (SPL): - Sensitivity (1W@1m, free field): 91dB SPL
Maximum SPL: Continuous: 100dB SPL / Peak: 106dB SPL - Regulatory compliance: - IEC62368(CB) / CE LVD, UL62368
FCC+IC, BIS, RCM
RoHS, REACH, WEEE - Industrial design: - wall–mounted, tool–less installation, available in black & white colors, removable logo
- The AW–8D all–weather PoE powered Speaker is a high–end solution for both outdoor and indoor installations delivering high–performance high–quality sound in professional Dante networked audio installations.
- Included in the box: - 1 speaker (single unit), 2 speakers are packed in a single master box
- 1 mounting bracket + 2 toolless bracket screws
- 1 Silicon Grommet
- Quick Start Guide
Why not buy this Kramer AW-8D/60-000111 8 Inch, 2-way Wall Mounted PoE Powered Dante Speaker (White) from HDTV Supply today?
Kramer AW-8D/60-000111 8 Inch, 2-way Wall Mounted PoE Powered Dante Speaker (White) Specification:
- DESCRIPTION
- All weather, 8”, 2–way wall mounted PoE powered Dante speaker
- Audio
- Driver:
- LF Driver: 200 mm (8 in) high output driver with polypropylene cone and rubber surround
- HF Driver: 25 mm (1 in) liquid cooled soft–dome tweeter
- Frequency characteristics
- Frequency Range (-10dB): 70Hz–20kHz
- Frequency Response (±3dB): 88Hz–20kHz
- Dispersion angle: 104 deg. (1 kHz to 4 kHz)
- Power handling:
- PoE++: 10W continuous / 30W peak
- PoE+: 10W continuous / 20W peak
- PoE: 10W continuous / 10W peak
- OCM (Over-Current Protection): Monitors input current and reduces gain to prevent damage
- OSP (Output Shortcut Protection): Shuts down and restarts the amplifier if a shortcut is detected
- Sound Pressure Level (SPL):
- Sensitivity (1W@1m, free field): 91dB SPL
- Maximum SPL: PoE++: Continuous: 101dB / Peak: 106dB
- Maximum SPL: PoE+: Continuous: 101dB / Peak: 104dB
- Maximum SPL: PoE: Continuous: 100dB / Peak: 101dB
- Built-in Protection OTM (Over-Temperature Protection): Automatically lowers volume if overheating is detected, restoring it once temperature normalizes
- Driver:
- MECHANICAL
- Installation
- Type: Surface mounted vertical or horizontal
- Mounting: Toolless mounting bracket
- Connectors: RJ–45, factory reset button
- Dimensions
- Dimensions without Bracket: 251mm x 200mm x 400mm / 9.88” x 7.88” / 15.75”
- Dimensions with Bracket: 251mm x 240mm x 400mm / 9.88” x 9.45” / 15.75”
- Shipping dimensions (single unit): 322mm x 312mm x 467mm / 12.7" x 12.3" / 18.4"
- Shipping dimensions (2 units in a Master box): 630mm x 330mm x 485mm / 24.8" x 13.0" x 19.1"
- Shipping weight (single unit): 4.7Kg / 10.4lbs
- Shipping weight (Master box): 10.2Kg / 22.5lbs
- Material
- Grill: Aluminum, removable logo
- Baffle & back enclosure: V–0 Flame Retardant
- Bracket: Aluminum
- Installation
- Environmental
- Operating Temperature: –5° to +50°C (23°F to 122°F.)
- Storage Temperature: –10° to +55°C (14°F to 131°F.)
- Humidity: 30% to 85%, RHL non–condensing
- Weight per single speaker (including mounting bracket)
- 3.9kg / 8.6lbs
- REGULATORY
- Safety
- IEC 62368 (CB) / CE LVD
- UL 62368-1
- BIS (India)
- RCM
- EMI
- FCC / IC
- Environmental
- RoHS, REACH, WEEE
- IP Rating: IP66
- Safety
