KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer

KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer
KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer
KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer - Extra Image 1KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer - Extra Image 2KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer - Extra Image 3
KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer
KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer
KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer



KanexPro Mini 2-input Audio Amplifier with Mic Mixer

Class D amplifier with EQ control and MIC mixer function

Free Shipping & Free 3-Year Warranty

Free Lifetime Telephone, CHAT, TEXT, FAX & Email Tech Support

Part # AP2DBL
Usually ships the same business day
Today's Price: $229.95
Ask Our WolfPack Experts

Features

KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer

The KanexPro Mini Audio Amplifier is a quarter-rack width digital amplifier (Class D) with equalizer control and Mic mixer. It’s a simple yet powerful device delivering 2x20 Watts@4Ohm default output with built-in volume/ bass feature. It also supports dual mono-output with 2 stereo audio selectable inputs. The Microphone mixer includes independent volume control with balance switching. Supports balanced/ unbalanced signals.

This Mini Audio Amplifier is mainly used during lectures, house of worship centers and various musical events where mic mixing together with equalizing audio is critical.

KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer Features:

  • Fast switching audio amplifier
  • 2x20 Watt@4Ohm as the default amplifier output
  • Bridge connection supported by switching the amplifier to be 1x40Watt@8Ohm
  • Supports Dual-mono output
  • Built-in Microphone mixer (separately controllable)
  • Line audio output, with volume controllable.
  • MIC input supports 48V phantom power
  • MIC port with balanced switching suppress
  • Supports balanced/ unbalanced signals
  • Supports Ducking power technology
  • Ultra low inrush current
  • Two stereo audio inputs, switchable by button, remote or RS232.
  • Volume/Bass/Treble controllable by buttons or RS232
  • Optional control by IR remote
  • Convection cooled, antistatic case design
  • LED indicator, for power and operating status
  • Internal Universal power adaptable (100-240 volt AC, 50/60Hz)

Why not buy this KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer today?

Specs

KanexPro AP2DBL Mini 2-input Audio Amplifier with Mic Mixer Specifications:

  • Audio Input:
    • Input 2 stereo audio
    • 1 MIC
  • Audio Output:
    • 1 amplifier
    • 1 stereo audio
  • Input Connector:
    • 2 RCA
    • 1 x 3.5mm jack
    • 1 captive screw
  • Output Connector:
    • 1 captive screw
    • 1 x 3.5mm jack
  • Input Impedance for Inputs 1&2: >10KΩ
  • Output Impedance: 50Ω/stereo, 4~8Ω/Amplifier
  • Audio General:
  • Frequency Response:
    • Input: 20Hz ~ 20KHz
    • Output: CMRR >70dB@20Hz~20KHz
  • Signal to Noise Ratio: 80dB at maximum output
  • Bandwidth: 20Hz ~ 25KHz
  • Stereo Channel Separation:
    • Input: >75dB@20Hz to 20KHz
    • Output: THD + Noise 1%(1KHz), 0.3%(20KHz) at nominal level
  • Voltage Gain: 32dB
  • Mic Input Impedance: 48V: 35 Kilo Ohms
  • Mic: 10 Kilo Ohms
  • Line: 75 Kilo Ohms
  • Mic Audio Detection Delay: < 1ms
  • Common Mode Rejection Ratio: >70dB (20Hz- 20KHz)
  • Power Output: 2x20 Watts (4 Ohms)
  • Control:
    • RS-232 Serial
    • 9-pin female D connector
  • Pin Configurations:
    • 2 = TX, 3 = RX, 5 = GND
  • IR: Optional IR Kit & remote control - please check with Sales
  • TCP/IP control through TCPRS2 (Optional)
  • Power consumption: 3.6 Watts
  • Dimensions: 1.5"x3.78"x3.45" (HWD)
  • Weight: 0.67 lbs (0.3Kg)
  • Warranty: 3 Year Parts & Labor
  • Industry Standards & Certifications:
  • CE, FCC, UL certified
Reviews

Similar

Make Offer

Videos

3D

Q/A

Warranty

Warranty HDTV Supply includes a 3 Year Limited Warranty on all Kanex Pro products. The warranty states that (a) its products (the will perform substantially in accordance with the accompanying written materials for a period of 3 years from the date of receipt and (b) that the Product will be free from defects in materials & workmanship under normal use & service for a period of 3 years. In order to get a warranty replacement for a defective item, HDTV Supplys and Kanex Pros Support Team will verify the product is eligible for warranty. An RMA number will then be issued. Shipped replacements will be in like new conditions, tested and all components included.

HDTV Supply also sells a 5 Year Extended U.S. Warranty for this Long-Runner HDMI 100M Extender. Please go to Extended Warranties or see the above Options to purchase it.
