Intelix RF-F Broadband Video Balun
Intelix RF-F Broadband Video Balun
passively transmits broadband (RF) video over unshielded twisted pair cabling, such as Cat 5e. Used in pairs, the RF-F transmits video up to 330 feet, providing a low-cost versatile cabling solution which uses a building's existing structured cabling system.
Intelix RF-F Broadband Video Balun Features:
- Male F-type to RJ45 connectivity
- Transmits video and audio up to 330 feet
- Supports CATV channels 2-150, VHF channels 2-13
- Supports FM broadcast band
- Used in pairs
Why not buy this Intelix RF-F Broadband Video Balun today?
Intelix RF-F Broadband Video Balun Specification:
| I/O Connections | |
| Video | One (1) Male F Connector |
| Twisted Pair | One (1) 8P8C port (RJ45) |
| Supported Video | |
| Maximum Distance via Cat 5e | 300 ft. |
| RJ45 Pin Configuration | Pins 7 and 8: Video |
| Video Bandwidth (3 dB) | 5 MHz to 900 MHz |
| Impedance | 75 ohms |
| Supported Video Channels | CATV channels 2-150 VHF channels 2-13 FM broadcast band |
| Insertion Loss | <9 dB: 5-10 MHz <3 dB: 10-900 MHz |
| Return Loss | >10 dB: 15-370 MHz >7 dB: 370-770 MHz >10 dB: 770-900 MHz |
| Common Mode Rejection | -20 dB or higher at 5-900 MHz |
| Chassis and Environmental | |
| Enclosure | Black ABS plastic |
| Dimensions | 63 mm x 23 mm x 25 mm (1.6" x 2.8" x 1") |
| Shipping Weight | 0.09 kg (0.20 lbs) |
| Operating Temperature (Environment) | 0˚ to +40˚C (+32˚ to +104˚F) |
| Operating Humidity (Environment) | 20% to 90%, Non-condensing |
| Storage Temperature (Environment) | -10˚ to +60˚C (+14˚ to +140˚F) |
| Other | |
| Regulatory | CE, RoHS |
| Standard Warranty | 2 Years |
| Included Accessories | Installation Guide |
