This Gefen EXT-VGAKVM-LANRX VGA KVM over IP Receiver provides high-performance remote access to all your VGA sources over a standard Gigabit Local Area Network.
This powerful receiver unit seamlessly extends VGA, USB, bi-directional analog audio, RS-232, and IR signals up to 330 feet (100 meters) from any compatible Sender unit on the network.
By combining multiple receivers with any of Gefen's HDMI, DVI, or VGA senders, you can create a massively scalable virtual crosspoint matrix with over 65,000 units.
Ideal for large-scale remote workstation access and professional digital signage applications, the VGA KVM over IP Receiver offers a flexible and intuitive solution for your AV and IT infrastructure.
Gefen EXT-VGAKVM-LANRX VGA KVM over IP Receiver Features:
- High-Resolution Video Extension: Supports resolutions up to 1920 x 1200 (WUXGA), ensuring sharp, crystal-clear video quality for professional applications.
- Flexible Signal Distribution: Extends VGA, USB, RS-232, bi-directional stereo analog audio, and IR over your IP network using a standard Gigabit Local Area Network.
- Massively Scalable KVM Matrix: Any Receiver can access any Sender on the network, supporting a total of just over 65,000 Sender and Receiver units to create a custom virtual matrix.
- Integrated Gigabit Ethernet Switch: Features a built-in three-port Gigabit Ethernet switch, allowing for the connection of computers and other IP-enabled devices directly to the receiver.
- High-Speed USB 2.0: Delivers two USB 2.0 ports for connecting keyboards, mice, and other peripherals, with data rates up to 480 Mbps and backward-compatibility with USB 1.1.
- Intuitive Web Interface: A built-in Web server interface provides simple and intuitive control for all features, setup, and configuration.
- Cross-Platform Compatibility: Works with any combination of Gefen KVM over LAN Senders and Receivers, including HDMI, DVI, and VGA models.
Why not buy this Gefen EXT-VGAKVM-LANRX VGA KVM over IP Receiver today?
Gefen EXT-VGAKVM-LANRX VGA KVM over IP Receiver Specifications:
- Video Output Connector: (1) VGA HD-15, female
- Mic Input: (1) 3.5mm mini-stereo jack
- Line Output: (1) 3.5mm mini-stereo jack
- USB Device Connectors: (2) USB Type A, female
- RS-232 Connector: (1) DB-9, male
- IR Extender Input: (1) 3.5mm mini-stereo jack
- Ethernet Connectors: (3) RJ-45, shielded
- Controls: (1) Switch button (tact-type), (1) Reset button (recessed)
- Indicators: (1) Link LED (green), (1) Power LED (blue)
- Power Supply: 5V DC, locking
- Power Consumption: 10W (maximum)
- Dimensions (W x H x D): 8.4" x 1.7" x 4.5" (213mm x 43mm x 113mm)
- Shipping Weight (EXT-VGAKVM-LANRX): 4.6 lbs. (2.0 kg)
Why not buy this Gefen EXT-VGAKVM-LANRX VGA KVM over IP Receiver today?
