This DVDO USBC-HDMI-PS-21 4K 2x1 Presentation Switcher with USB-C & HDMI Inputs is a 2x1 presentation switcher with 1 HDMI & 1 USB-C inputs and 1 HDMI output with a separate analog audio output.
It supports video resolutions up to 4K60 at 18Gbps as well as HDR.
The USB-C input supports DisplayPort 1.4 Alt Mode up to 4K60 video, USB 3.2 Gen 1 up to 5Gbps data transfer and can provide up to 100W charging when the USB-C charge port next to it is powered by an external power adapter.
The unit includes 4 USB 3.0 Device ports for peripherals such as camera, hard disk, keyboard and mouse that can connect to both inputs / host devices.
It features a Hotkey function, allowing to switch between both connected computers without reaching for buttons or the remote.
It can be controlled over RS-232, IR, CEC or via the front panel button.
DVDO USBC-HDMI-PS-21 4K 2x1 Presentation Switcher with USB-C & HDMI Inputs Features:
- HDMI 2.0, HDCP 2.3 and DP 1.4 compliant
- Supports Ultra-wide screen & resolutions up to 4K@60Hz or 2K@60Hz/144Hz
- Two inputs: 1 x HDMI + 1 x USB-C
- One HDMI output with separate L/R audio output
- USB-C input supports DisplayPort 1.4 Alt Mode up to 4K@60Hz video, USB 3.2 Gen 1 up to 5Gbps data transfer
- USB-C charging port supports PD3.0 with 100W charging
- Advanced hardware/software design and production ensure zero video and audio latency
- Four USB 3.0 Device ports allow sharing of peripherals such as webcam, printer, scanner, hard disk,… between computers with data transfer rate up to 5Gbps
- HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
- Same set of keyboard, mouse & monitor can control 2 computers
- Fast video switching & seamless keyboard/mouse switching
- Each input port has an EDID emulator to provide the correct information for the PC
- Supports hot plug, allowing devices to connect / disconnect with KVM at any time
- Auto switching or switching via front panel button, keyboard/mouse hotkeys, IR remote control or RS-232
- CEC support
Why not buy this DVDO USBC-HDMI-PS-21 4K 2x1 Presentation Switcher with USB-C & HDMI Inputs today?
DVDO-USBC-HDMI-PS-21 User Manual
DVDO-USBC-HDMI-PS-21 Datasheet
HDTV Supply partners with DVDO to sell and support all DVDO products
Why not buy this DVDO USBC-HDMI-PS-21 4K 2x1 Presentation Switcher with USB-C & HDMI Inputs today?
1.How does EDID selection work on this switcher?
A: EDID is chosen by a 4‑pin DIP switch on the transmitter and can either learn the lower resolution of TX and RX or select several built‑in and custom EDIDs.
2.Can I share USB peripherals like a webcam or keyboard between the two hosts?
A: Yes; the kit provides USB device ports on both transmitter and receiver so multiple peripherals can be shared between connected hosts.
3.Does the system support automatic or manual input switching and what triggers are supported?
A: The transmitter supports both auto and manual switching, with trigger modes selectable for 5V or TMDS detection and also supports CEC, RS‑232, GUI and front‑panel control.
4.Can I downscale outputs from the transmitter or receiver automatically?
A: Yes; the GUI and RS‑232 provide settings to enable or disable auto downscale on the transmitter or receiver HDMI outputs.
5.Is bidirectional Power over Cable (PoC) supported over the HDBaseT link?
A: Yes; the system supports HDBaseT 3.0 with bidirectional 48V PoC.
6.Can I upgrade firmware on the transmitter and receiver over RS‑232?
A: Yes; the manual describes upgrading transmitter and receiver MCU firmware via the transmitter RS‑232 port using the provided upgrade tool at 115200 baud.
