This Atlona AT-HDR-CAT-2 2-Output 4K HDR HDBaseT Distribution Amplifier is a high dynamic range (HDR) distribution amplifier with one HDMI® input and two HDBaseT™ outputs. Each output transmits 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling plus support for HDR formats, multi-channel audio, control signals, and power up to 130 ft. (40 m) or 1080p up to 230 ft. (70 m) over Category 6/6A cable.
The HDR-CAT-2 features sophisticated integration capabilities designed for commercial AV distribution applications including HDMI signal pass-through, audio de-embedding, EDID management, CEC display control, RS-232 and IR control extension, remote power for receivers, and HDBaseT link testing. It offers compatibility with any TCP/IP or RS-232 control system and is housed in a low-profile enclosure with external universal power supply. The HDR-CAT-2 is ideal for sending HDR and 4K/60 4:4:4 content to AT-HDR-EX-70C-RX receivers.
The HDR-CAT-2 is part of a family of 4K HDR HDBaseT distribution amplifiers that also includes the HDR-CAT-4 four output, HDR-CAT-8 eight output, and HDR-CAT-4ED four output extended distance models.
Atlona AT-HDR-CAT-2 2-Output 4K HDR HDBaseT Distribution Amplifier Feature:
- 4K HDR distribution amplifier with one HDMI input and two HDBaseT outputs
- Pass-through HDMI output to support local monitor
- 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling
- Supports HDR10, HLG, and Dolby® Vision™ HDR formats
- Features visually lossless compression with no latency to enable HDR and 4K/60 4:4:4 video signal extension over HDBaseT.
- HDBaseT outputs extend AV, control signals, and power up to 130 feet (40 meters) for 4K HDR or 230 feet (70 meters) for 1080p with Category 6/6A
- Bidirectional RS-232 and IR control extension for each output
- Remotely powers compatible receivers over HDBaseT
- CEC display control sends display power on/off commands to the pass-through HDMI output and HDBaseT receiver HDMI outputs using the power button, IP, or RS-232
- Audio de-embedding to balanced analog output with volume control for integration with a separate audio system
- HDBaseT link test verifies cable, termination, and link quality for more reliable installations
- Multi-channel audio pass-through
- Cascade up to 8 units to expand system without compromising performance
- Compliant with HDCP 2.2, the latest specification for passing protected content between devices
- Manages EDID communications with the source through a display’s EDID or internally stored EDID
- Intuitive GUI-based configuration using integrated web server
- Flexible control options via TCP/IP, RS-232, and IR with Atlona Velocity™ or third-party control systems
- Easy to configure and manage with Velocity Device Manager
- Front panel includes LEDs for power, HDBaseT link, and HDMI signal status information as well as buttons for power and EDID control
- Compatible with the AT-HDR-EX-70C-RX receiver for 4K/60 4:4:4 HDR and AT-UHD-EX receivers for 4K/60 4:2:0
- Low-profile enclosure for easy installation under a table or in furniture
- Included accessories – surface mounting hardware, power supply, and installation guide
Why not buy this Atlona AT-HDR-CAT-2 2-Output 4K HDR HDBaseT Distribution Amplifier from HDTV Supply today?
Atlona AT-HDR-CAT-2 2-Output 4K HDR HDBaseT Distribution Amplifier Specifications:
- Video
- Signal: Input – HDMI
- Signal: Output – HDMI / HDBaseT
- Copy Protection: HDCP 2.2
- Pixel Clock: 600 MHz
- UHD / HD / SD Resolutions
- 4096×2160 (DCI) @ 24/25/30/50/60 Hz
- 3840×2160 (UHD) @ 24/25/30/50/60 Hz
- 1920×1080p @ 23.97/24/25/29.97/30/50/60 Hz
- 1920×1080i @ 50/60 Hz
- 1280×720p @ 30/50/60 Hz
- 720×576p @ 50 Hz
- 720×576i @ 25/50 Hz
- 720×480p @ 60 Hz
- 640×480p @ 60 Hz
- VESA Resolutions
- 2560×1600 @ 60 Hz (RB)
- 2048×1536 @ 60 Hz
- 2048×1200 @ 60 Hz
- 2048×1080 @ 60 Hz
- 1920×1200 @ 60 Hz (RB)
- 1920×1080 @ 60 Hz (RB)
- 1680×1050 @ 60 Hz
- 1600×1200 @ 60 Hz
- 1600×900 @ 60 Hz
- 1440×900 @ 60 Hz
- 1400×1050 @ 60 Hz
- 1366×768 @ 60 Hz
- 1360×768 @ 60 Hz
- 1280×1024 @ 60 Hz
- 1280×800 @ 60 Hz
- 1280×768 @ 60 Hz
- 1280×720 @ 60 Hz
- 1024×768 @ 60 Hz
- 800×600 @ 60 Hz
- 640×480i @ 29.97/30 Hz
- Color and HDR
- Color Space: YUV, RGB
- Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
- Color Depth: 8-bit, 10-bit, 12-bit
- HDR: Up to 4K HDR10 @ 60 Hz, 4K Hybrid-Log Gamma (HLG) @ 60 Hz, and 4K Dolby® Vision™ @ 60 Hz
- Audio – HDMI / HDBaseT Pass-Through Formats
- PCM 2.0
- LPCM 5.1
- LPCM 7.1
- Dolby® Digital
- Dolby Digital Plus™
- Dolby TrueHD
- Dolby Atmos®
- DTS® Digital Surround™
- DTS-HD Master Audio™
- DTS:X®
- Bit Depth: Up to 24 bits
- Analog Audio
- Format: Stereo 2-Channel
- Balanced Output: +4 dBu nominal gain, +19 dB headroom
- Frequency Response: 20 Hz to 20 kHz, ± 0.5 dB
- THD+N: < 0.006% at 20 Hz to 20 kHz
- SNR: > 105 dB at 1 kHz, zero clipping @ 0 dBFS, unweighted
- Sample Rate: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
- Ethernet
- Port: 1 × RJ45
- Standards and Protocols: HTTP, Telnet
- Speeds: 10/100 Mbps
- Addressing: DHCP, Static – selectable through front panel, IP and RS-232 commands, and built-in web server
- RS-232
- Port: 1 × 5-pin captive screw; 1 × 10-pin captive screw
- Use: Unit and external device control and configuration
- Baud Rates: 2400, 4800, 9600, 19200, 38400, 57600, 115200
- Data Flow: Bidirectional
- IR
- Port: 1 × 5-pin captive screw; 1 × 10-pin captive screw
- Use: Pass-through from control system to sink device; pass-through from viewing location to source
- Frequency Range: 30 kHz to 60 kHz
- CEC
- Ports: 1 × HDMI OUT, Type A, 19-pin female; 2 × RJ45 (HDBaseT OUT)
- Triggering: Through IP, RS-232, and built-in web server
- Resolution / Distance
- HDMI IN/OUT: 4K/UHD – 15 feet (5 meters); 1080p – 30 feet (10 meters)
- CAT5e/6: 4K/UHD – 115 feet (35 meters); 1080p – 200 feet (60 meters)
- CAT6a/7: 4K/UHD – 130 feet (40 meters); 1080p – 230 feet (70 meters)
- Buttons and Indicators
- Buttons: POWER, EDID – 2 × momentary, tact-type
- Indicators: HDMI IN/OUT, HDBaseT (1 – 2), LOCK, INT, LEARN – 7 × LED, blue
- Connectors
- HDMI IN: 1 × Type A, 19-pin female
- HDMI OUT: 1 × Type A, 19-pin female
- HDBaseT OUT: 2 × RJ45
- LAN: 1 × RJ45
- AUDIO OUT: 1 × 5-pin captive screw
- RS-232 / IR: 3 × 5-pin captive screw
- FW: 1 × USB-C
- DC 48V: 1 × 2-pin captive screw
- Environmental
- Operating Temperature: +32 to +122°F / 0 to +50°C
- Storage Temperature: -4 to +140°F / -20° to +60°
- Operating Humidity (RH): 20% to 90%, non-condensing
- Power
- Consumption (with 2 PoE): 38.3 W
- Idle Consumption (no PoE): 8.3 W
- BTU/h: 28.3
- External Power Supply: 100 – 240 V AC, 50/60 Hz
- Output: 48 V / 1.25 A DC
- Dimensions (H x W x D)
- Unit: 1.02 × 8.62 × 5.98 inches / 26 × 219 × 152 millimeters
- Power Supply (AT-PS-4812-C): 1.34 × 1.85 × 4.41 inches / 34 × 47 × 112 millimeters
- Weight
- Device: 1.76 pounds / 0.8 kilograms
- Certification and Compliance
- Device: CE, RoHS, FCC
- Power Supply: CE, FCC, UL, CUL, TUV-GS, CB, PSE, CCC
- NDAA-899: Yes
