The HDTV Supply HDTV-B88-H100 is a 4K 60 Hz 8x8 HDMI and HDBaseT Matrix Switcher that allows seamless switching of 8 HDMI sources to 2 HDMI 2.0 outputs and 6 HDBaseT outputs. It supports resolutions up to 4K@60Hz (YUV 4:4:4) and extends signals up to 330 feet at 1080p or 295 feet at 4K using a single CAT6/6a/7 cable. Flexible control options include front panel buttons with an OLED display, IR remote, RS-232, and Web GUI.
This switcher features an independent audio matrix that allows selection from external audio, HDMI input audio, or ARC audio. It also supports audio volume, mute, and delay adjustments via Web GUI. Two-way IR control is included (excluding the 2 local HDMI outputs), with IR following the HDMI video path for efficient system integration.
The product provides an intuitive set of front panel with OLED screen and supports front panel button, IR remote, RS-232 or Web GUI control ways.
4K 60 Hz 8x8 HDMI and HDBaseT Matrix Switcher Features:
- HDMI 2.0b, HDCP 2.2 and HDCP 1.4 compliant
- Support 8 HDMI sources to 2 independent HDMI outputs and 6 HDBaseT outputs
- Video resolution up to 4K@60Hz (YUV 4:4:4) for all HDMI ports
- All HDMI outputs support audio embed and de-embed
- All HDBaseT ports support 4k@60Hz (YUV 4:4:4) and distance up to 295 feet / 90 meters or 1080p@60Hz and distance up to 330 feet / 100 meters via CAT6/6a/7 cable
- All HDBaseT support feature: High-Definition video and audio, 24V PoC (Transmitter is powered and Receiver don't need to power supply) and control (Bi-directonal IR & RS-232 pass-through)
- HDMI Pass-through audio up to 7.1 channels of high definition audio (LPCM, Dolby TrueD and DTS-HD Master Audio)
- Built-in independent audio matrix with volume, mute and audio delay adjustment (PCM 2.0 only)
- HDR, ARC, CEC and smart EDID managment are supported
- Control via front panel button, IR remote, RS-232 and Web GUI
- 2U rack mounted design with aluminum housing on the front
Why not buy this 4K 60 Hz 8x8 HDMI and HDBaseT Matrix Switcher today?
4K 60 Hz 8x8 HDMI and HDBaseT Matrix Switcher Specification:
- Technical
- HDMI Compliance: HDMI 2.0b
- HDCP Compliance: HDCP 2.2 and HDCP 1.4
- Video Bandwidth: 18Gbps
- Video Resolution: Up to 4K2K@50/60Hz (YUV 4:4:4), 4K2K@24/30Hz, 1080p@120Hz and 1080p 3D@60Hz, 1080i@60Hz
- Color Space: RGB, YCbCr 4:4:4, YUV 4:4:4, YCbCr 4:2:2/4:2:0
- Color Depth: 8-bit, 10-bit, 12-bit (1080p@60Hz), 8-bit (4K2K@60Hz)
- HDMI Audio Formats (Pass-through): LPCM 2/5.1/7/1CH, Dolby Digital, DTS 5.1, Dolby, Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
- Audio Formats (Audio Matrix): PCM 2.0, 32K/44.1K/88.2K/96K/192K, 16/20/24-bit
- Audio Volume (Audio Matrix): -20dB ~ 0dB
- L/R Audio Formats: Analog Stereo 2CH
- Infrared: 20KHz ~ 60KHz
- ESD Protection: Human-body Model: +/-8kV (Air-gap discharge) , +/-4kV (Contact discharge)
- Connections
- Matrix
- Input Ports
- 8xHDMI Type A [19-pin female]
- 9xIR INPUT [3.5mm Stereo Mini-jack]
- 1xIE EXT [3.5mm Stereo Mini-jack]
- 2xL/R Audio INPUT [3.5mm Stereo Mini-jack]
- 2xOptical Audio INPUT [S/PDIF]
- 2xCoaxial Audio INPUT [RCA]
- Output Ports
- 2xHDMI Type A [19-pin female]
- 9xIR OUTPUT [3.5mm Stereo Mini-jack]
- 8xL/R Audio OUTPUT [3.5mm Stereo Mini-jack]
- 8xCoaxial Audio OUTPUT [RCA]
- 6xHDBaseT OUTPUT [RJ45]
- Control Ports
- 6xRS-232 [Phoenix jack]
- 1xLAN [RJ45]
- 1xRS-232 [DB9]
- HDBaseT Receiver
- Input Ports
- 1xHDBaseT IN [RJ45]
- 1xIR IN [3.5mm Stereo Mini-jack]
- 1xOPTICAL IN [S/PDIF]
- Output Ports
- 1xHDMI Type A [19-pin female]
- 1xIR OUT [3.5mm Stereo Mini-jack]
- Control Ports
- 1xRS-232 [Phoenix jack]
- 1xLAN [RJ45]
- 1xSERVICE [Micro USB]
- Mechanical
- Housing: Metal Enclosure
- Color: Black
- Dimensions: TX: 483mm (W)x373mm (D)x88.6mm (H), RX: 171.8mm (W)x97mm (D)x20mm (H)
- Weight: TX: 6.7kg, RX:333g
- Power Supply: 100~240V AC 50/60Hz Power cable
- Power Consumption: 85W (Max)
- Operating Temperature: 0˚C ~ 40˚C / 32˚F ~ 104˚F
- Storage Temperature: -20˚C ~ 60˚C / -4˚F ~ 140˚F
- Relative Humidity: 20~90% RH (non-condensing)
