This Zenty ZT-338 Modular Matrix 4K@60Hz HDBaseT 328ft Receiver uses HDBaseT technology, and can receive signals with audio de-embedded, bi-directional IR and RS232 signal over single STP Cat5e/6/7. For 1080P 60Hz resolution, it can transmit to a distance of 330ft., and for 4K 60Hz up to 220ft.
Zenty ZT-338 Modular Matrix 4K@60Hz HDBaseT 328ft Receiver Features:
- Uses the HDBaseT technology extension over single CAT5e/6/7 cable
- Extend 4K/60(4:2:0) video & IR & RS232 Control
- Transmission distance up to 70/100m 220/330ft(1080P60) or 35/70m 110/220ft(4K60)
- HDMI2.0 and HDCP2.2
- RS232 and IR signal transmission, POC function
- Support DIP switch scaling and 3.5mm audio de-embed
Why not buy this Zenty ZT-338 Modular Matrix 4K@60Hz HDBaseT 328ft Receiver from HDTV Supply today?
Zenty ZT-338 Modular Matrix 4K@60Hz HDBaseT 328ft Receiver Specification:
- Description: HDMI 70/100m HDBaseT Receiver
- Input Port: 1 x HDBaseT
- Output Port: 2 x HDMI, 1 x RS232, 1 x IR TX, 1 x IR RX
- Standard Protocol: Supports HDMI 2.0 and compatible with HDCP 2.2
- Resolution: 1920x1200, 1680x1050, 1360x768, 1280x800, 1920x1080, 1600x900, 1366x768, 1280x720, 1024x576, 4096x2160@30Hz, 3840x2160@30Hz, 3840x2160@60Hz
- Bandwidth: 10.2 Gbps
- Distance: 1080p60 up to 220/330 ft, 4K60 (4:2:0) up to 110/220 ft
- Dimensions: 152 x 102 x 27 mm
- Weight: 0.35 kg
- Power: AC 100–240V 50/60Hz, DC 12V 1.5A
- Power Consumption: ≤10W
- Working Temperature: 0°C ~ 50°C
- Storage Temperature: -20°C ~ 55°C
