This Thor Broadcast H-STB-IP Compact IP Decoder Set Top Box is becoming more and more common. It is simple now days to encode high definition video into an IP stream that can be carried over any standard Ethernet network equipment. These IP Set Top Boxes are designed to make remote display of network content simple. These units can accept any standard IP network stream and decode it to HDMI. The units support both MPEG-2 and MPEG-4/H.264 codecs, and are compatible with both multicast and unicast streams. These are low cost IP decoders designed for large rollouts with many displays. As many as 250 decoders can be used on a single closed network to display IP content. Contact Thor today for help designing your IP content distrubution system.
Thor Broadcast H-STB-IP Compact IP Decoder Set Top Box Features:
- Compact Form Factor easily mounts behind displays
- High Definition HDMI output with HDCP support
- Supports both MPEG-2 and MPEG-4/H.264 Codecs
- Compatible with both Unicast and Multicast Transport Streams
- Supports up to 250 displays on a single subnet
Why not buy this Thor Broadcast H-STB-IP Compact IP Decoder Set Top Box today?
Thor Broadcast H-STB-IP Compact IP Decoder Set Top Box Specifications:
- 5V DC at 1.5A via external power supply Less than 8W typical usage (external supply input voltage 100-240V AC 50-60Hz 3A max)
- Codecs: MPEg-2 MP@HL MPEg-4 pt10 AVC/H.264 HP@L4
- Video Resolutions: up to 720p and 1080i. Displays up to 1080p
- Graphics Resolutions: HD graphics up to 1280x720
- Audio: Analog stereo audio out. Stereo and Dolby 5.1 surround via S-PDIF and HDMI. Dolby Digital+ pass through to external decoder
- Security: Wide selection of DRM and Conditional Access support. HDCP on HDMI Macrovision on SD outputs (option)
- Memory: 128MB Flash, 256MB RAM
- Front Panel LED's: Power on /IR command received (Red)
- Operating Environment: ETS 300-019-1-3 Class 3.1
- EMC Conformance: FCC Part 15 class B. 2004/108/EC E n55022
- Safety Approvals: CAn/ CSA-C22.2 no. 60950-1-03 En60950
- Operating Temperature: 0°C (32°F) to 40°C (104°F)
- Storage Humidity: 5% to 95% RH (non-condensing)
- Size and Weight: 140mm x 114mm x 40mm. 320g
(excluding accessories and packaging)
Why not buy this Thor Broadcast H-STB-IP Compact IP Decoder Set Top Box today?
What video codecs does the H-STB-IP support?
A: It supports MPEG-2 and MPEG-4/H.264 codecs, including MPEG-2 MP@HL and MPEG-4 AVC/H.264 HP@L4.
Will the H-STB-IP decode multicast and unicast streams?
A: Yes; it is compatible with both multicast and unicast transport streams.
What HDMI video resolutions will the H-STB-IP output?
A: It decodes up to 720p and 1080i and can display up to 1080p on connected displays.
What audio outputs and formats does the H-STB-IP provide?
A: It provides analog stereo output, stereo and Dolby 5.1 via S-PDIF and HDMI, and supports Dolby Digital+ pass-through to an external decoder.
Does the H-STB-IP support HDCP or other content protection?
A: Yes; it supports HDCP on HDMI and lists Macrovision on SD outputs as an option.
What memory does the H-STB-IP include?
A: It includes 128MB of flash memory and 256MB of RAM.
What operating and regulatory standards are listed for the H-STB-IP?
A: Operating environment is ETS 300-019-1-3 Class 3.1; EMC and safety listings include FCC Part 15 Class B, 2004/108/EC EN55022, and CAN/CSA-C22.2 no. 60950-1-03 / EN60950.
What front-panel indication does the H-STB-IP provide?
A: A front panel LED indicates power on and reception of IR commands (red).
Can I mount the H-STB-IP behind a display and how big is it?
A: Yes; it has a compact form factor for behind-display mounting and measures 5.51 inches x 4.49 inches x 1.57 inches (5.51" x 4.49" x 1.57").
How heavy is the H-STB-IP for rack or bracket considerations?
A: The unit weighs 0.71 pounds, which is 0.71 pounds.
