Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232

Smart-AVI

Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232
Price: $1,399.00
Today's Price: $1,189.15
Part Number:
Smart-AVI-P2P-KHG100
UPC:
657477052126
Condition:
New
Availability:
In Stock
1:
Supporting USB 2.0 Peripheral
2:
Infrared (IR) & RS-232 Extension
3:
Supports HDMI Video Upto 4K @ 30Hz
4:
Analog Audio Extension
5:
EDID Learning & Management
6:
Free USA Shipping
7:
1-Year Smart-AVI Warranty
8:
Ships with the Latest Firmware
9:
International Shipping - Call

This Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232 extends your HDMI-based workstation's console point-to-point or over an IP network (via a 1Gb Ethernet switch) up to 328 feet (100 m) per segment.

Supporting flexible Direct, Matrix, and SaviGate modes, P2P-KHG100 adapts to your installation needs – from simple point-to-point extensions to full multi-user managed environments – over CATx.

High-Performance KVM-over-IP Extension and Matrix-Switching Solution Experience seamless, real-time remote access with P2PKVM series, a high-performance KVM-over-IP extender and matrix solution.

P2PKVM series is a plug-and-play IP KVM solution delivering 4K video, USB, audio, and optional RS232 and IR control over a standard 1Gb Ethernet network with flexible extension and switching modes.

Designed for mission-critical environments, it delivers ultra-low latency, high-resolution video, and secure connectivity over IP networks, ensuring efficient system control and flexibility.

SmartAVI's P2PKVM series is a high-performance, IP-based KVM platform designed to scale effortlessly from simple point-to-point control to fully matrixed KVM environments.

Supporting up to 64 servers and 8 users out of the box, the system expands to an enterprise-class 256-server / 32-user matrix when integrated with the SaviGate P2PManager, delivering exceptional flexibility for control rooms, data centers, and mission-critical operations.

Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232 Feature:

  • Supports HDMI video up to 4K @ 30Hz, or 1080p @ 60Hz
  • Transparent USB 2.0 extension for USB peripherals
  • Analog audio extension
  • RS-232 extension
  • Infrared (IR) extension
  • Selectable Direct, Matrix, and Savigate modes via web interface
  • Up to 328 feet (100 m) extension distance over CATx
  • Ultra-low latency with JPEG2000 compression
  • Plug-and-play installation
  • EDID learning and management
  • Savigate controller support for centralized management

Why not buy this Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232 from HDTV Supply today?

Smart-AVI P2P-KHG100 IPGard Point to Point Single Head HDMI CAT5& Fiber Extender Group with USB 2.0, Audio and RS232 Specifications:

  • Video
    • Format: HDMI 1.4
    • HDCP 1.4 compliant
    • Video Bandwidth: Up To 10.2 Gbps
    • Video Resolution: Up To 4K @ 30 Hz, 1080p @ 60 Hz
    • EDID Storage and emulation
    • Compression: Ultra-low latency JPEG2000
    • Connector: 1x HDMI (19-pin female)
  • Audio
    • Format: PCM 2.0/2.1/5.1/7.1, Dolby Digital 5.1 ch, Dolby Digital Plus, Dolby TrueHD, DTS 5.1 ch
    • Input/Output Interface: 3.5 mm stereo aux socket (female)
  • USB
    • Transmitter Connector: 1x USB Type-B
    • Receiver Connectors: 4x USB Type-A
    • USB Version: USB 2.0, USB 1.1, USB 1.0 compatible
    • Keyboard and mouse emulation
  • System
    • Transmission Distance: Up to 328 feet (100 m) over CATx
    • RS-232: Pass-through up to 115200
    • Management: Selectable Direct, Matrix, SaviGate support for centralized management (sold separately - see listing below)
  • Environment/Power
    • Operating Temperature: 32~113°F (0~45°C)
    • Operating Humidity: 10~90%, non-condensing
    • Power: 12 V DC, 3 A (power supply included)
    • Reliability (MTBF): 135,540 Hours (MIL-HDBK-217F (N2) Parts Count Prediction Calculator)
    • Certification: CE, FCC, RCM, UL
  • Physical
    • Dimensions (W x D x H): 4.25 x 3.7 x 1.6 in.
    • Weight: 1 lb (0.45 kg)
    • ESD Protection: Protection per IEC 61000-4-2 standard at ±30 kV Air and ±30 kV contact
