This QSC Q-SYS NM-T1 Tabletop Beamforming Microphone provides flexible networked audio capture for Q-SYS collaboration spaces. Its four software-configurable beamforming zones provide up to 360° coverage around the microphone. PoE, touchless mute, onboard controls, and Q-SYS integration simplify installation and operation.
The NM-T1 uses advanced beamforming technology with 16 MEMS microphone elements and a 3-9 ft (1-3 m) pickup range. Its four independent zones can be configured within Q-SYS Designer Software to provide coverage where needed.
Four touch-sensitive mute buttons control the active microphone beams, while the dedicated call button and programmable user button provide additional room control. A proximity sensor enables touchless mute or unmute with a hand gesture, and the programmable RGB light ring can indicate mute and call status.
The NM-T1 connects directly to Q-LAN through a single RJ45 connection and receives power through IEEE 802.3af Type 1 Class 2 PoE. Q-SYS Call Sync can synchronize controls and LED status across compatible Q-SYS devices.
QSC Q-SYS NM-T1 Tabletop Beamforming Microphone Features:
- Native Q-SYS Network Beamforming Microphone
- Four Software-Configurable Beamforming Zones
- Up to 360° Coverage
- 3-9 ft (1-3 m) Pickup Range
- 16 MEMS Microphone Elements
- Superdirective Polar Pattern
- Touchless Mute via Proximity Motion Sensor
- Four Touch-Sensitive Mute Buttons
- Touch-Sensitive Call Button
- Programmable User Button
- Programmable RGB Light Ring
- Q-SYS Call Sync Compatible
- Q-SYS Designer Software Integration
- Q-SYS Reflect Management Support
- Single-Cable Q-LAN and PoE Connectivity
- IEEE 802.3af Type 1 Class 2 PoE
QSC Certified Expertise
Knowledgeable Support for QSC Products
HDTV Supply has QSC Level 1 certified expertise. Our team has completed QSC Level 1 Training, demonstrating foundational knowledge of the QSC platform, including system design, hardware and software, programming, and troubleshooting.
This training helps us provide knowledgeable product guidance when customers are selecting and deploying Q-SYS solutions. When you purchase Q-SYS products from HDTV Supply, you are working with a team that understands the Q-SYS platform and can help you make informed product and system decisions.
Why not buy this QSC Q-SYS NM-T1 Tabletop Beamforming Microphone from HDTV Supply today?
Ask a Question (0):
There are no questions for this product, click the button below to ask one.
QSC Q-SYS NM-T1 Tabletop Beamforming Microphone Specifications:
| Specification | Details |
|---|---|
| Model | NM-T1 |
| Product Type | Network Tabletop Beamforming Microphone |
| Platform | Q-SYS |
| Polar Pattern | Superdirective |
| Beamforming Zones | 4 Software-Configurable Zones |
| Coverage | Up to 360° |
| Pickup Range | 3-9 ft (1-3 m) |
| Microphone Elements | 16x MEMS Microphone Elements |
| Network Audio Channels Required | 1 Network Audio Stream and 16 Network Audio Channels per NM-T1 |
| Frequency Response | 100 Hz-16 kHz, ±3 dB |
| Sampling Rate | 16 kHz Wideband / 48 kHz Fullband |
| Bit Depth | 24 bit |
| Sensitivity | -36 dBFS (94 dB SPL) |
| Maximum SPL | 118 dB SPL (1 kHz @ 1% THD) |
| Dynamic Range | 95 dB |
| Signal-to-Noise Ratio | 65 dB (48 kHz); 66 dB (16 kHz) |
| Self Noise | 28 dB SPL (48 kHz); 28 dB SPL (16 kHz) |
| Latency | 4 ms |
| Mute Controls | 4 Touch-Sensitive Mute Buttons |
| Call Control | Touch-Sensitive Call Button |
| User Control | Programmable Touch-Sensitive User Button |
| Proximity Sensor | Touchless Mute/Unmute and Q-SYS Control Event Triggering |
| LED Light Ring | Programmable Color, Brightness, Pattern, and Speed |
| Call Sync | Q-SYS Call Sync Compatible |
| Network / Audio | Q-LAN |
| Network Connector | RJ45 |
| Power Requirements | Power over Ethernet (PoE), Type 1 Class 2 |
| Power Consumption | <6.5 W |
| Dimensions | 4.21 x 1.1 in (107 x 28 mm) |
| Weight | 1.5 lbs (0.68 kg) |
| Included Accessories | Mounting Stem, Strain Relief Cap, CAT6 Cable (10 ft / 3 m) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 5% to 85% RH, non-condensing |
| Expected Product Lifecycle | 10 Years |
Why not buy this QSC Q-SYS NM-T1 Tabletop Beamforming Microphone from HDTV Supply today?
QSC Q-SYS NM-T1 Tabletop Beamforming Microphone Manuals:
Q-SYS NM-T1 Tabletop Conference Microphone Hardware User Manual (PDF)
Q-SYS NM Series Network Microphone Specification Sheet (PDF)
Q-SYS NM-T1 Architectural and Engineering Specifications
Documentation: Official Q-SYS documentation for the NM-T1 Tabletop Beamforming Microphone.
What is the QSC Q-SYS NM-T1?
A: The NM-T1 is a native Q-SYS network tabletop beamforming microphone designed for collaboration and conferencing spaces.
How many beamforming zones does the NM-T1 have?
A: The NM-T1 has four software-configurable beamforming zones that can provide up to 360° coverage.
What is the pickup range of the NM-T1?
A: The specified pickup range is 3-9 ft (1-3 m).
How many microphone elements does the NM-T1 use?
A: The NM-T1 uses 16 MEMS microphone elements.
Does the NM-T1 support touchless muting?
A: Yes. Its proximity motion sensor allows users to trigger mute or unmute with a hand gesture near the microphone.
Does the NM-T1 have physical mute controls?
A: The microphone has four touch-sensitive mute buttons that control the mute status of the active microphone beams.
Does the NM-T1 have a programmable button?
A: Yes. The NM-T1 includes a touch-sensitive programmable user button that can be customized in Q-SYS Designer Software.
Does the NM-T1 have a status light?
A: Yes. Its RGB light ring supports programmable color, brightness, and pattern settings and can indicate mute and call status.
Does the NM-T1 support Q-SYS Call Sync?
A: Yes. Q-SYS Call Sync can synchronize compatible call controls and LED status across supported Q-SYS devices.
How is the NM-T1 powered?
A: The NM-T1 is powered through IEEE 802.3af Type 1 Class 2 Power over Ethernet using its RJ45 Q-LAN connection.
What type of microphone is the Q-SYS NM-T1?
A: The Q-SYS NM-T1 is a network tabletop beamforming microphone with a superdirective polar pattern and four software-configurable beamforming zones.
Can the Q-SYS NM-T1 provide 360° microphone coverage?
A: Yes. Its four configurable beamforming zones can provide up to 360° coverage around the microphone.
What is the frequency response of the Q-SYS NM-T1?
A: The NM-T1 has a frequency response of 100 Hz to 16 kHz with a tolerance of ±3 dB.
How does the Q-SYS NM-T1 connect to a Q-SYS system?
A: The NM-T1 connects through Q-LAN using its RJ45 network port and receives power through PoE.
What is the maximum SPL of the Q-SYS NM-T1?
A: The NM-T1 has a maximum SPL of 118 dB SPL at 1 kHz and 1% THD.
Why not buy this QSC Q-SYS NM-T1 Tabletop Beamforming Microphone from HDTV Supply today?
QSC Q-SYS NM-T1 Tabletop Beamforming Microphone Warranty:
The QSC Q-SYS NM-T1 is covered by a 3-year limited warranty. The standard warranty period begins from the invoice date of first purchase, and proof of purchase is required for warranty validation.
