We are sorry but the Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card is no longer available and has been discontinued by the manufacturer. We've left this page up for reference only.
Please call us at 833-965-3722 immediately for the replacement product.
This Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card is a four−channel 4K@60Hz (4:2:0), long reach, HDBaseT input card for the VS−3232 Series Modular Multi−Format Digital Matrix Switchers. DT−IN4−F32 inputs four long reach HDBaseT signals with bidirectional RS−232 and IR from the line to the chassis.
Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card Features:
- Max. Data Rate — 10.2 Gbps (3.4Gbps per graphic channel).
- System Range — 40m (130ft) — 4K60 4:2:0 or 4K30 4:4:4; 70m (230ft) — 1080p 12bit (deep color). Note: When using Kramer HDBaseT cables.
- HDTV Compatible.
- HDCP Compliant.
- 3D Pass–Through.
- Bidirectional RS–232 and IR per Port.
- Kramer Equalization and re–Klocking Technology
Why not buy this Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card from HDTV Supply today?
Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card Specification:
- INPUTS
- 4 HDBaseT: On RJ–45 connectors
- PORTS
- 4 RS−232 and 4 IR ports: On 10–pin terminal blocks
- BANDWIDTH PER CHANNEL
- Video: 3.4Gbps
- Serial data: 115200
- TOTAL BANDWIDTH
- Video: 10.2Gbps
- Serial data: 115200
- MAxIMUM RANGE
- 40m (130ft) — 4K@60Hz (4:2:0) or 4K@30Hz (4:4:4)
- 70m (230ft) — 1080p 12 bit (deep color)
- Note: When using Kramer HDBaseT cables
- 3D PASS-THROUGH
- Supported
- ExTENDED RS-232
- 300 to 115200 baud rate
- STANDARDS COMPLIANCE
- HDCP 1.4, HDMI 1.3a, HDBaseT, HDTV compatible
- POWER CONSUMPTION
- 10W
- ENVIRONMENTAL CONDITIONS
- Operating Temperature: 0° to +40°C (32° to 104°F)
- Storage Temperature: –40° to +70°C (–40° to 158°F)
- Humidity: 10% to 90%, RHL non–condensing
- REGULATORY
- Safety: CE
- Environmental: RoHs and WEEE
- INCLUDED ACCESSORIES
- Screw driver
- PRODUCT DIMENSIONS
- 21.60cm x 19.00cm x 2.00cm (8.50" x 7.48" x 0.79") W, D, H
- PRODUCT WEIGHT
- 0.4kg (0.8lbs) approx.
- SHIPPING DIMENSIONS
- 25.00cm x 22.50cm x 5.50cm (9.84" x 8.86" x 2.17") W, D, H
- SHIPPING WEIGHT
- 0.4kg (0.8lbs) approx.
Why not buy this Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card from HDTV Supply today?
Kramer DT-IN4-F32 Installation Sheet
