This Kramer CL-8P 8 Inch In-Ceiling 2-Way, Closed Back Co-Axial Passive Speaker is a plenum rated high−performance ceiling speaker that provides exceptional sound with high SPL. The speaker was designed with present mid−range optimized for speech clarity and background music. The speaker supports both 8? low impedance as well as several 70V/100V high impedance modes.
The speaker’s high performance and sound quality make it ideal for high−end areas with high ceilings such as auditoriums, hotel lobbies and boardrooms. Features front−access wiring for easy installation and troubleshooting. Both black & white magnetic grills are included in the box.
Kramer CL-8P 8 Inch In-Ceiling 2-Way, Closed Back Co-Axial Passive Speaker Features:
- Premium sound with high SPL
- Plenum rated UL2043 & UL1480A
- Low–impedance (8Ω) / high–impedance (70V/100V)
- Power ratings: 60W continuous / 90W peak
- Sensitivity (1W@1m, free field): 90dB SPL
- Maximum SPL (@1m): Continuous: 108dB SPL / Peak: 110dB SPL
- Industrial design: black & white bezel–less magnetic grills included in the box, Low profile — light weight, front–access wiring
- Eco–friendly mono–material packaging
Why not buy this Kramer CL-8P 8 Inch In-Ceiling 2-Way, Closed Back Co-Axial Passive Speaker from HDTV Supply today?
Kramer CL-8P 8 Inch In-Ceiling 2-Way, Closed Back Co-Axial Passive Speaker Specification:
- Audio
- LF Driver: 200 mm (8 in) with polypropylene cone and rubber surround
- HF Driver: 25 mm (1 in) liquid cooled soft–dome tweeter
- Frequency Characteristics
- Frequency Range (-10dB): 55Hz–20kHz
- Frequency Response (±3dB): 70Hz–20kHz
- Dispersion Angle: 82° conical (1 kHz to 4 kHz)
- Power Ratings
- @ 8? Low impedance: 60W continuous / 90W peak
- @ 100V High impedance: 60W / 30W / 15W
- @ 70V High impedance: 60W / 30W / 15W / 7.5W
- Sound Pressure Level (SPL)
- Sensitivity (1W@1m, free field): 90dB SPL
- Maximum SPL: Continuous: 108dB SPL / Peak: 110dB SPL
- Mechanical
- Installation
- Type: In–ceiling speaker with brackets and C–ring
- Mounting: 4–point screw down Dog–Ear clamp, up to 60mm (2.36") ceiling thickness
- Connectors: 4–pin pluggable Euroblock connector, 28–12AWG
- Cutout template included in the box
- Weight (single speaker): 6.23kg (13.7lbs)
- Dimensions
- Depth (ceiling clearance): 270mm (10.7")
- Back Enclosure Outer Diameter: 295mm (11.6")
- Cutout Diameter: 297mm (11.7")
- Grill Diameter: 327mm (12.9")
- Shipping
- Single Box Dimensions: 430mm x 430mm x 338mm (17" x 17" x 13.3")
- Master Box Dimensions: 438mm x 438mm x 351mm (17.3" x 17.3" x 13.9")
- Single Box Weight: 8.5kg (18.8lbs)
- Master Box Weight: 9.2kg (20.3lbs)
- Packaging: Eco–friendly mono–material recyclable carton
- Installation
- Material
- Grill: Black/White powder-coated steel, magnetic, paintable, with cloth and removable logo
- Baffle: V–0 Flame Retardant
- Back Enclosure: Powder–coated steel
- Environmental
- Operating Temperature: –5° to +50°C (23° to 122°F)
- Storage Temperature: –10° to +55°C (14° to 131°F)
- Humidity: 30% to 85%, RHL non–condensing
- Balanced Line Level Input
- Single Box Weight: 8.5kg (18.8lbs)
- Regulatory
- Safety
- UL 2043 Certified: Plenum rated for air–handling spaces
- UL1480A Certified: Fire–protective signaling in commercial spaces
- Environmental Compliance: RoHS, REACH, WEEE
- Safety
Why not buy this Kramer CL-8P 8 Inch In-Ceiling 2-Way, Closed Back Co-Axial Passive Speaker from HDTV Supply today?
Kramer CL-8P Quick Start Guide
