The Blustream UEX3D-WP-US is a USB 3.2 Gen1 HDBaseT wall plate extender that connects up to 4 USB devices (USB-A and USB-C) to a host up to 100m over CAT6A, with up to 5Gbps bandwidth.
The UEX3D-WP-US supports USB 2.0/1.1 and bi-directional PoC. UEX3D-WP-EU extends USB 3.2 Gen1 devices like cameras, drives, KVM, and audio.
Blustream UEX3D-WP-US USB 3.2 Gen1 HDBaseT Extender US Wall Plate - Device Features:
- USB 3.2 Gen1 HDBaseT Extender supporting 2 x USB-C and 2 x USB-B ports for connection to USB devices
- Supports USB 3.2 signal extension up to 100m over HDBaseT *
- Backwards compatible with USB 2.0 & 1.1 devices
- Combined USB3.2 Gen1 data transfer rate up to 5Gbps *
- Provides up to 3A combined power to USB devices (up to 1.7A per single USB port)
- Configurable USB device power management via API commands
- Bi-directional PoC (Power over Cable) to power extenders from either the host or device unit (supports 12-48V PoC)
- Supports bi-directional RS-232 when used with compatible HDBaseT products
- PoC function can be enabled/disabled via dipswitch
- Simple plug and play, no driver installation or setup required
Why not buy this Blustream UEX3D-WP-US USB 3.2 Gen1 HDBaseT Extender US Wall Plate - Device form HDTV Supply today?
Blustream UEX3D-WP-US USB 3.2 Gen1 HDBaseT Extender US Wall Plate - Device Specification
- CAT Connectors: 1 x RJ45 connector
- USB Device Ports: 2 x USB Type C female, 2 x USB Type A female
- Local power input: 1 x 2-Pin Phoenix connector
- Firmware Upgrade: 1 x Micro-USB
- RS-232: 1 x 3-Pin Phoenix connector
- Power Supply: 24V/1.5A DC
- Dimensions (W x H x D): 136mm x 76mm x 46mm (without faceplate)
- Faceplate Dimensions (W x H x D): 146mm x 86mm x 6mm (faceplate)
- Mounting hole spacing: UK 121mm CTC, EU 60mm CTC
- Backbox Mounting Depth: 40mm (minimum), 47mm (recommended), UK or EU double gang
- Shipping Weight: 0.8kg
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature : -4°F to 140°F (-25°C to +70°C)
Why not buy this Blustream UEX3D-WP-US USB 3.2 Gen1 HDBaseT Extender US Wall Plate - Device form HDTV Supply today?
Blustream UEX3D-WP-US User Manuals
Blustream UEX3D-WP-US Datasheet
Why not buy this Blustream UEX3D-WP-US USB 3.2 Gen1 HDBaseT Extender US Wall Plate - Device form HDTV Supply today?
What host or receiver does this wall-plate extender work with?
A: It’s compatible with Blustream UEX3H and UEX3H-WP host/receiver products.
Which USB ports are on the UEX3D-WP-US wall plate?
A: The wall plate provides 2 USB Type‑C ports and 2 USB Type‑A ports for connecting USB devices.
How far can this extender carry USB 3.2 Gen1 signals and what cable is required?
A: It supports USB 3.2 Gen1 signal extension up to 100 m (328 ft) over HDBaseT when using a minimum of CAT6A cable.
Does the package include a power supply or other accessories?
A: Yes; the package includes a 24V 1.5A power supply, an RS‑232 control cable, a magnetic faceplate (wall plate versions only), and a quick reference card.
How much USB power can the wall plate provide to connected devices?
A: The unit can provide up to 3 A combined to USB devices, with a maximum of 1.7 A available per single USB port.
Can I extend a USB 3.2 Gen1 camera 100 feet away and keep full USB3 speeds?
A: Yes; the product is designed to extend USB 3.2 Gen1 data up to 100 m (328 ft) over HDBaseT using CAT6A, supporting combined bandwidth up to 5 Gbps.
Will this wall plate pass video from a laptop USB‑C video output (DP Alt Mode)?
A: No; this product supports USB 3.2 data only and does not support DP Alt Mode video pass‑through.
How can I power the wall plate and the remote unit — does it support Power over Cable (PoC)?
A: You can power units locally with the supplied 24V/1.5A adapter or use bi‑directional PoC over the HDBaseT link; PoC supports 12–48 V and can be enabled or disabled with a dipswitch.
Can I use USB 2.0 devices on this wall plate?
A: Yes; the extender is backwards compatible with USB 2.0 and USB 1.1 devices.
What RJ45 wiring should I use when terminating the HDBaseT cable?
A: Use a straight (pin‑to‑pin) CAT cable wired to the T568B standard and a minimum of CAT6A for long runs or high‑EMI environments.
