The product extends HDMI, Bi-directional IR & RS-232 and Bi-directional PoC up to lengths of 70m (4K to 40m) and includes a HDMI loop-out for integrating local displays or cascading to multiple devices.
Blustream HEX70CS-TX HDBaseT Transmitter - 70m (4K 60 4/4/4 up to 40m), RS-232 Pass through Features:
- Advanced HDBaseT technology offering distribution of video and audio over a single CAT cable
- Advanced Color Space Conversion (CSC)
- Supports HDMI 2.0 18Gbps specification including HDR
- Supports 4K @ 60Hz 4:4:4 UHD video up to 40m
- Extends HDMI 1080p video up to 70m
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
- Features 1 x HDMI loop-out on HEX70CS-TX for integrating local displays or cascading to multiple devices
- Supports bi-directional RS-232 pass-through
- Supports bi-directional IR pass-through
- Supports bi-directional IR pass-through with switchable 5V/12V IR hardware support
- HDCP 2.2 support
Why not buy this Blustream HEX70CS-TX HDBaseT Transmitter - 70m (4K 60 4/4/4 up to 40m), RS-232 Pass through today?
Blustream HEX70CS-TX HDBaseT Transmitter - 70m (4K 60 4/4/4 up to 40m), RS-232 Pass through Specifications:
- Video Input Connectors: 1 x HDMI Type A, female
- Video Output Connectors: 1 x HDBaseT RJ45 connector, 1 x HDMI Type A, female
- RS-232 Serial Port: 1 x DB-9, female
- IR Input Ports: 1 x 3.5mm stereo jack
- IR Output Ports: 1 x 3.5mm mono jack
- EDID DIP Switch: 4-pin
- Power Supply: 12V/2A DC, screw type connector
- Power Consumption: 12.7W
- Transmitter Dimensions (W x D x H): 143 x 134 x 22mm (without connections)
- Transmitter Dimensions (W x D x H): 143 x 141 x 22mm (with connections)
- Ind. Extender Weight: 0.35kg (excluding accessories)
- Shipping Weight: 1.4kg
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -4°F to 140°F (-20°C to 60°C)
- Mounting Kit included
Why not buy this Blustream HEX70CS-TX HDBaseT Transmitter - 70m (4K 60 4/4/4 up to 40m), RS-232 Pass through today?
What video resolutions and distances does this transmitter support?
A: It supports 4K @ 60Hz 4:4:4 up to 40m and HDMI 1080p up to 70m; it also supports industry-standard resolutions from 480i up to 4K.
Which connectors are on the HEX70CS-TX transmitter?
A: The transmitter includes 1 HDMI Type A input, 1 HDMI Type A loop-out, and 1 HDBaseT RJ45 output; it also has a DB-9 RS-232 port and IR input/output jacks.
Does this unit pass through RS-232 and IR control signals?
A: Yes; it supports bi-directional RS-232 pass-through and bi-directional IR pass-through.
Is HDCP supported and what HDMI specification does it meet?
A: The unit supports HDCP 2.2 and meets the HDMI 2.0 18Gbps specification including HDR.
What power input and consumption are specified for the transmitter?
A: The transmitter uses a 12V/2A DC power supply and lists power consumption at 12.7W.
Can I use this to send a 4K 60 signal 50 meters away?
A: No; the product specifies 4K @ 60Hz 4:4:4 only up to 40m, so 50m exceeds the documented 4K distance.
Will I be able to connect a local display at the transmitter location?
A: Yes; the transmitter features an HDMI loop-out for integrating local displays or cascading to multiple devices.
Does the transmitter support powering over the HDBaseT link (PoC/PoE)?
A: The product description states it supports bi-directional PoC but does not detail power arrangements; further documentation would be needed to confirm how power is provided or received.
Can I mount the HEX70CS-TX and what is included for mounting?
A: Yes; a mounting kit is included with the transmitter.
What operating and storage temperatures should I expect for this unit?
A: The unit's operating range is 32°F to 104°F (0°C to 40°C) and its storage range is -4°F to 140°F (-20°C to 60°C).
