This Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub achieves new levels of performance and flexibility. AV installers can now easily specify their desired I/O structure and choose the additional control features required for a specific project. The Custom Pro matrix chassis??have been specifically designed to operate in challenging AV environments. The robust housing and interlocking board configuration make both installation and maintenance a seamless experience. Advanced features include audio breakout, IR routing, HDBaseT??inputs, simultaneous HDBaseT??/ HDMI outputs, RS-232 pass through and a web browser interface module for control and configuration of the matrix (subject to I/O card specification)
Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub Features:
- Custom Pro Matrix with 12 x modular bays for population of input / output / control boards
- Supports up to 16 x video inputs and 16 x video outputs using a combination of 2-Way and 4-Way interchangeable input and output boards
- Supports 4K UHD video up to 4K @ 60Hz 4:4:4*
- Optional Color Space Conversion (CSC) boards support HDMI 2.0 18Gbps specification including HDR over HDBaseT
- Optional CSC boards feature independent downscaling of up to 4K @ 60Hz 4:4:4 video input to the following formats:
- 1080p @ 60Hz (for screens that do not support 4K)
- 4K @ 60Hz 4:2:0 (for screens that do not support full 18Gbps 4K @ 60Hz 4:4:4)
- 16 x analog L/R audio inputs which can be embedded onto corresponding HDMI / HDBaseT zone outputs
- 16 x IR outputs for routed control of local source equipment
- 16 x IR inputs for distribution of IR to compatible Blustream HDBaseT receivers
- Optional RS-232 control board for bi-directional IR control with Blustream HDBaseT receivers
- Optional analog and digital audio breakout board with line-level volume control
- Web browser interface for control and configuration of matrix
- Control of matrix via front panel, RS-232, TCP/IP, IR and Web GUI
- Supports PoC (Power over Cable) when used with compatible Blustream HDBaseT receivers
- 3rd Party drivers available for major control brands
- Advanced EDID management
- HDCP 2.2 compliant
Why not buy this Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub today?
Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub Specifications:
- Audio Input Connectors: 16 x 3.5mm stereo jack (L/R)
- RS-232 Serial Ports: 1 x 9-pin RS-232 connector
- IR Input Ports: 16 x 3.5mm stereo jack
- IR Output Ports: 16 x 3.5mm mono jack
- TCP/IP Control: 1 x RJ45, female
- Rack-Mountable: 4U rack height, rack ears included
- Casing Dimensions (W x H x D): 440mm x 173mm x 422m without feet
- Dimensions Including Connections (W x H x D): 440mm x 178mm x 430mm with feet
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Power Supply: Internal 100-240v AC
Why not buy this Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub today?
Blustream CUSTOMPRO-HUB16 User Manual
Blustream CUSTOMPRO-HUB16 Data Sheet
Blustream CUSTOMPRO-HUB16 Declaration of Conformity
Blustream CUSTOMPRO-HUB16 Configuration Guide
Why not buy this Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub today?
Why not buy this Blustream CUSTOMPRO-HUB16 4 U Custom Pro Matrix Hub today?
How many inputs and outputs can this matrix hub support?
A: It supports up to 16 video inputs and 16 video outputs using a combination of 2-way and 4-way interchangeable input and output boards.
What physical rack space does the CUSTOMPRO-HUB16 require?
A: The unit is a 4U rack-mount chassis and includes rack ears.
What control methods can I use with this matrix hub?
A: You can control it from the front panel, RS-232, TCP/IP, IR, and a Web GUI.
Does the hub include analog audio inputs and can they be embedded to outputs?
A: Yes; it has 16 analog L/R audio inputs that can be embedded onto corresponding HDMI/HDBaseT zone outputs.
Does the hub support HDCP and 4K video formats?
A: Yes; it is HDCP 2.2 compliant and supports 4K UHD up to 4K @ 60Hz 4:4:4 (with optional Color Space Conversion boards available for additional handling).
Can I send 4K @ 60Hz 4:4:4 video through this matrix?
A: Yes; the chassis supports 4K up to 4K @ 60Hz 4:4:4, subject to the populated I/O cards and system configuration.
Will this work with HDBaseT receivers over long cable runs?
A: It supports HDBaseT inputs and simultaneous HDBaseT/HDMI outputs and also supports PoC when used with compatible Blustream HDBaseT receivers.
Can I route IR and RS-232 through this matrix to control remote devices?
A: Yes; it provides 16 IR outputs, 16 IR inputs for distribution to compatible Blustream receivers, and an optional RS-232 control board for bi-directional IR control with Blustream HDBaseT receivers.
Does the matrix include a web interface for configuration?
A: Yes; it includes a web browser interface module for control and configuration of the matrix, subject to I/O card specification.
What power input does the CUSTOMPRO-HUB16 use?
A: The unit uses an internal 100-240V AC power supply.
