This Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m offers 4x independent HDBaseT??outputs utilizing CSC technology allowing support of HDMI 2.0 4K @ 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m).
The PRO-OUT4TL-V2 features independent downscaling of 4K video inputs on the CSC HDBaseT??outputs to allow displays only capable of supporting lower video resolutions to receive 4K video while still showing maximum original 4K UHD resolution on the higher-definition displays.
The PRO-OUT4TL-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m Features:
- Advanced HDBaseT technology offering distribution of video and audio over a single CAT cable
- Features 4x HDBaseT outputs for connection to compatible HDBaseT receivers
- Advanced Color Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR support
- Supports 4K @ 60Hz 4:4:4 UHD video up to 40m*
- Independent downscaling of video input resolutions up to 4K @ 60Hz 4:4:4 to the following formats:- 1080p @ 60Hz (for screens that do not support 4K)- 4K @ 60Hz 4:2:0 (for screens that do not support full 4K @ 60Hz 4:4:4)
- Extends HDMI 1080p video up to 70m
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
- Supports PoC to power Blustream HDBaseT receivers
- Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
- HDCP 2.2 support
- To be used with the HEX70CS-RX receivers
Why not buy this Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m today?
Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m Specifications:
- Video Output Connectors: 4 x HDBaseT RJ45 connector
- Card Dimensions (W x H x D): 182mm x 22mm x 177mm
- Dimensions Including Connections (W x H x D): 202mm x 22mm x 188mm
- Shipping Weight: 0.5kg
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Why not buy this Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m today?
Why not buy this Blustream PRO-OUT4TL-V2 4 Output HDBaseT(TM) Lite CSC Board Supporting HDMI 2.0 4K 60Hz 4:4:4 up to 40m today?
Is the PRO-OUT4TL-V2 compatible with Blustream HEX70CS-RX receivers?
A: Yes. The product page lists the PRO-OUT4TL-V2 "To be used with the HEX70CS-RX receivers."
Does the PRO-OUT4TL-V2 support HDCP 2.2?
A: Yes. The board includes HDCP 2.2 support.
How many HDBaseT outputs and what connector type does it provide?
A: It provides four independent HDBaseT outputs using RJ45 connectors.
Does the board support powering receivers over the CAT cable (PoC)?
A: Yes. The PRO-OUT4TL-V2 supports PoC to power Blustream HDBaseT receivers.
Can I send a 4K source to some displays and downscale for others with this board?
A: Yes. Each HDBaseT output supports independent downscaling from 4K to lower formats so some displays can get 1080p while others receive the original 4K.
Will this board extend a 1080p HDMI signal farther than 4K?
A: Yes. The product states it can extend HDMI 1080p video up to 70m.
Does the PRO-OUT4TL-V2 carry HDR and advanced audio formats?
A: Yes. The board supports HDR via HDMI 2.0/18Gbps CSC and lists support for Dolby TrueHD, Atmos and DTS-HD Master Audio.
What are the card dimensions if I need to check fit in a hub?
A: The card dimensions are 182mm x 22mm x 177mm; dimensions including connections are 202mm x 22mm x 188mm.
What operating and storage temperatures does this board support?
A: Operating temperature is 32°F to 104°F (0°C to 40°C) and storage temperature is -4°F to 140°F (-20°C to 60°C).
