Build Your Own Audio Matrix Switcher

WolfPack

$1,250.00
Part Number:
AUDRGB
UPC:
728370341911
Availability:
Usually ships in 3-4 business days
1:
Build an Audio Matrix with 3-Modular Chassis
2:
7-inch Color Touch Screen (Shown)
3:
100ms (0.1 sec) Seamless Switching
4:
Universal 3.5mm Audio In & Out Cards
5:
Apps, WEB GUI, RS232 & Touch Screen Control
6:
Crestron, Elan, URC & Control4 Drivers
7:
Optional Dual 7 Color Monitors (Shown) "
MUST CLICK TO BUILD YOUR OWN:
Build your own Seamless Modular Audio Matrix Switcher using an integrated Audio modular Audio chassis. The chassis back plane allows various technologies, like Audio, to be converted and switched eliminating external converters. This Audio Matrix Switcher allows any input to be routed to any output, or the same input to be routed to all outputs, or any combination using Audio input and Audio output cards or other cards of different or mixed technologies. A built-in 7-inch Color Touch Screen (Shown) lets you make your selections directly on the front of the Audio matrix switcher.

The core of the these Audio Seamless Modular Audio Matrix Switcher Chassis consists of its highly configurable backplane that supports up to 36-seamless Audio input cards & up to 36-seamless Audio output cards. You can control the Audio Matrix Switcher via its iOS or Android app, a few simple button taps from the front panel buttons, a WEB GUI Browser control or the Dual RS-232 serial and LAN ports. Our Modular  Audio Matrix Switchers also can support high-frequency Audio sources routed to  Audio amps, etc.

WolfPack Modular Audio Matrix Switcher Features:

  • 100ms Seamless switching of Universal Audio input and Universal Audio output cards
  • Supports 1 port Audio Output cards and includes a separate De-embedded Audio output also
  • Supports 1 port Audio Input cards and a separate Embedded audio input
  • 7-inch Color Touch Screen (Shown)
  • Flexible card type design supporting up to 36-Audio input cards and up to 36-Audio output cards
  • Advanced EDID management for rapid integration of sources and displays
  • Dual IP controlled via built-in web server and LAN
  • Dual RS-232 Serial interface for remote control via an automated control system (not supplied)
  • Hot-pluggable
  • Control with an IOS or Android app, a few button taps from the front panel touch screen, a WEB GUI Browser control or the Dual RS-232 serial ports
  • The matrix does not have IR nor a remote control but can be controlled with its iOS and Android App as well as the above.
  • Rack-mountable

Dual Control System

Redundant Power Supply


Supports a dual control system with 2 - RS232 ports and 2 - LAN ports. Using the LAN ports it can be controlled with our WEB GUI, iOS and Android App

2 power supply system guarantees a more reliable way to use in any applications No more worries for the power supply down to cause any issues.

Reasons that sets our Seamless WolfPack™  Audio Matrix Switcher apart from others:

  1. 3-Chassis Sizes: 9x9, 18x18 and 36x36
  2. Uses Seamless Audio cards
  3. Switches in 100 ms (0.1 sec)
  4. Optional Crestron, URC, Elan & 2-Way Control4 Drivers
  5. 40 - Programmable Preset Scenes To Choose From
  6. Card cage chassis has up to 36-Audio in and up to 36-Audio out card slots
  7. Control via an iPad, Android, Web Browser, Dual RS232 & 7-inch Color Touch Screen
  8. 2 - Power Supplys with larger matrices w/automatic switch-over if a problem occurs
  9. 2 - Year Warranty
  10. Free Lifetime Telephone, CHAT, TEXT and Email Tech Support

WolfPack™ 1080p 8x16 Seamless  Audio Matrix Switcher Configuration Example:

  • 1 - 18-card in and 18-card out card cage
  • 8 - 1-port  Audio seamless input cards = 8  Audio inputs
  • 16 - 1-port  Audio seamless output cards = 16  Audio outputs
  • 10 additional input slots for future card expansion to 18- Audio inputs
  • 2 additional output slots for future card expansion to 18- Audio outputs

The heart of these Seamless Modular Matrix Router chassis allows customization of the number of  Audio input and output cards to match every need of your system design and application. The matrix support hot-plugs and you can change the cards while the equipment is still working.

WolfPack HDMI Switchers Slide In Audio Cards: By having 1-port slide-in seamless  Audio cards the matrix is very reliable as in the unlikely even there is a loss of signal you just replace the card with a spare you have purchased, use our  2 - Year Advance Replace Warranty or order another from us. The complete matrix doesn't have to be sent to us for a repair. The WolfPack Modular  Audio Matrix Routers manage many type of  Audio signals. These Modular  Audio Matrix Switchers support long  Audio cables, maintains power reliability in the event of failure and offer the best flexible solutions in a complex  Audio system deployment.


No black or blue screens appear while switching between the sources. Provides users a more enjoyable and greater video and audio switching experience
Seamless Switching: This WolfPack™  Audio Matrix Switcher allows seamless switching between inputs with a clean video cut (frame-to-frame switching with no glitches). The WolfPack™ Seamless  Audio Matrix Switcher advanced processor allows it to process up to 36-live signals simultaneously, that means it can seamlessly and instantly switch (~100ms) between up to 36-Audio inputs and up to 36-Audio outputs. Most non-seamless matrix switcher require a delay of several seconds before they can switch between devices but with this WolfPack seamless  Audio family that wait time is completely eliminated.


Users can connect to their the local network or a WIFI router via our LAN port. You can even download the iOS APP from the Apple store or from our website directly
Free Android and iOS App: The IOS App for this WolfPack card cage matrix is in the Apple Application Store and when you SEARCH the key words "MCS" or "Matrix Control System" you can download and install it to your iPad or iPhone. Also from your iPad or iPhone click the following link...MCS-matrix control system to install it directly. For the Android App click the following link and download it. Go to Android App for control of this  Audio matrix switch.

WolfPack HDMI SwitchersEDID HANDSHAKE MANAGEMENT: The Modular Audio Matrix Routers EDID provides for optimal source-to-screen switching. EDID will optimize the video card output for the capabilities of the end display. The EDID ghost unit enables the copying, emulating, cloning, and "learning" of EDID data from a display. Our EDID Emulator and repeater comes with predefined presets, user programmable banks, Sink EDID sniffing bank and more. Our EDID Emulator ensures the Audio audio between any source and display and will resolve any loss of, intermittent (flashing) video, snow or color-space (purple or red) issues.

Why not configure a WolfPack Seamless Modular  Audio Matrix Switcher based upon your needs today?

This Modular WolfPack Modular Matrix System has dual RS232 ports on the back of the chassis that can be used (1) as a back-up control if one malfunctions and (2) you can use the 2nd-RS232 port to control the Matrix Switcher at the same time as the first. The same for the 2-LAN ports.

Hardware Scaling via DIP Switches on both in and out cards: The 8-pin DIP switch on the cards are for the up/down manual scaling of resolutions. Each HDMI card has a 8-pin DIP switch to select multiple resolution settings to conform to your source devices and the destination devices.

Separate Embedded Audio In and De-embedded Audio Out: The matrix allows you to display video with separate audio coming from another audio source as it supports embedding the audio on the input cards 3.5mm audio connector and then de-embedding the audio on the output cards 3.5mm audio.

100ms Seamless HDMI Switching: This WolfPack™ Seamless 4x10 HDMI Matrix Switcher over CAT6 w/10-HDBaseT Receivers delivers 100ms instantaneous video switching with full 1080p/60 video at each port. This high-performance engine processes HDMI signals by executing EDID hops & HDCP handshakes simultaneously at both the source input, the display outputs & scales the inputs for the best output resolution. It sets the output clock timing & uses a frame buffer to retain the input signal information for the fastest output. The cards also have Embedded audio inputs & De-embedded Audio Outputs.

Modular HDMI Matrix Routers Specs:

  • Modular Configuration Chassis: 9x9, 18x18 & 36x36
  • Supported Input & Outputs Signals:
    • Audio Video: Red-Green-Blue
    • Optional Audio Video Balun Sets with Mono Analog Audio to 300' (Male 3.5mm to 4-female RCA adapter & 2-RCA male to one RCA female adapter are needed and not supplied)
  • Power Supply: 100 to 240VAC, 50-60Hz
  • Operating Temperature: -10鈩 to 50鈩
  • Storage Temperature: -25鈩 to 55鈩

Why not buy one of these Modular Matrix Routers today?

Frequently
Reasons To Buy an HDTV Supply WolfPack Product

Why not configure a WolfPack Seamless Modular  Audio Matrix Switcher based upon your needs today?

Control

When one is designing an HDMI Matrix Switch the most important initial specification is the number of inputs and outputs you will need in your facility. The next, and often forgotten, is how the user wants to control those inputs and outputs. HDTV Supply has your back when you're buying one of our WolfPack Family of Modular Matrix Switchers as we have dozens of way to control the inputs and outputs and are shown at Controlling WolfPack Modular Matrix Systems, as well as below:
  1. Free iPad App (iOS)
  2. Free iPhone App (iOS)
  3. Free iPod App (iOS)
  4. Free Android Tablet App
  5. Free Android Phone App
  6. Free Samsung Galaxy Tablet App
  7. Free Samsung Galaxy Phone App
  8. Free Web GUI from any browser is standard
  9. Dual RS232 ports are standard on select models
  10. Dual TCPIP ports are standard on select models
  11. Sports Bar DirecTV™ Control System (Call)
  12. Free One-Way Control4 Drivers
  13. Optional $99 2-Way Control4 Drivers
  14. Optional $99 URC Drivers
  15. Optional $129 Crestron Drivers
  16. Optional $99 Elan Drivers
  17. Optional $99 RTI Drivers
For an up-to-date listing of all the methods to control our WolfPack Matrix Switchers go to Ways to Control Our WolfPack Family Of Modular Matrix Systems.

Control Drivers

DirecTV Controller

Apps

HDTV Supply has successfully installed our WolfPack, WolfPackLite and our other Audio Modular Matrix Switcher in Sports Bars, Restaurants, Bowling Alleys, Fitness Centers, Malls, Places of Worship, Data Centers, Gaming Rooms, Nail Salons, County Clubs, Casinos, Factories, Conference Rooms, Schools, Home Theaters or many other installations requiring Audio matrix switching. The reason, we are told by the users, is the number of features we offer compared to other companies they looked at.

These modular matrix switchers can usually be integrated with many third party control systems using the RS232 port on the back of the matrix.

For experienced AV hardware and software professionals who want to write their own drivers for 3rd party control systems from:

  • AMX™
  • Control4™
  • Creston™
  • RTI™
  • DTVGameControl™
  • Elan g!™
  • Media Switcher™
  • OnControls™
  • Savant™
  • SimpleControl™
  • SwitchItUp™
  • SAVI Control™
  • URC Control™

...and we have created a simple and very easy to use RS232 script to write your own drivers.

EXAMPLE: If you want to switch input 8 to output 1, 8, 16, the RS232 command would be 8x1&8&16. and notice the command has a period (.) at the end of the string. The matrix even replies "OK" when the right command is received and shows "ERR" when receiving a wrong command. Here is the RS232 User Manual if you want to write your own drivers.

How to use the info:

END USER: If you are an end user and want to have a whole-house control system from any of the above 3rd party control houses but your budget can't support the price you were quoted, do the following:

  1. Call us for a quote
  2. Once you get our quote call a 3rd party control reseller or installer in your area and tell them "Here is the hardware I want to use, please give me a quote on writing the software and installing all of the hardware at my location." You usually can save $1,000s on larger systems.

CAVEAT: We are not certified by any of the above 3rd party control systems companies nor have the necessary hardware to verify, troubleshoot and support the 3rd party writing of the code. We do warranty, though, that the RS232 script in the above RS232 Users Manual has and will work to control the matrix directly.

Also, CLICK HERE for our DirecTV™ & HDMI Matrix Control Software for Bars & Restaurants

Why not buy this Audio Matrix Switcher today?
