This Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches is a 10GBASE-LR Lite SFP+ fiber transceiver designed for high-speed, long-distance Ethernet connectivity over single-mode fiber.
Operating at 1310 nm, it supports data rates up to 10 Gbps and transmission distances up to 2 kilometers using LC duplex connectors.
Fully hot-swappable and compliant with SFP+ MSA standards, it’s ideal for enterprise networks, AV-over-IP systems, and data center applications that require reliable, low-latency fiber links between switches and networked devices.
These are NETGEAR SFP+ (small form factor pluggable) fiber optic transceiver modules for NETGEAR M4250 managed Gigabit Ethernet network switches.
They fit into the SFP+ interfaces of these switches and enable 10 Gigabit Ethernet links between NETGEAR M4250 switches to expand networked AV system capacity.
These modules can also be used to extend network connections over long distances up to 550 meters (1,800 feet) with multi mode fiber, and up to 2 km (1.2 mi) with single mode fiber.
Atlona is offering these SFP+ modules as accessories to the NETGEAR M4250 switches for customers wanting to build large OmniStream AV over IP systems spanning several network switches.
NOTE: NETGEAR SFP+ modules are available only in the United States and Canada.
Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches Feature:
- SFP+ fiber optic transceiver modules for NETGEAR M4250 network switches
- Enables 10 Gigabit Ethernet links for aggregating M4250 switches to expand networked AV system capacity
- Also can be used to transmit 10 Gigabit Ethernet long distances over fiber optic cable
- Up to 550 m (1800 ft) over multi mode fiber
- Up to 2 km (1.2 mi) over single mode fiber
- Fits into SFP+ interfaces of M4250 switches (except NETGEAR-GSM4212P)
- LC duplex connector
- Hot-swappable installation and removal
Why not buy this Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches from HDTV Supply today?
Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches Specifications:
- Ports
- Panel: IEEE 802.3ae 10GBase-SR
- Wavelength: 850 nm
- Max. Operating Distance:
- 50/150 μm multi-mode fiber (OM1): 984 ft
- 62.5/125 μm multi-mode fiber (OM2, OM3, OM4): 108 ft
- Connectors
- Type: 1 x LC
- Power
- Consumption: < 1.0 W
- MTBF: 4,986,536 hours (569 years)
- Environmental Fahrenheit
- Operating Temperature: +32° to +158°
- Storage Temperature: +32° to +185°
- Operating Humidity (RH): 85% (at +25° C), non-condensing
- Dimensions (H x W x D) Inches
- Unit: 0.46 x 0.53 x 2.19
- Weight Pounds
- Unit: 0.04
- Certification
- Device: UL 1950, CSA 22.2 No. 950, RoHS
Why not buy this Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches from HDTV Supply today?
Atlona NETGEAR-AXM761 User Manual
Why not buy this Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Modules for NETGEAR M4250 Switches from HDTV Supply today?
What is the Atlona NETGEAR-AXM761 SFP+ Fiber Optic Transceiver Module?
A: It is an SFP+ optical transceiver for compatible NETGEAR M4250 switches, providing a 10 Gigabit Ethernet fiber link.
It is intended for AV-over-IP, enterprise, and switch-aggregation links where fiber is preferred for distance, bandwidth, or electrical isolation.
What speed does it support?
A: The module supports 10 Gigabit Ethernet through an SFP+ interface.
10GbE provides high-speed aggregation capacity for multiple networked AV streams and switch-to-switch connections.
What fiber type is required?
A: This model is designed for single-mode fiber using its specified optical design.
The fiber plant must match the module type because wavelength, modal behavior, and optical budget determine compatibility.
What is its maximum distance?
A: The specified reach is up to 2 km for the intended fiber configuration.
Actual reach depends on fiber quality, connector condition, optical loss, and a compatible transceiver at the other end.
What wavelength does it use?
A: The optical design operates around 1310 nm for the specified transmission mode.
Matching wavelength and fiber characteristics at both ends is essential for a stable optical Ethernet link.
Does it use LC duplex?
A: Yes, the module uses an LC duplex fiber connector.
The duplex connector provides separate transmit and receive paths and requires correct fiber polarity and clean connectors.
Is it hot-swappable?
A: Yes, the SFP+ module is designed for hot-swappable installation in compatible switch ports.
This makes maintenance and optical-link changes easier without replacing the network switch itself.
Is it suitable for AV-over-IP?
A: Yes, it is intended to expand high-speed optical connectivity between compatible M4250 switches in AV-over-IP systems.
Fiber uplinks can aggregate multiple AV streams and connect switches across longer physical paths.
Which switches use it?
A: It is designed as an accessory for compatible NETGEAR M4250 managed switches with SFP+ interfaces.
Always verify the exact switch and transceiver compatibility before installation and match optics at both ends.
What should installers check?
A: Installers should verify SFP+ port compatibility, fiber type, polarity, connector cleanliness, optical budget, and distance.
Following these checks helps prevent link loss and ensures the 10GbE optical connection operates within specification.
