HDTV Supply′s WolfPack 5x1 HDMI Switcher with HDMI 2.0 Compliancy was designed to support a new display technology called 4K. The 5x1 HDMI Switch with HDMI 2.0 Compliancy was created to improve the contrast between light and dark images for a more realistic picture featured in new 4K TVs. Since 4K is four times the resolution of 1080p, it required more bandwidth to support the extra data and that is why we have designed these HDMI switchers with HDMI 2.0 Compliancy.
Our WolfPack 5x1 HDMI 2.0 Switcher supports the latest 4K TVs, the NVidia Shield and the latest graphics cards with HDMI 2.0. To enjoy 4K 60Hz video be sure to use the TV′s HDMI port labeled with HDMI 2.0. HDMI 1.4 ports only support 4K at 30Hz. The IR receiver is not built into the box but instead is attached to a long wire plugged into a mini jack on the front of the switch so it simplified cable management.
Newer TVs and AV surround sound receivers have only one HDMI 2.0 and HDCP 2.2 input and output so this HDMI 2.0 switcher will allow you to have up to 5-source devices using HDMI 2.0 and HDCP 2.2 compliantcy. Also HDMI 1.4 supported 4K resolutions but only at 24 or 30 frames per second and HDMI 1.4 limits 4K content to 8-bit color. Our new HDMI 2.0 products can handle 4K video up to 60 frames per second and up to 10.2 gigabits per second.
WolfPack 5x1 HDMI Switcher with HDMI 2.0 Compliancy Features
5-HDMI input signals switched to 1-HDMI device
HDMI 2.0 compliant on all inputs and the output
HDCP 2.2 protocol compliant on all inputs and the output
4K Sony PS4 Pro
Samsung UHD 4K DVD Player
Roku 4 media player
4K DirecTV Genie receivers
4K Sony FMP-X10 UHD players
4K NVidia Shield UHD Netflix devices
4K Amazon Fire Players
4K Surround Sound AV Receivers
and more 4K HD HDCP 2.2 devices
3D video format support including frame packing for all 3D formats up to a 297MHz ™DS clock rate.
Supported video display resolutions:
Supported video format up to 4Kx2K @ 30Hz with 24bit
RGB/YcbCR 4:4:4 / YCBCR 4:2:2 and to 4Kx2K @ 60Hz with 12bit
Up to 1080p @ 120Hz
Up to 1080p 3D @ 60Hz and
All lower resolutions
Supported deep color bit rates:
36 bits and
48 bits per pixel
Supported Digital audio formats:
Our 5x1 HDMI 2.0 Switcher distributes 5-HDMI sources to 1-HDMI displays. It can handle video up to a 4K at 60 frames per second and up to 10.2 gigabits per second assuring you of the finest 4K picture you can get.
Why not buy this WolfPack 5x1 HDMI Switcher with HDMI 2.0 Compliancy today?
Even if you do not need HDMI 2.0 compliancy today you may in the future so why not buy this HDMI 2.0 Switcher so you can be prepared when you get 4K products in the future?
5x1 HDMI Switcher with HDMI 2.0 Compliancy Features
4K@50/60, (2160p), which is 4 times the clarity of 1080p/60 video resolution
Up to 32 audio channels for a multi-dimensional immersive audio experience
Up to 1536kHz audio sample frequency for the highest audio fidelity
Support for the wide angle theatrical 21:9 video aspect ratio
Dynamic synchronization of video and audio streams
CEC extensions provides expanded command and control of consumer electronics devices through a single control point
Q: What are the remote control HEX codes?
A: See the below that can be used on our 3x1 and 5x1 HDMI 2.0 switchers:
#define SYS_CODE 0x02
#define IR_INPUT_1 0xde
#define IR_INPUT_2 0xda
#define IR_INPUT_3 0xdb
#define IR_INPUT_4 0x55
#define IR_INPUT_5 0xdf
Q: Does HDMI 2.0 support BT.2020 (rec.2020) colorimetry?
A: Yes. HDMI 2.0 includes support for BT.2020 Colorimetry with 10 or more bits of color depth. Video Formats defined in BT.2020 and supported by the HDMI 2.0 specification are:
2160p, 10/12 bits, 24/25/30Hz, RGB/4:2:2/4:4:4
2160p, 10/12 bits, 50/60Hz, 4:2:0/4:2:2
Q: This product has CEC, what is CEC?
A: This product features CEC (Consumer Electronics Control) allowing your HDTV's remote to manage up to ten devices that are connected via HDMI (such as Blu-ray Disc players or home theater receivers) with no special programming needed. For example, you can use your remote to turn on your TV, your player, and your receiver at the same time, and adjust the system volume with one button. All devices must support CEC, though.
Most major TV manufacturers now support CEC, and an HDTV with HDMI 1.3 will likely have the technology. Manufacturers call it by different names; LG Electronics, for instance, calls its implementation SimpleLink, whereas Toshiba calls its version CE-Link. Interoperability isn't mandatory, so some manufacturers limit control to their own products; Sony, for one, allows only Sony-to-Sony communication.
Why not buy this 5x1 HDMI Switcher with HDMI 2.0 Compliancy today?
Click Here for Product Warranty
Ask a Question
Questions & Answers
Ask a question about the WolfPack 4K 5x1 HDMI 2.0 Switcher w/HDCP 2.2 - 1 Year Warranty or Call 833-WOLFPACK (833-965-3722)
