HDTV Supply's WolfPack 4K 30 Hz 4x4 Seamless HDMI Matrix with Video Wall, Splicing, Capture & Multi-Viewer Modes is a HDMI Multi-Function Controller, which integrates the functions of Video Capture, Video Matrix,Quad Multi-Viewer and Video Splicer, and can be switching the function by pressing front panel keys or via its IR remote control.
The video capture function can be combined with the other three functions.
WolfPack 4K 30 Hz 4x4 Seamless HDMI Matrix with Video Wall, Splicing, Capture & Multi-Viewer Modes Features:
Input & Output Port: The 4x4 Video Matrix Switch uses 4-HDMI video inputs, 4-HDMI output and supports 4K 30 Hz and HDMI 1.4 and HDCP 1.4.
Operation is with a Remote Control: Use an infrared remote control to operated the matrix.
Supports One Key Black & One Key Freeze: When the image output needs to be closed during its use, the front panel black screen key can be used to operate the fast black screen. During playback, it may be necessary to freeze the current picture to operate and "pause" picture (combined with current functions).
Supports Audio Sync Output and One Key Mute: HDMI audio and video can be a synchronized output by selecting the corresponding video input source with the remote control or key and output synchronously corresponding to different audio sources The audio output port is independent.
Video Capture: The output interface on output 4 can be used for real-time HDMI audio and video capture. The audio and video signals can be transmitted to computers or intelligent phones for preview and storage. It is suitable for high-definition acquisition, teaching recording, medical video transcribe etc.
It supports most capture software such as VLA, OBS, Amcap, etc., as well as it support Windows, Android and MacOS. It complies with the USB video UVC specification and USB Audio UAC specification.
Video Matrix: The 4x4 HDMI Matrix Switch seamlessly switches any input channel to any output channel for display by pressing the key or the remote control The remote can control the specified input channel to the specified output channel in real time to a display.
Quad Multi-Viewer: Multiple input signals can be displayed on one monitor at the same time according to the built-in template parameters, such as double Windows, four picture windows and more.
The output channels of this function are output 1 & 4 and 1 & 4 channels are in the copy the mode. The output 2 & 3 channels can continue to use the matrix function by using the remote control.
Video Splicer: You can divide the image signal of the HDMI 1 channel into "n" blocks and distribute them to "n" video display units (such as 2 splicing, 3 splicing and 4 splicing). In addition to the 1 & 4 splicing mode, the remaining redundant channels in the 2 & 3 splicing mode can continue to use the matrix function;
Why not buy this WolfPack 4K 30 Hz 4x4 Seamless HDMI Matrix with Video Wall, Splicing, Capture & Multi-Viewer Modes today?
WolfPack 4K 30 Hz 4x4 Seamless HDMI Matrix with Video Wall, Splicing, Capture & Multi-Viewer Modes Specifications:
- Brand: WolfPack
- Name: HDTV4x4AMSMTX
- HDMI Ports: Interface Type: HDMI-A Female Connector
- 4-HDMI INPUTS: Signal Standard: HDMI1.4 Backward compatible
- 4-HDMI OUPUTS: Resolution: VESA Standard, ≤3840×2160p@30Hz
- AUDIO OUT: Audio Output Interface, Dual Track
- Power Supply: Internal 100~240V AC, 50~60Hz
- Temperature:
- Storage: T: -104 Degree F ~ +176 Degree F, H: 10% ~ 90%, Non-condensing
- Working: T: 0 Degree F ~ +140 Degree F, H: 10% ~ 90%, Non-condensing
- Matrix Size: 14.57 in (Length) x 7.28 in (Width) x 1.38 in (Height) (Including Ear Hook)
- Packing Size: 16.54 in (Length) x 10.04 in (Width) x 3.35 in (Height)
- Product Weight: Gross Weight : 4.40 lbs
- Package Weight: Volume Weigh: 6.60 lbs
- Warranty: 3 Years
Why not buy this WolfPack 4K 30 Hz 4x4 Seamless HDMI Matrix with Video Wall, Splicing, Capture & Multi-Viewer Modes today?
Which HDMI and HDCP versions does the matrix support?
A: ,The matrix supports HDMI 1.4 and HDCP 1.4.
Can I capture HDMI output to a computer or phone from this device?
A: Yes — the output on output 4 can be used for real-time HDMI audio and video capture to computers or phones.
Which operating systems and capture software are supported for capture?
A: The device supports Windows, Android and MacOS and works with capture software such as VLA, OBS, and Amcap.
Does the device present captured video as a standard UVC/UAC device?
A: Yes — it complies with the USB Video Class (UVC) and USB Audio Class (UAC) specifications.
How does the Video Splicer (video wall) function allocate outputs?
A: The splicer splits one HDMI input into multiple blocks and distributes them to multiple displays (2-, 3- or 4-splice modes); in 1 & 4 splicing the remaining channels are redundant, and in 2 & 3 splicing the other channels can still be used as a matrix.
Can the video capture function be used at the same time as other functions?
A: Yes — the video capture function can be combined with the other functions.
How do I switch inputs to outputs and control the matrix?
A: You can switch any input to any output using the front-panel keys or the included infrared remote control in real time.
Will this unit work as a live-recording interface for lecture or medical capture?
A: Yes — the product describes suitability for high-definition acquisition tasks such as teaching recording and medical video transcribe when using the output-4 capture function.
Do I need special capture software to record from this matrix?
A: You do not need proprietary software — the matrix supports common capture programs like VLA, OBS, and Amcap and presents as UVC/UAC devices for compatible software.
