Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder

Osprey Video

Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder

DISCONTINUED, PLEASE CONTACT US FOR ITS REPLACEMENT

Part Number:
Talon 4K-SCD
UPC:
850010356150
Condition:
New
1:
Enhanced Security Features
2:
Network Time Protocol
3:
Remote Firmware Upgrade
4:
Fanless Operation
5:
Free USA Shipping
6:
2-Year Osprey Warranty

Out of stock

We are sorry but the Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder is no longer available and has been discontinued by the manufacturer. We've left this page up for reference only.

Please call us at 833-965-3722 immediately for the replacement product.

This Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder, Encode, scale, and convert up to DCI 4K60 video for streaming and archiving with the Talon 4K-SC 12G-SDI/HDMI Hardware Video Encoder from Osprey. The decoder supports input of up to 4096 x 2160p60 video via one HDMI 2.0 and one 12G-SDI input, and output via USB 3.1 Gen 1, NVME, or network storage for archiving. There is also a 12G-SDI loop output for previewing your video. The decoder supports simultaneously streaming your video while archiving the stream to a hardware or network drive.

This professional decoder supports up to 10-bit 4:2:2 color depth, deinterlacing, upscale and downscale, frame rate conversion, H.265/HEVC and H.264/MPEG-4/AVC encoding, eight channels of AAC-LC audio via HDMI, and sixteen channels of AAC-LC audio via SDI. You can stream video via its Gigabit Ethernet port using a variety of protocols such as RTMP, RTSP, RTP, and UDP, and it supports a variety of CDN integrations. You can save to MP4 and TS files via the USB 3.1 Gen 1 Type-A output, via the Ethernet port, and it supports NVME archiving using a separately available drive.

The decoder also supports SRT secure reliable transport protocol with multiple security features, remote firmware upgrade, embedded closed captioning, a JSON REST API, and password protection. A status display shows the current settings of the unit, and status LEDs indicate active ports. It features a fanless design and has a locking power jack.

Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder Features:

Software Features

  • Enhanced Security Features
  • Remote Firmware Upgrade from Web
  • Network Time Protocol
  • JSON REST API for software integration
  • Password Protected
  • Embedded Closed Caption support
  • SMPTE 2038 Support

Hardware Features

  • Fanless Operation
  • Locking Power Jack
  • Status Display
  • Status LED's
  • GigE Ethernet connection

Why not buy this Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder today?

Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder Specifications:

  • Video Inputs:
    • 1 x 12G-SDI with Loopout
    • 1 x HDMI 2.0 (non-HDCP)
  • Audio Inputs:
    • Embedded SDI 16Ch of audio (8 stereo pairs)
    • Embedded HDMI 8Ch of audio (4 stereo pairs)
  • Video Input Resolution:
    • Up to 4096 x 2160 (DCI) 60fps
  • Color Depth:
    • Up to 10-bit 4:2:2
  • Video Archiving:
    • USB 3.0
    • Network Storage
  • Streaming Transports:
    • RTMP, UDP, RTP, SRT™, Zixi™
    • Number of Output Channels 1
    • Number of concurrent input channels 1
    • Simultaneous streaming and save to file
    • Saving to MP4 file
  • Video Processing:
    • Upscale/Downscale, Frame rate Conversion,
    • Deinterlacing
  • Video Compression:
    • H.264 (AVC), H.265 (HEVC)
  • Encoding Controls:
    • Bitrate up to 100Mbps
    • VBR & CBR
  • Audio Compression:
    • AAC-LC
  • Audio Sample Rate:
    • 44.1kHz, 48kHz
    • Audio Bitrate 64Kbps to 512Kbps
  • Mechanical:
    • 5.5 x 5.5 x 1.5"
    • Operating Temperature 0 to 40C
    • Power 12V | 28W max

Why not buy this Osprey Talon 4K-SCD Talon Pro 4K60 12G-SDI/HDMI Decoder today?

What Is a WolfPack Fixed HDMI Matrix Switcher?

A WolfPack Fixed HDMI Matrix Switcher is a single-chassis device that routes any HDMI source — such as a cable box, satellite receiver, streaming player, or computer — to any TV or display in a building, simultaneously and independently. Unlike an HDMI splitter (which sends one source to many screens) or a simple HDMI switch (which selects one source for one screen), a matrix switcher lets you show a different channel on every TV at the same time. HDTV Supply has sold WolfPack fixed matrix switchers to sports bars, restaurants, hotels, churches, schools, and commercial AV integrators since 2000.

Fixed vs. Modular: Which Do You Need?

WolfPack comes in two families: Fixed and Modular. Fixed matrix switchers have a set number of inputs and outputs built into one box — for example, 4 inputs × 4 outputs (4×4) or 8 inputs × 8 outputs (8×8). They are plug-and-play, rack-mountable, and the right choice when your input/output count won't change. Modular matrix switchers use a chassis with swappable I/O cards, scaling from a few ports up to 80×80 or beyond. If you know exactly how many sources and screens you need today, a fixed unit is typically lower cost and simpler to deploy.

Available Fixed WolfPack Configurations

HDTV Supply offers WolfPack Fixed HDMI Matrix Switchers in the following sizes:

  • 4Ă—2 — 4 sources to 2 displays
  • 4Ă—4 — 4 sources to 4 displays
  • 8Ă—8 — 8 sources to 8 displays
  • 8Ă—9 — 8 sources to 9 displays
  • 16Ă—16 — 16 sources to 16 displays
  • 16Ă—32 via CAT6 — extends signal up to 450 feet over CAT6 cable

Select models include built-in video wall processing, multiview, and picture-in-picture (PIP) — allowing two or more sources to display on a single screen simultaneously.

Control Options for Fixed Matrix Switchers

Every WolfPack Fixed HDMI Matrix Switcher supports multiple control methods so you can integrate it into any environment:

  • Front-panel buttons — manual source switching directly on the unit
  • IR remote control — included with most models
  • RS-232 serial control — for integration with Crestron, Control4, AMX, and similar systems
  • TCP/IP (LAN) control — send hex commands over your network from any device
  • Web GUI — browser-based interface for switching without additional software
  • Free iOS and Android apps — available for select WolfPack models

For RS-232 hex command strings and TCP/IP control protocols, see our WolfPack HEX Code Reference and TCP/IP Control Guide.

Frequently Asked Questions

What is the difference between a fixed HDMI matrix switcher and a modular HDMI matrix switcher?

A fixed HDMI matrix switcher has a set number of HDMI inputs and outputs built into a single unit — for example, 8 inputs and 8 outputs. A modular matrix switcher uses a chassis with interchangeable I/O cards, so you can configure it for many different port counts and expand it later. Fixed units are simpler and more affordable; modular units offer flexibility for larger or changing installations.

Can a WolfPack fixed matrix switcher show different channels on different TVs at the same time?

Yes. A matrix switcher routes any input to any output independently. In an 8×8 configuration, all 8 displays can show 8 completely different sources simultaneously, or multiple displays can share the same source — in any combination you choose.

Can I control a WolfPack fixed matrix switcher from a Crestron or Control4 system?

Yes. WolfPack Fixed HDMI Matrix Switchers support RS-232 and TCP/IP control, which are standard integration protocols supported by Crestron, Control4, AMX, and other third-party control systems. HDTV Supply provides hex command strings and driver documentation to support custom integrations.

What resolution do WolfPack Fixed HDMI Matrix Switchers support?

Resolution support varies by model. WolfPack fixed matrix switchers are available in 1080p (Full HD) and 4K 30Hz configurations. Select 4K models also support HDR and HDCP 2.2. Always check the individual product specification sheet for confirmed resolution, color depth, and HDCP version.

How far can I run HDMI from a WolfPack fixed matrix switcher?

Standard HDMI outputs on fixed matrix switchers support runs up to approximately 25–50 feet depending on cable quality and resolution. The WolfPack 16×32 model transmits over CAT6 cabling for distances up to 450 feet per run. For longer distances with other fixed models, HDMI extenders can be added at each display.

What is the best HDMI matrix switcher for a sports bar?

For sports bars with up to 16 TVs, a WolfPack Fixed 16×16 HDMI Matrix Switcher is a popular choice — it handles 16 independent sources (cable boxes, satellite receivers, streaming devices) and routes any of them to any TV. For larger venues with 20–80+ TVs, HDTV Supply's WolfPack Modular Matrix Switchers or AV Over IP systems are typically the better fit. Call 833-WOLFPACK (833-965-3722) for a free consultation.
