This Atlona AT-OME-RX31 3x1 AV Switcher & Dual HDBaseT Receiver With Scaler & HDMI Input is an HDBaseT receiver, three-input switcher, and 4K/UHD scaler with a local HDMI input. Part of the Omega™ Series of integration products for modern AV communications and collaboration, the OME-RX31 features two HDBaseT inputs for receiving video up to 4K/60 4:2:0, plus embedded audio, control, and Ethernet over distances up to 330 feet (100 meters).
The HDMI input supports video up to UHD/60 4:4:4. The OME-RX31 is HDCP 2.2 compliant and features 4K/60 upscaling and downscaling with frame rate conversion. Additionally, it provides integrated control for displays and room functions such as motorized screens, and can be externally triggered with the addition of an occupancy sensor. The OME-RX31 is ideal for 4K presentation applications with Omega or UHD-EX Series transmitters, as well as Atlona AV presentation switchers with HDBaseT outputs, local HDMI sources, and the Gain™ Series amplifiers.
Versatile scaler, switcher, and extender: The OME-RX31 combines the benefits of 4K/UHD scaling, auto-switching for HDBaseT and HDMI inputs, integrated display control, room controls, and more. It incorporates many popular integration convenience features, while delivering excellent performance and value for 4K presentation and video conferencing applications. The OME-RX31 can remotely power two Atlona transmitters over HDBaseT. For additional integration convenience, the OME-RX31 features audio de-embedding, integrated two-port Ethernet switch, contact closure ports for controlling a motorized screen or display lift, trigger I/O ports for button controls or an occupancy sensor, internal video test patterns for setup and troubleshooting, and remote management with Velocity Device Manager.
Automatic Display Control: The OME-RX31 can provide control to a display through TCP/IP, RS-232, or CEC*, without the need for a separate control system. This simplifies system design and integration while reducing costs. With automatic display control, the OME-RX31 can trigger a display to power on automatically whenever a laptop or other device is connected to the OME-RX31. At the end of the presentation, when the presenter disconnects the laptop, the OME-RX31 forces the display to power off. Ease of presenter interaction with the system, and the savings incurred by automatic display shutdown provide a significant return on investment. The OME-RX31 display control capability can also be triggered by an external control system.
Atlona AT-OME-RX31 3x1 AV Switcher & Dual HDBaseT Receiver With Scaler & HDMI Input Feature:
- Dual HDBaseTTM receiver for HDMI® video, Ethernet, power, and control
- Local HDMI input
- 4K/UHD downscaling and upscaling
- Supplies power over HDBaseT to a transmitter
- Audio de-embedding
- Dual Ethernet ports and integrated network switch
- Two relays provide control for motorized screen, shades, or display lift
- Trigger I/O ports for occupancy sensing
- Dual HDBaseT receiver with local HDMI input
- Video, audio, power, and data over category cable utilizing HDBaseT technology
- 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling for HDMI input and output
- HDCP 2.2 compliant
- Advanced 4K/UHD scaling with selectable frame rate conversion
- 4K/UHD downscaling and upscaling
- Advanced motion-adaptive deinterlacing for 1080i input signals
- Internal video test patterns for setup, calibration, and troubleshooting
- Automatic input selection using hot plug detect and video detection technology
- Front panel power and signal status LEDs
- Low-profile, 1.02 inch (26 mm) high enclosure
Atlona AT-OME-RX31 3x1 AV Switcher & Dual HDBaseT Receiver With Scaler & HDMI Input Specifications:
| Video | |
|---|---|
| HDMI | 2.0 |
| HDCP | 2.2 |
| UHD / HD Resolutions | |
| 4096×2160 | 60(1)/50/30/25/24 Hz |
| 3840×2160 | 60(1)/50/30/25/24 Hz |
| 1920×1080p | 60/59.9/50/30/29.97/25/24/23.98 Hz |
| 1920×1080i | 30/29.97/25 Hz |
| 1280×720p | 60/59.94/50 Hz |
| 720×576p | 50 Hz |
| 720×576i | 50 Hz |
| 640×480p | 60/59.96 Hz |
| 640×480i | 30 Hz |
| VESA Resolutions (60 Hz) | |
| 2560×1600, 2048×1536, 1920×1200, 1680×1050, 1600×1200, 1440×900, 1400×1050, 1280×1024, 1280×800, 1366×768, 1360×768, 1152×864, 1024×768, 800×600, 640×480 |
|
| VESA 21:9 | |
| 2560×1080 | 30 Hz 4:4:4, 60 Hz 4:4:4 |
| 3440×1440 | 30/50 Hz 4:4:4 |
| 3840×1600 | 30 Hz 4:4:4 |
| Scaler Output | |
| 1024×768 @ 60 Hz, 1280×720 @ 50/60 Hz, 1280×768 @ 60 Hz, 1280×800 @ 60 Hz, 1360×768 @ 60 Hz, 1600×1200 @ 60 Hz, 1920×1080 @ 24/25/50/60 Hz, 1920×1200 @ 60 Hz, 2048×1080 @ 60 Hz, 3840×2160 @ 24/25/30/50/60 Hz, 4096×2160 @ 24/25/30/50/60 Hz |
|
| Color Space | YUV, RGB |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 |
| Color Depth | 8-bit, 10-bit, 12-bit |
| HDR | HDR10, HLG, Dolby Vision @ 60 Hz |
| Audio | |
| HDMI Pass-Through Formats | LPCM 2.0, LPCM 5.1, LPCM 7.1, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS Digital Surround, DTS-HD Master Audio, DTS:X |
| Bit Rate | 24 Mbps max |
| Analog Audio | |
| Format | 2-channel stereo |
| Balanced Output | +4 dBu nominal, +20 dBu headroom |
| Frequency Response | 20 Hz – 20 kHz, ±0.5 dB |
| THD+N | < 0.004% |
| SNR | > 104 dB @ 1 kHz |
| Sample Rates | 32–192 kHz |
| Control | |
| RS-232 | 2400–115200 baud; device control/configuration |
| Trigger | Occupancy sensor; 30 V @ 1 A max |
| Relay | NO; Toggle & Pulse; 48 V @ 1 A |
| IP | HTTPS, Telnet, mDNS; DHCP / Static modes |
| CEC | Yes |
| Resolution / Distance | |
| HDMI IN/OUT | 4K: 15 ft (5 m) • 1080p: 30 ft (10 m) |
| CAT5e | 4K: 295 ft (90 m) • 1080p: 330 ft (100 m) |
| CAT6/6a/7 | 4K/1080p: 330 ft (100 m) |
| Connectors & Controls | |
| HDMI IN | 1 × Type A |
| HDMI OUT | 1 × Type A |
| Audio Out | 1 × 5-pin captive screw |
| Trigger I/O | 1 × 4-pin captive screw |
| RS-232 | 1 × 5-pin captive screw |
| Relay | 1 × 3-pin captive screw |
| LAN | 2 × RJ45 |
| HDBaseT | 2 × RJ45 |
| Power | 1 × 4-pin DIN |
| Control Buttons | SHOW IP, INPUT; IP MODE, RESET |
| Indicators | PWR, INPUT, IP MODE, RESET (LED) |
| Environmental | |
| Operating Temperature | 32–122 °F (0–50 °C) |
| Storage Temperature | -4–140 °F (-20–60 °C) |
| Humidity | 20%–90%, non-condensing |
| Power | |
| Consumption | 8.1 W |
| BTU/h | 27.6 |
| External Power Supply | 100–240 V AC; Output: 24 V / 2.7 A DC |
| Dimensions | |
| Unit (H × W × D) | 1.02 × 8.62 × 5.98 in (26 × 219 × 152 mm) |
| Power Supply | 1.26 × 1.93 × 4.69 in (32 × 49 × 119 mm) |
| Weight | |
| Device | 2.15 lb (0.975 kg) |
| Certification | |
| Device | CE, FCC |
| Power Supply | CE, FCC, UL |
Atlona AT-OME-RX31 3x1 AV Switcher & Dual HDBaseT Receiver With Scaler & HDMI Input Manuals:
Atlona AT-OME-RX31 User Manual
