This Atlona AT-OME-RX11 HDBaseT Receiver With Audio De-Embedding is an HDBaseT receiver for video up to 4K/60 4:2:0, plus embedded audio, control, and Ethernet over distances up to 330 feet (100 meters). Part of the Omega™ Series of integration products for modern AV communications and collaboration, the OME-RX11 is HDCP 2.2 compliant and receives RS-232 and IP control signals. Additionally, this receiver features two-channel audio de-embedding to a balanced analog audio output. The OME-RX11 is locally powered, and can deliver remote powering over HDBaseT to an Atlona Omega Series, HDVS-200 Series, or AT-UHD-EX-100CE-TX-PD transmitter.
The OME-RX11 incorporates many popular integration convenience features, while delivering excellent performance and value for 4K presentation applications. The Ethernet port on the OME-RX11 is for IP pass-through with the transmitter.
Atlona AT-OME-RX11 HDBaseT Receiver With Audio De-Embedding Feature:
- Video, audio, power, and data over category cable utilizing HDBaseT technology
- Receives 4K/UHD video up to 330 feet (100 meters) with CAT6/6a/7 cable, or up to 295 feet (90 meters) using CAT5e cable.
- Uses easy-to-integrate category cable for low-cost, reliable system installation.
- 4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling
- Compatible with sources up to 4K/60 4:2:0 and 4K/30 4:4:4.
- Supports HDMI data rates up to 10 Gbps from PCs, media players, and Ultra HD Blu-ray players.
- HDCP 2.2 compliant
- Adheres to latest specification for High-bandwidth Digital Content Protection.
- Allows protected content stream to pass between authenticated devices.
- HDBaseT transmitter or switcher must also be HDCP 2.2 compliant.
- Local powering
- Supplies IEEE 802.3af PoE over HDBaseT to an Omega Series transmitter.
- Includes AC power supply.
- Audio de-embedding
- De-embeds two channel PCM audio to a balanced, analog audio output.
- Delivers audio to an amplifier and speakers for sound reinforcement.
- Multi-channel audio compliant
- Passes through multi-channel audio formats.
- Supports PCM, Dolby® Digital, Dolby Digital Plus™, Dolby TrueHD, Dolby Atmos®, DTS® Digital Surround™, DTS-HD Master Audio™, and DTS:X®.
- Field-updatable firmware
- Device can be updated in the field via the USB port.
- Front panel power and signal status LEDs
- LED indicators provide power and HDBaseT link status information.
- Provides convenient setup and troubleshooting.
- Low-profile, 1.02 inch (26 mm) high enclosure
- Easy installation into confined spaces below tables, in furniture, and behind or above displays.
- Included accessories
- Installation guide, surface mounting hardware, and external universal power supply.
Why not buy this Atlona AT-OME-RX11 HDBaseT Receiver With Audio De-Embedding from HDTV Supply today?
Atlona AT-OME-RX11 HDBaseT Receiver With Audio De-Embedding Specifications:
- Video
- HDMI: 2.0
- HDCP: 2.2
- UHD/HD/SD Resolutions:
- 4096×2160@60/50/30/25/24Hz
- 3840×2160@60/50/30/25/24Hz
- 1080p@60/59.9/50/30/29.97/25/24/23.98Hz
- 1080i@30/29.97/25Hz
- 720p@60/59.94/50Hz
- 576p@50Hz
- 576i@25Hz
- 480p@60/59.96Hz
- 480i@30Hz
- VESA Resolutions:
- 2560×1600
- 2048×1536
- 1920×1200
- 1680×1050
- 1600×1200
- 1440×900
- 1400×1050
- 1280×1024
- 1280×800
- 1366×768
- 1360×768
- 1152×864
- 1024×768
- 800×600
- 640×480
- Color Space: YUV, RGB
- Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
- Color Depth: 8-bit, 10-bit, 12-bit
- Audio
- HDMI Pass-Through Formats:
- PCM 2.0
- LPCM 5.1
- LPCM 7.1
- Dolby® Digital
- Dolby Digital Plus™
- Dolby TrueHD
- Dolby Atmos®
- DTS® Digital Surround™
- DTS-HD Master Audio™
- DTS:X®
- Bit Rate: 24 Mbits/s max
- Analog Audio:
- Format: Stereo 2-Channel
- Output Level: L: 5.883 Vrms, R: 5.855 Vrms
- Frequency Response: 20 Hz to 20 kHz
- THD+N: < 0.00009% at 20 Hz to 20 kHz
- SNR: > 141.49 dB at 1 kHz
- Sample Rate: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
- HDMI Pass-Through Formats:
- Control
- RS-232: 2-way device control and monitoring
- Supported baud rates: 2400, 4800, 9600, 19200, 38400, 57600, 115200
- CEC Support: Yes
- RS-232: 2-way device control and monitoring
- Resolution / Distance
- HDMI IN/OUT: 15 ft (5 m) @ 4K/UHD, 30 ft (10 m) @ 1080p
- CAT5e: 295 ft (90 m) @ 4K/UHD, 330 ft (100 m) @ 1080p
- CAT6/6a/7: 330 ft (100 m) @ 4K/UHD, 330 ft (100 m) @ 1080p
- Connectors, Controls, and Indicators
- HDBaseT IN: 1 – RJ45, female
- HDMI OUT: 1 – Type A, 19-pin female
- AUDIO OUT: 1 – 5-pin captive screw, balanced / unbalanced 2-channel
- RS-232: 1 – 3-pin captive screw (bidirectional)
- LAN: 1 – RJ45, 100Base-T
- FW: 1 – Mini-USB, 5-pin female
- DC 24V: 1 – 4-pin, mini-DIN locking connector
- PWR Indicator: 1 – LED, green
- LINK Indicator: 1 – LED, yellow
- Environmental
- Operating Temperature: 32 to 122°F (0 to 50°C)
- Storage Temperature: -4 to 140°F (-20 to 60°C)
- Humidity (RH): 20% to 60%, non-condensing
- Power
- Consumption: 15.12 W
- Supply:
- Input: 100 – 240 VAC, 50/60 Hz
- Output: DC 24 V / 2.7 A
- Dimensions
- Unit (H x W x D): 1.02 x 4.29 x 5.24 in (26 x 109 x 133 mm)
- Power Supply: 1.26 x 1.93 x 4.69 in (32 x 49 x 119 mm)
- Weight
- Device: 0.90 lb (0.41 kg)
- Certification
- Device: CE, FCC
- Supply: CE, FCC, UL
