This Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit is a slimline HDBaseT extender pair that can transmit HDMI signals of up to 4K 60Hz (4:2:0 8-bit) along 70m of category cabling.
CAT6 cable supports 4K 60Hz (4:2:0 8-Bit) up to 70m and 1080p 60Hz HDMI signals can also be extended up to 100m. CAT6A / 7 cabling offers increased distances of 100m for 4K 60Hz (4:2:0 8-Bit) resolutions.
The AT-AVA-F1311 also features bi-directional PoC, two-way IR and RS232 pass-through.
The AT-AVA-F1311 is a slimline HDBaseT extender pair that can transmit HDMI signals of up to 4K 60Hz (4:2:0 8-bit) along 100m of category cabling.
CAT6 cable supports 4K 60Hz (4:2:0 8-Bit) up to 70m and 1080p 60Hz HDMI signals can also be extended up to 100m. CAT6A / 7 cabling offers increased distances of 100m for 4K 60Hz (4:2:0 8-Bit) resolutions.
The AIM-100 also features bi-directional PoC, two-way IR and RS232 pass-through.
With the built-in control pass-through, users can control the source from the displays location or can control the display from the sources location.
And, with their small form factor, the extenders are easy to install in many locations.
Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit Feature:
- Supports resolutions up to 4K@60Hz 4:2:0 8bit and HDCP 2.2.
- Over a Cat 6a/7 cable, extends 4K@60Hz 4:2:0 8bit and 1080P up to 70m.
- Over a Cat 5e/6 cable, extends 4K@60Hz 4:2:0 8bit up to 70m/230ft and 1080P up to 70m.
- Bi-directional PoC, one power adapter at either transmitter or receiver side can power both units.
- Supports bi-directional IR and RS232 pass-through
Why not buy this Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit from HDTV Supply today?
Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit Specifications:
- HDMI Compliance: HDMI 21.4
- HDCP Compliance: HDCP 2.2
- Video Bandwidth: 10.2 Gbps
- Video Resolution: 4K@60Hz (8-bit 4:2:0), 4K@30Hz, 1080p, 1080i, 720p
- Color Depth: 8/10/12-bit (4K@60Hz), 16-bit (1080p@60Hz)
- HDMI Audio Formats: PCM 2.0/2.1/5.1/6.1/7.1, Dolby Atmos, Dolby TrueHD, DTS-ES, DTS HD Master, DTS-X
- Resolution/Distance:
- 4K60: Cat6a/7: 328 ft (100m)
- 1080p:
- Cat5e/6: 220 ft (70m)
- Cat6a/7: 328 ft (100m)
- Note: Premium High Speed HDMI cable is highly recommended.
- Operating Temperature: 0°C to 45°C (32°F to 113°F)
- Storage Temperature: -20°C to 70°C (-4°F to 140°F)
- Humidity: 10% to 90%, non-condensing
- Power Consumption: 13W (Pair, PoC)
- Power: 1x DC 18V/2A (included)
- Dimensions: 135mm W x 14mm H x 77mm D (5.3" W x 0.6" H x 3" D)
- Weight: 220g (0.485 lbs.)
Why not buy this Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit from HDTV Supply today?
Atlona AT-AVA-F1311 User Manual
Why not buy this Atlona AT-AVA-F1311 70m Avance HDBT Transmitter & Receiver Kit from HDTV Supply today?
What is the Atlona AT-AVA-F1311?
A: The AT-AVA-F1311 is a slimline HDBaseT transmitter and receiver kit for extending HDMI video and control over category cable.
It supports 4K/UHD video and combines video extension with bidirectional power, IR, and RS-232 pass-through for professional AV installations.
What video resolution does it support?
A: It supports up to 4K at 60Hz with 4:2:0 8-bit color and HDCP 2.2.
It can also transport 1080p60 signals, with actual performance depending on the source, display, cable, and HDCP chain.
How far can it extend 4K video?
A: The system can extend 4K60 4:2:0 8-bit video over long category-cable runs, including up to 100 meters with suitable CAT6A/CAT7 cabling.
Cable category, termination quality, and installation conditions affect the achievable distance, so the specified limits should be followed.
Does it support Power over Cable?
A: Yes, bidirectional PoC allows one power adapter at either endpoint to power both the transmitter and receiver.
This simplifies installations by reducing the need for separate local power supplies at both ends of the HDBaseT link.
Does it support IR and RS-232?
A: Yes, bidirectional IR and RS-232 pass-through are supported over the HDBaseT connection.
This allows source or display control from the opposite end of the extension link and supports integration with AV control systems.
What cable is required?
A: The extender uses category cable, with CAT6A/CAT7 recommended for high-performance 4K installations.
Proper cable termination and routing are important for maintaining HDBaseT signal integrity and reliable long-distance operation.
Is HDCP 2.2 supported?
A: Yes, the AT-AVA-F1311 supports HDCP 2.2 for compatible protected 4K/UHD content.
The source, extender, and display must all support compatible HDCP behavior for protected content to pass successfully.
Can it extend 1080p farther than 4K?
A: Yes, lower-bandwidth 1080p60 signals can be extended over longer distances than 4K signals.
This makes the kit useful in mixed-resolution installations where some displays operate at Full HD and others at 4K.
What applications suit it?
A: It is suitable for conference rooms, classrooms, digital signage, control rooms, and commercial AV systems.
Its compact endpoints and integrated power and control extension make it useful where source and display locations are separated.
Why use HDBaseT instead of a long HDMI cable?
A: HDBaseT carries HDMI and control functions over structured category cabling, which is often easier to install over long building runs.
The AT-AVA-F1311 also adds bidirectional PoC, IR, and RS-232, making it a complete extension solution for integrated AV systems.
