4K 60 1x4 HDBaseT Splitter

WolfPack

4K 60 1x4 HDBaseT Splitter
$650.00
Part Number:
HDTVSUH141T-KIT
UPC:
728370340228
Condition:
New
Availability:
Usually ships in 5-7 business days
1:
Support resolution up to 4K 60 4:2:0
2:
RS232, IR pass through, and IR cascade control
3:
Supports PoH and EDID management
4:
1080p Transmission distance up to 230'
5:
Send 1-UHD/4K HDMI signal to 4 HDBaseT outs

4K 60 1x4 HDBaseT Splitter

The 4k/60 1x4 HDBaseT Splitter is a 4K/UHD HDMI to HDBaseT splitter with 1 HDMI input, 1 HDMI loop output and 4 extended distance HDBaseT outputs. Each output transmits video and control signals up to 70m@1080P and 40m@4K. It features 4K@60Hz 4:2:0, HDCP 2.2compliance, EDID management and PoH for powering remote receiver. Backed by a HDTVSupply 1-year warranty and free lifetime technical support.

4K 60 1x4 HDBaseT Splitter Features:

  • Splits a single HDMI input to four HDBaseT outputs and one HDMI loop output.
  • Supports video resolutions up to 4K@60Hz 4:2:0.
  • Extends 1080p signals on each output to distance up to 229 feet (70 meters) and 4K signals to distance up to 131 feet (40 meters) over a CATx Ethernet cable.
  • Supports the Power over HDBaseT (PoH) feature, allowing the HDBaseT receivers to be powered by the splitter over the Ethernet cables.
  • Supports bidirectional IR and RS232 pass-through and loop out.
  • Smart EDID management. Features DIP switch to select the output resolution to match the connected displays.
  • Fully compliant with the HDMI 1.4 specification.
  • Supports HDCP pass-through management.
  • Supports firmware update.
  • Intuitive indicator for connection status

Why not buy this 4K 60 1x4 HDBaseT Splitter today?

4K 60 1x4 HDBaseT Splitter Specification:

Why not buy this 4K 60 1x4 HDBaseT Splitter today?

Frequently
Reasons To Buy an HDTV Supply WolfPack Product

What Is a WolfPack Fixed HDMI Matrix Switcher?

A WolfPack Fixed HDMI Matrix Switcher is a single-chassis device that routes any HDMI source — such as a cable box, satellite receiver, streaming player, or computer — to any TV or display in a building, simultaneously and independently. Unlike an HDMI splitter (which sends one source to many screens) or a simple HDMI switch (which selects one source for one screen), a matrix switcher lets you show a different channel on every TV at the same time. HDTV Supply has sold WolfPack fixed matrix switchers to sports bars, restaurants, hotels, churches, schools, and commercial AV integrators since 2000.

Fixed vs. Modular: Which Do You Need?

WolfPack comes in two families: Fixed and Modular. Fixed matrix switchers have a set number of inputs and outputs built into one box — for example, 4 inputs × 4 outputs (4×4) or 8 inputs × 8 outputs (8×8). They are plug-and-play, rack-mountable, and the right choice when your input/output count won't change. Modular matrix switchers use a chassis with swappable I/O cards, scaling from a few ports up to 80×80 or beyond. If you know exactly how many sources and screens you need today, a fixed unit is typically lower cost and simpler to deploy.

Available Fixed WolfPack Configurations

HDTV Supply offers WolfPack Fixed HDMI Matrix Switchers in the following sizes:

  • 4Ă—2 — 4 sources to 2 displays
  • 4Ă—4 — 4 sources to 4 displays
  • 8Ă—8 — 8 sources to 8 displays
  • 8Ă—9 — 8 sources to 9 displays
  • 16Ă—16 — 16 sources to 16 displays
  • 16Ă—32 via CAT6 — extends signal up to 450 feet over CAT6 cable

Select models include built-in video wall processing, multiview, and picture-in-picture (PIP) — allowing two or more sources to display on a single screen simultaneously.

Control Options for Fixed Matrix Switchers

Every WolfPack Fixed HDMI Matrix Switcher supports multiple control methods so you can integrate it into any environment:

  • Front-panel buttons — manual source switching directly on the unit
  • IR remote control — included with most models
  • RS-232 serial control — for integration with Crestron, Control4, AMX, and similar systems
  • TCP/IP (LAN) control — send hex commands over your network from any device
  • Web GUI — browser-based interface for switching without additional software
  • Free iOS and Android apps — available for select WolfPack models

For RS-232 hex command strings and TCP/IP control protocols, see our WolfPack HEX Code Reference and TCP/IP Control Guide.

Frequently Asked Questions

What is the difference between a fixed HDMI matrix switcher and a modular HDMI matrix switcher?

A fixed HDMI matrix switcher has a set number of HDMI inputs and outputs built into a single unit — for example, 8 inputs and 8 outputs. A modular matrix switcher uses a chassis with interchangeable I/O cards, so you can configure it for many different port counts and expand it later. Fixed units are simpler and more affordable; modular units offer flexibility for larger or changing installations.

Can a WolfPack fixed matrix switcher show different channels on different TVs at the same time?

Yes. A matrix switcher routes any input to any output independently. In an 8×8 configuration, all 8 displays can show 8 completely different sources simultaneously, or multiple displays can share the same source — in any combination you choose.

Can I control a WolfPack fixed matrix switcher from a Crestron or Control4 system?

Yes. WolfPack Fixed HDMI Matrix Switchers support RS-232 and TCP/IP control, which are standard integration protocols supported by Crestron, Control4, AMX, and other third-party control systems. HDTV Supply provides hex command strings and driver documentation to support custom integrations.

What resolution do WolfPack Fixed HDMI Matrix Switchers support?

Resolution support varies by model. WolfPack fixed matrix switchers are available in 1080p (Full HD) and 4K 30Hz configurations. Select 4K models also support HDR and HDCP 2.2. Always check the individual product specification sheet for confirmed resolution, color depth, and HDCP version.

How far can I run HDMI from a WolfPack fixed matrix switcher?

Standard HDMI outputs on fixed matrix switchers support runs up to approximately 25–50 feet depending on cable quality and resolution. The WolfPack 16×32 model transmits over CAT6 cabling for distances up to 450 feet per run. For longer distances with other fixed models, HDMI extenders can be added at each display.

What is the best HDMI matrix switcher for a sports bar?

For sports bars with up to 16 TVs, a WolfPack Fixed 16×16 HDMI Matrix Switcher is a popular choice — it handles 16 independent sources (cable boxes, satellite receivers, streaming devices) and routes any of them to any TV. For larger venues with 20–80+ TVs, HDTV Supply's WolfPack Modular Matrix Switchers or AV Over IP systems are typically the better fit. Call 833-WOLFPACK (833-965-3722) for a free consultation.

Need Help Choosing?

HDTV Supply has been helping AV integrators, sports bars, hotels, and homeowners select the right matrix switching system for 25 years. Call us at 833-WOLFPACK (833-965-3722) or email kent@hdtvsupply.com and we'll recommend the right unit for your source count, display count, resolution requirements, and control system.
