HDTV Supplys WolfPack™ 1x10 Wallplate HDMI Matrix Switch Over IP with POE use our implementation of H.264 LAN technology as the compression format as it occupies a lower bandwidth and transmits HDMI video and audio over the LAN for a better picture. Because it is a 1x10 HDMI Matrix Switcher it allow the any input to be routed to any output or the same input to be routed to all outputs or any combination.
The 1x10 Wallplate HDMI Matrix Switch Over IP with POE supports distances up to ~400 feet over single CAT5e/6 cable in point to point, point to many & many to many configurations. The 1x10 Matrix Switch allows you to route signals from any of the four video inputs to any or all of the four video outputs, in any combination. POE technology from your POE Ethernet switch (not supplied) supplys power to the Wallplate Transmitters & Wallplate Receivers. The set includes a DC 5V 1A power supply when POE is not used.
POE Designed: By utilizing POE (Power Over Ethernet) technology both HDMI audio and video signals and power can be sent to a device via standard CAT5e/6/6a cabling. This means you do not need to install a power outlet at the device location and you can use readily available, relatively low cost Ethernet cabling with this HDMI Wallplate Extender over IP Extender. A Ethernet POE switch is required and not supplied.
1x10 Wallplate HDMI Matrix Switch Over IP with POE Features:
Supports one to one, one to many, many to one, many to many modes, with large cascade
Follows the North American Wall plate standard
Transmit up to 120m or ~400 feet over single CAT5e/6 cable
Using H.264 compression encoding and supports resolutions up to 1080p@60hz
Complies with TCP/IP protocol with a streaming bit rate to 15Mbps
Supports Analog 2.0 Audio Extraction at Receiver for an Amp
Supports LPCM audio format
Supports PC Tools control
Compatible with Video Players such as VLC, etc
802.3 of compliant POE (No Power Supplys needed when connecting with a user supplied POE Switch)
HDCP 1.3 Compliant
Includes a DC 5V 1A power supply when POE not used.
Why not buy this 1x10 Wallplate HDMI Matrix Switch Over IP with POE today?
HDMI conversions to TCP/IP allows you to forego the limitations of point-to-point extender systems and transmit directly over your network. You can also use this 1x10 Wallplate HDMI Matrix Switch Over IP with POE as a matrix switch and transmit for up to ~400 feet over a single CAT5e/6 cable or 330 feet over a CAT5e cable.
1x10 Wallplate HDMI Matrix Switch Over IP with POE Specs:
Includes 1-POE TXs and 10-POE RXs
Data compression: Complies to H.264
Data transmission protocol: Complies to TCP / IP
Supported Video format: 480i/480p/576i/576p/720p/1080i/1080p@60HZ
